Metabo Spare Parts for Multi Hammer UHEV 2860-2 Quick
We have the original Spares for Multi Hammer UHEV 2860-2 Quick - 00713000, the diagram, parts list and tool repair that help you need to get your tools running like new again.
In the following table, look for the model of the Mahher and the respective parts of the code.
| Multi Hammer UHEV 2860-2 Quick/00713000 | ||
| # | Part Num. | Description |
| 1 | 31001165 | Armature compl.,230 V (w. tacho gen.) |
| 2 | 31101163 | Field coil w.field coil,230 V |
| 3 | 14111826 | Self-tap. fill. h. screw |
| 4 | 34341095 | Electronic Switch |
| 5 | 34448673 | Cord with plug |
| 6 | 34339430 | Cable sleeve |
| 7 | 34336249 | Cable clip |
| 8 | 31605196 | Brush holder module,230V |
| 9 | 34308515 | Electronic unit,230V 50/60Hz |
| 10 | 31501370 | Motor housing |
| 11 | 14311517 | Ball bearing,6x19x6 |
| 12 | 14311488 | Ball bearing, 8x22x7 |
| 13 | 14319243 | O-ring |
| 14 | 34343804 | Intermediate flange |
| 15 | 14111706 | Self-tap. fill. h. screw |
| 16 | 34337604 | Sealing ring |
| 17 | 31400146 | Support handle compl. |
| 18 | 34151163 | Depth stop |
| 19 | 34343803 | Handle cover |
| 20 | 34152023 | Cylindrical pin |
| 21 | 34410178 | Seal |
| 22 | 34409592 | Rubber buffer |
| 23 | 34407067 | Felt seal |
| 24 | 34100630 | Bearing ring |
| 25 | 14319535 | O-ring |
| 26 | 34121133 | exciter sleeve compl. |
| 27 | 34107175 | Ratched wheel |
| 28 | 34105976 | Catching sleeve |
| 29 | 14319521 | O-ring |
| 30 | 14115656 | Circlip |
| 31 | 33900719 | Washer |
| 32 | 14319515 | O-ring |
| 33 | 34101347 | Support ring |
| 34 | 34100595 | Bushing |
| 35 | 34121220 | piston |
| 36 | 14319538 | Shaft sealing ring |
| 37 | 34000445 | Intermediate gear |
| 38 | 33900715 | Washer |
| 40 | 34000449 | Pinion shaft |
| 41 | 33913435 | guide sheet |
| 42 | 34001309 | Spur gear |
| 43 | 34107183 | clutch hub |
| 44 | 34000453 | Claw wheel |
| 45 | 34000446 | coupling sleeve |
| 46 | 34200406 | Pressure spring |
| 47 | 34154022 | Switch rod |
| 48 | 31606255 | Shift element compl. |
| 49 | 31606245 | Control knob compl. |
| 50 | 34337675 | Seal |
| 51 | 14319587 | O-ring |
| 52 | 34343824 | Housing cap,UHE |
| 54 | 33913718 | Bearing cover |
| 55 | 14111884 | Self-tap. fill. h. screw |
| 56 | 14111957 | Fill. head screw(DIN 7985) |
| 57 | 14111613 | Self-tap. fill. h. screw |
| 58 | 14112398 | Fillister head screw |
| 59 | 31604735 | Adaptor SDS -PLUS |
| 60 | 31604750 | Keyless chuck w.adapt. |
| 61 | 33806690 | Rating plate |
| 64 | 31606524 | Intermediate shaft compl. |
| 65 | 31606397 | Gear-box compl. |
| 66 | 31606398 | Gear housing compl. |
| 67 | 31606399 | Gear flange cpl. |
| 68 | 31606907 | Drill driving sleeve compl. |
| 69 | 31606401 | Wobbler drive compl. |
| 70 | 31606536 | Striker compl. |
| 71 | 31606402 | Maintenance kit SDS |
| 73 | 33000183 | Fan |
| 74 | 30100314 | Keyless chuck, 1,5-13 |
| 75 | 31605063 | Quick-change adaptor |
| 76 | 34170336 | Cap screw |
| 77 | 39999999 | Part not needed |
| 80 | 14115636 | Circlip |
| 880 | 34413080 | Grease FG 126 |
| 885 | 34413121 | Tube Grease,50g Klueber Microlube GL 261 |
