Metabo Spare Parts for Rotary Hammer UHE 20
€84.41
Tax included
Metabo Spare Parts for Rotary Hammer UHE 20
Fix Your Rotary Hammer UHE 20 00691000. All Spares are Ready For Quick Delivery. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Metabo Spare Parts for Rotary Hammer UHE 20
Fix Your Rotary Hammer UHE 20 00691000. All Spares are Ready For Quick Delivery. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following table, look for the model of the Drill and the respective parts of the code.
| Metabo Rotary Hammer UHE 20 00691000 | ||
| # | Part Num. | Description |
| 1 | 31602959 | Adaptor SDS - PLUS |
| 2 | 14319491 | Shaft sealing ring |
| 3 | 14311383 | Needle sleeve |
| 4 | 31603053 | Gear housing cpl. |
| 5 | 14115375 | Supporting disc |
| 6 | 34200269 | Pressure spring |
| 7 | 34337444 | Retaining ring |
| 8 | 33811449 | Indication label |
| 9 | 14112249 | Self-tap. fill. h. screw |
| 10 | 31602951 | Sliding block |
| 11 | 31603056 | Drill driving sleeve cpl. |
| 13 | 31603058 | Intermediate striker cpl. |
| 14 | 14319240 | O-ring |
| 15 | 34101255 | Supporting ring |
| 16 | 14319391 | O-ring |
| 17 | 31603057 | Catching sleeve cpl. |
| 18 | 14319392 | O-ring |
| 19 | 14118184 | Circlip |
| 20 | 31601766 | Striker cpl. |
| 21 | 34409314 | Sealing ring |
| 22 | 34105577 | Exciter sleeve |
| 23 | 32005048 | Ball holder |
| 24 | 34409557 | Seal |
| 25 | 31603054 | Gear flange cpl. |
| 26 | 34407067 | Felt seal |
| 27 | 34409592 | Rubber buffer |
| 28 | 31603262 | Control knob cpl. |
| 29 | 33912961 | Washer |
| 30 | 14311428 | Axial needle bearing |
| 31 | 14115492 | Cup spring |
| 32 | 34000323 | Coupling sleeve |
| 33 | 31603048 | Intermediate gear cpl. |
| 34 | 31602956 | Shift element |
| 35 | 14111944 | Fill. head screw(DIN 7985) |
| 36 | 34151163 | Depth stop |
| 37 | 31400063 | Supporting handle cpl. |
| 38 | 34337604 | Sealing ring |
| 39 | 14311488 | Ball bearing, 8x22x7 |
| 40 | 30100219 | Futuro plus ring S2M 13 mm |
| 41 | 31000783 | Armature cpl.230V |
| 42 | 14311475 | Ball bearing, 6X 19X 6 |
| 43 | 34337427 | Intermediate flange |
| 44 | 33804629 | Rating plate |
| 45 | 34337428 | Cover w.o. electronic |
| 46 | 34340687 | Electronic switch with dial |
| 47 | 14111706 | Self-tap. fill. h. screw |
| 48 | 34339302 | Pistol grip 2 piece |
| 49 | 34336249 | Cable clip |
| 50 | 14319243 | O-ring |
| 51 | 14111826 | Self-tap. fill. h. screw |
| 52 | 31100980 | Field coil 230V |
| 53 | 31501265 | Motor housing |
| 54 | 33812216 | M-Label,08 52x22 |
| 55 | 31602810 | Brush holder module |
| 56 | 34325378 | Interference suppr. cond. |
| 57 | 34448673 | Cord with plug |
| 59 | 34410114 | Cable sleeve |
| 60 | 31603494 | Brush with holder,230V/120V |
| 61 | 31603203 | Maintenance kit |
| 62 | 34170099 | Cap screw |
| 63 | 31603239 | Adaptor |
| 64 | 33913098 | Butting sheet |
| 65 | 34337675 | Seal |
| 66 | 33811541 | Indication label |
| 68 | 34101263 | Ring |
| 69 | 31603573 | Fan w. prot. Grid |
| 880 | 34413080 | Grease FG 126 |
| 890 | 34413056 | Grease SF 011 50Gr 1,8oz |
| 1001 | 33850413 | Diagram |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Metabo websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Metabo brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Metabo UHE 20 - 00691000
5 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10 BUSYNESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK S/N METABO:
- METABO S/N START WITH ( 0 ) and have 8 DIGITS
