Metabo Spare Parts for Hammer Drill SBE 1010 Plus
€27.50
Tax included
Metabo Spare Parts for Hammer Drill SBE 1010 Plus
We are METABO original spare parts and Accessories Worldwide Dealers at low at Amazing price guarantee, tech assistance with professional repair service able to advise you to purchase the most suitable spare part to quickly solve any maintenance or repair issues for Hammer Drill SBE 1010 Plus - 01108000.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Metabo Spare Parts for Hammer Drill SBE 1010 Plus
We are METABO original spare parts and Accessories Worldwide Dealers at low at Amazing price guarantee, tech assistance with professional repair service able to advise you to purchase the most suitable spare part to quickly solve any maintenance or repair issues for Hammer Drill SBE 1010 Plus - 01108000.
In the following table, look for the model of the Percussion Drill and the respective parts of the code.
| Hammer Drill SBE 1010 Plus 01108000 | ||
| # | Part Num. | Description |
| 3 | 34160364 | Drill Spindle |
| 4 | 34151163 | Depth Stop |
| 5 | 14112249 | Self-Tap. Fill. H. Screw |
| 6 | 31603099 | Gear Housing CPL. |
| 7 | 34000401 | Cursor lock |
| 8 | 31602771 | Switch Housing Compl. |
| 9 | 31603038 | Intermediate Gear |
| 10 | 34154001 | Guide Bolt |
| 11 | 33912927 | Shift fork |
| 12 | 34409591 | Seal |
| 13 | 31603100 | Gear Flange CPL. |
| 14 | 33921083 | Shaft Sealing Ring |
| 15 | 14118168 | Retaining Ring |
| 16 | 14311022 | Ball Bearing 15x 32x 9 |
| 17 | 34105565 | Slotted Disc |
| 18 | 31602953 | Control Knob CPL. |
| 20 | 34337604 | Sealing ring |
| 21 | 34409592 | Rubber Buffer |
| 22 | 14311340 | Ball Bearing 8x 22x 7 |
| 23 | 31000788 | Armature compl. 230 V |
| 24 | 14311475 | Ball bearing 8x 22x 6 |
| 25 | 34337427 | Intermediate flange |
| 26 | 34307802 | Temperature sensor |
| 27 | 31400079 | Support Handle CPL. |
| 28 | 33804533 | Rating plate |
| 29 | 34307878 | VTC Electronic Signal, 230V |
| 31 | 34340688 | Poti switch |
| 32 | 14111706 | Screw |
| 33 | 31604106 | Pistol grip, 2 piece, rubber |
| 34 | 34336249 | Cable clip |
| 36 | 14319243 | O-ring |
| 37 | 14111826 | Self-Tap. Fill. H. Screw |
| 38 | 31100981 | Field Coil 230 V |
| 39 | 31501265 | Motor Housing |
| 40 | 33812216 | Metabo label, 08 52x22 |
| 41 | 33811541 | Iindication Label |
| 42 | 33912939 | Brush contact |
| 43 | 31602879 | Brush holder Module |
| 44 | 34449318 | Cord with CEE plug |
| 46 | 34410116 | Cable sleeve |
| 47 | 31603496 | carbon Brush set |
| 49 | 14115581 | ring |
| 50 | 34337865 | supporting piece |
| 51 | 31603574 | Fan with prot. Grid |
| 52 | 33811788 | Self adhesive |
| 880 | 34413093 | Grease in tube 50gr 1,8oz |
| 882 | 34413097 | Grease in tube 50gr 1,8oz |
| 1001 | 33850225 | Data plate |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Metabo websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Metabo brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Metabo SBE 1010 Plus - 01108000
