Metabo Spare Parts for Band Saw BAS 317 Precision WNB
We are METABO original spare parts and Accessories Worldwide Dealers at low at Amazing price guarantee, tech assistance with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Band Saw BAS 317 Precision WNB 0090317000 10.
In the following table, look for the model of the Band Saw and the respective parts of the code.
| BAS 317 Precision WNB 0090317000 10 | ||
| # | Part Num. | Description |
| 1 | 14118011 | Retaining ring |
| 2 | 34410193 | bandsaw bandage |
| 3 | 31541974 | BANDSAW WHEEL, UPPER |
| 4 | 7100047254 | DEEP GROOVE BALL BEARING 17X40X12 6203-2 |
| 5 | 34341135 | Switch |
| 6 | 1009719748 | SAFETY SWITCH MIT KABEL BAS 317 PRECISIO |
| 7 | 14111032 | Hexagon head screw |
| 8 | 14113101 | Hexagonal nut |
| 9 | 34343318 | Push stick |
| 10 | 138114459 | LAMELLAR PLUG 100X60X3,2 VL SCHWARZ |
| 11 | 7005135529 | Thumb-nut |
| 12 | 7001047374 | STARKNOB SCREW M 8X65 (DIN 558) VERZINKT |
| 13 | 1009719845 | Door handle BAS 317 PRECISION |
| 14 | 1009719888 | SAWBAND GUARD BAS 317 PRECISION |
| 15 | 1388681035 | SHAFT WITH GEARWHEEL ET |
| 16 | 1381681013 | STARKNOB ET |
| 17 | 1009719853 | ADAPTOR, SUCTION PORT BAS 317 PRECISION |
| 18 | 1485051518 | BEARING SHAFT RD 25X124 UNTEN |
| 19 | 1482666317 | SPANNER SCHAFT ET |
| 20 | 14115005 | Washer |
| 21 | 7000074122 | STARKNOB NUT M 10 / RD 63 VERZINKT |
| 22 | 1382666301 | SAFETY LEVER ET |
| 23 | 1485400172 | SLIDING BOLT RD 30X47 |
| 24 | 7100086764 | DEEP GROOVE BALL BEARING 12X28X8 6001-2Z |
| 25 | 148540018 | TENSION ROLLER RD 35X28 |
| 26 | 14118006 | RETAINING RING |
| 27 | 6442084643 | SPACER SLEEVE RD 10,7/8,5X50 VERZ. |
| 28 | 9132081414 | BRUSH STRIP |
| 29 | 6110082701 | CUP SQUARE NECK SCREW M 8X100 VERZ. |
| 30 | 6200046208 | HEXAGON NUT M 20X1,5 VERZ. |
| 31 | 14118011 | Retaining ring |
| 32 | 100971987 | BEARING BUSH BAS 317 PRECISION |
| 33 | 1009719861 | THREE-ROLLER GUIDE BAS 317 PRECISION |
| 34 | 1380421352 | BANDSAW WHEEL, LOWER |
| 35 | 7233190017 | POLY-RIB BELT 4 PJ 610 |
| 40 | 1009719802 | SAWBAND GUARD BAS 317 PRECISION |
| 41 | 1009719810 | THREE-ROLLER GUIDE BAS 317 PRECISION |
| 42 | 1009719829 | THRUST BEARING BAS 317 PRECISION |
| 43 | 1009719837 | BEARING BUSH BAS 317 PRECISION |
| 44 | 1009719896 | GUIDE EXTRUSION BAS 317 PRECISION |
| 45 | 14111333 | Hexagon head screw |
| 46 | 6209110995 | Flange nut |
| 47 | 6150421509 | THUMB SCREW RED M 8X18 |
| 48 | 6305002486 | Washer |
| 49 | 138140440 | TABLE INSERT RD 70X5 SCHMALER SCHLITZ |
| 50 | 1380421212 | BANDSAW TABLE 400X548 ET |
| 51 | 1009719942 | TABLE TRUNNION BAS 317 PRECISION |
| 52 | 1009719918 | Clamp BAS 317 PRECISION |
| 53 | 10097199 | PARALLELANSCHLAG BAS 317 PRECISION |
| 60 | 1381666324 | CHIP CASE ET |
| 61 | 1009719969 | DOOR BAS 317 PRECISION |
| 62 | 7000028937 | STARKNOB NUT M 8 (DIN 934) VERZINKT |
| 63 | 1009719772 | Adjustment set for blade tension |
| 64 | 1009719764 | Quick release function BAS 317 PRECISIO |
| 65 | 1009719756 | shaft with handle BAS 317 PRECISION |
| 66 | 1009719926 | MITRE FENCE BAS 317 PRECISION |
| 67 | 1009719934 | AUXILIARY FENCE EXTRUSION BAS 317 PRECI |
| 68 | 1009003602 | MOTOR, BANDSAW BAS 0,74 WNB 1X230 V |
| 69 | 7240419429 | POLY-RIB PULLEY 4JX62 / RDA 62X47,5 RDI |
| 70 | 14115041 | Serrated lock washer |
| 71 | 6103001127 | Hex head screw |
| 72 | 1009719799 | ROLLER GUIDE BAS 317 PRECISION |
| 75 | 1382705951 | FAN COVER BAS 316 |
| 76 | 138170594 | No longer available |
| 77 | 8050724043 | CAPACITOR 16µF 40X80 KABEL.300 BAS 317 |
| 80 | 100971995 | WORKSTAND BAS 317 PRECISION |
