Metabo Spare Parts for Angle Grinder W 750-115
€1.66
Tax included
Metabo Spare Parts for Angle Grinder W 750-115
We are METABO original spare parts and Accessories Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Angle Grinder W 750-115 - 01230000.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Metabo Spare Parts for Angle Grinder W 750-115
We are METABO original spare parts and Accessories Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Angle Grinder W 750-115 - 01230000.
In the following table, look for the model of the Angle Grinder and the respective parts of the code.
| Angle Grinder W 750-115/01230000 | ||
| # | Part Num. | Description |
| 1 | 31400054 | Handle cpl. |
| 2 | 31604061 | Spindle stop compl. |
| 3 | 31606364 | Gear housing compl. |
| 4 | 34110094 | Hexagon nut w.recess |
| 5 | 31605781 | Bevel gear and pinion |
| 6 | 14111046 | Fillister head screw |
| 7 | 14311542 | Ball bearing, 8x22x7 |
| 8 | 31541749 | Fixed bearing cover |
| 9 | 34339274 | Sealing washer |
| 10 | 14311587 | Ball bearing, 6x19x6 |
| 11 | 31001071 | Armature cpl. 230 V |
| 12 | 34409526 | Rubber bushing |
| 13 | 34339943 | Baffle |
| 14 | 34339945 | Cover |
| 15 | 14111602 | Self-tap fill h screw |
| 16 | 14319592 | O-ring |
| 17 | 34116115 | Spindle M14 |
| 18 | 14319254 | O-ring |
| 19 | 31606378 | Flange compl. |
| 20 | 14112007 | Fill. head screw |
| 21 | 34110690 | Flange nut |
| 22 | 34103116 | Clamping flange |
| 23 | 14112406 | Fillister head screw |
| 24 | 33920366 | Wheel guard compl.,Ø115 |
| 25 | 33812216 | M-Label,08 52x22 |
| 26 | 34341051 | Switch slide red |
| 27 | 34339917 | Switch rod |
| 28 | 34336249 | Cable clip |
| 29 | 31101180 | Field coil |
| 30 | 33806578 | Rating plate, 01230000 W 750-115 |
| 31 | 34339944 | Motor housing |
| 32 | 33812254 | Metabo plate |
| 33 | 31605277 | Carbon brush compl. |
| 35 | 34301295 | Brush holder |
| 36 | 34325503 | Capacitor |
| 37 | 34341102 | Switch,EPXe 230 V |
| 38 | 34409736 | Cable sleeve |
| 39 | 34449954 | Cable w.CEE plug |
| 40 | 34416392 | Pin spanner |
| 41 | 33906016 | Compensating Washer |
| 42 | 33900779 | Washer |
| 880 | 34413091 | Grease 100G |
| 1001 | 33850447 | Diagram |
