Metabo Spare Parts for Wall Chaser MFE 40
€2.03
Tax included
We are METABO original spare parts and Accessories Worldwide Dealers at low at Amazing price guarantee, tech assistance with professional repair service able to advise you to purchase the most suitable spare part to quickly solve any maintenance or repair issues for Wall Chaser MFE 40 - 04040000.Metabo Spare Parts for Wall Chaser MFE 40
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Metabo Spare Parts for Wall Chaser MFE 40
We are METABO original spare parts and Accessories Worldwide Dealers at low at Amazing price guarantee, tech assistance with professional repair service able to advise you to purchase the most suitable spare part to quickly solve any maintenance or repair issues for Wall Chaser MFE 40 - 04040000.
In the following table, look for the model of the Wall Chaser and the respective parts of the code.
| Wall Chaser MFE 40/04040000 | ||
| # | Part Num. | Description |
| 1 | 31001223 | Armature compl.,230V |
| 2 | 31101298 | Field coil assembly 230V |
| 3 | 34341155 | Switch,AC |
| 6 | 34336249 | Cable clip |
| 7 | 14111706 | Self-tap. fill. h. screw |
| 8 | 34308626 | Electronic unit,230V |
| 9 | 31501379 | Motor housing |
| 10 | 33915118 | Baffle |
| 11 | 33915120 | Baffle |
| 12 | 14311517 | Ball bearing,6x19x6 |
| 13 | 34409787 | Rubber bushing |
| 14 | 14311518 | Ball bearing,8x22x7 |
| 15 | 34343306 | Tacho disc |
| 16 | 33913306 | Washer,8,05x17x0,4 |
| 17 | 33900639 | Washer,7,05x19,5x0,2 |
| 18 | 34110226 | Hexagon nut w.recess |
| 19 | 34344511 | D-handle 2 part |
| 21 | 33901224 | Gasket |
| 22 | 31606602 | Intermediate flange pre-assembled |
| 23 | 31606625 | Routing attachment compl. |
| 24 | 34121244 | clamping flange |
| 25 | 34103238 | spacing washer |
| 26 | 34121245 | Clamping nut |
| 27 | 33901197 | Gasket |
| 28 | 14112164 | Fill. head screw(DIN 7985) |
| 29 | 14111698 | Self-tap. fill. h. screw |
| 31 | 14112409 | Fillister head screw |
| 32 | 33806912 | Rating plate |
| 33 | 39999999 | Part not needed |
| 34 | 34416070 | Pin spanner offset |
| 35 | 34414765 | Point |
| 36 | 31605498 | Bevel gear w.pinion |
| 37 | 31605508 | Friction washer set compl. |
| 38 | 31605510 | Gear housing compl. |
| 39 | 31606542 | Brush holder set |
| 40 | 31605485 | Fan w. dust guard |
| 41 | 31606545 | Carbon brush set cut-off |
| 42 | 31606627 | Gear wheel compl. |
| 43 | 31606628 | Shaft & Washers set compl. |
| 44 | 34344588 | Handle welded |
| 45 | 14111474 | Countersunk screw |
| 61 | 14115665 | Retaining ring |
| 62 | 14319600 | O-ring |
| 63 | 34200339 | Pressure spring |
| 64 | 34343364 | Push button |
| 65 | 34151564 | Bolt |
| 80 | 31520314 | Gear flange |
| 81 | 14319532 | O-ring |
| 82 | 14311546 | Needle roller |
| 83 | 14311146 | Needle sleeve |
| 84 | 14115128 | Washer |
| 85 | 14111957 | Fill. head screw(DIN 7985) |
| 86 | 34160541 | Intermediate shaft |
| 87 | 14311562 | Ball bearing, |
| 89 | 14115112 | Washer 10,2 X 14,8X 0,2 |
| 90 | 14115230 | Washer 10,2 X 14,8X 0,1 |
| 91 | 14115392 | Washer 10,2 X 14,8X 0,5 |
| 92 | 34110246 | Nut |
| 93 | 34344592 | Extraction nozzle compl. |
| 94 | 34111293 | Clamping lever,M6x20 |
| 95 | 34121230 | Roller |
| 124 | 31606717 | carbonbrush with brusholder Set 230V |
| 880 | 34413092 | Grease 100G |
| 885 | 34413056 | Grease SF 011 50Gr 1,8oz |
| 1001 | 33850637 | Wiring diagram |
| 1005 | 31606732 | Cable with sleeve |
