Metabo Spare Parts for Angle Grinder W 2000 - 06420260
We are METABO original spare parts Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Angle Grinder W 2000 - 06420260.
In the following table, look for the model of the Angle Grinder and the respective parts of the code.
| ANGLE GRINDER METABO W 2000 - 06420260 | ||
| # | Part Num. | Description |
| 1 | 31400028 | Handle |
| 2 | 34337644 | Button |
| 3 | 34200173 | Spring |
| 4 | 34100397 | Guide bushing |
| 5 | 31603172 | Gearbox |
| 6 | 34151381 | Pin |
| 7 | 34110066 | Hexagonal nut with collar |
| 8 | 31602529 | Bevel Gear Set |
| 9 | 34101151 | Spacer ring |
| 10 | 14319244 | Impregnated felt ring |
| 11 | 33907008 | Cover disk |
| 12 | 14311523 | ball Bearing 12x 37x 12 |
| 13 | 33900728 | Fixed bearing cover |
| 14 | 31609425 | Armature Ass'y |
| 15 | 14311340 | Ball Bearing 8x 22x 7 |
| 16 | 34409408 | Rubber support |
| 17 | 33915095 | Air conveyor |
| 18 | 14112168 | Screw |
| 19 | 31101260 | Complete Stator (Field) |
| 20 | 34449369 | Faston |
| 21 | 39999999 | DETAIL NOT NECESSARY |
| 22 | 39999999 | DETAIL NOT NECESSARY |
| 23 | 14111937 | Screw |
| 24 | 14112202 | Screw with mik shell |
| 25 | 14112480 | Screw with cap |
| 26 | 33906014 | Seal ring |
| 27 | 31604747 | Complete gearbox flange, D 230 |
| 28 | 14112164 | Screw (DIN 7985) |
| 29 | 34160416 | Grinding shaft |
| 30 | 39999999 | DETAIL NOT NECESSARY |
| 31 | 39999999 | DETAIL NOT NECESSARY |
| 32 | 34110690 | Nut with flange |
| 33 | 39999999 | DETAIL NOT NECESSARY |
| 34 | 39999999 | DETAIL NOT NECESSARY |
| 35 | 34103116 | Clamping flange |
| 36 | 31604500 | Complete protection cap, D 230 |
| 37 | 34170205 | Screw |
| 38 | 34337643 | Cover |
| 39 | 31604748 | Carbon Brush set |
| 40 | 34300077 | Carbon Brush guide |
| 41 | 14111602 | Screw |
| 42 | 34339826 | Upper and lower handle 22 |
| 43 | 34340918 | Complete switch 26 |
| 44 | 33912773 | Cable holder 11 |
| 45 | 14111680 | Screw 11 |
| 46 | 34409455 | Cable protection 13 |
| 47 | 34448780 | Cable with CEE plug 25 |
| 48 | 33811734 | Information plate 11 |
| 49 | 34416084 | Two pin wrench 17 |
| 50 | 31501276 | Motor case 27 |
| 51 | 33812208 | Metabo plate 14 |
| 52 | 33805397 | Data plate 11 |
| 53 | 39999999 | DETAIL NOT NECESSARY |
| 54 | 14118009 | Safety ring 12 |
| 55 | 34343557 | Washer with centrifugal lubrication 11 |
| 880 | 34413091 | 100G GREASE TUBE 24 |
| 1001 | 33850211 | Data plate |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Metabo websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Metabo brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Metabo W 2000 - 06420260
12 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10 BUSYNESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK S/N METABO:
- METABO S/N START WITH ( 0 ) and have 8 DIGITS
