Metabo Spare Parts for Chipping Hammer MHE 5
€19.23
Tax included
Metabo Spare Parts for Rotary Hammer MHE 5
Distribution and sale of original Metabo spare parts, low prices and a professional repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance and repair problem for Rotary Hammer MHE 5 - 00688000.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Metabo Spare Parts for Rotary Hammer MHE 5
Distribution and sale of original Metabo spare parts, low prices and a professional repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance and repair problem for Rotary Hammer MHE 5 - 00688000.In the following table, look for the model of the Hammer and the respective parts of the code.
| Chipping Hammer MHE 5/00688000 | ||
| # | Part Num. | Description |
| 1 | 34410255 | Rubber bushing |
| 2 | 34121093 | Sleeve |
| 3 | 34344026 | Ring |
| 4 | 34101340 | Support ring |
| 5 | 34101332 | semi ring |
| 6 | 34101333 | Support ring |
| 8 | 14115672 | Retaining ring |
| 9 | 34344099 | Setting ring |
| 10 | 14319576 | O-ring |
| 11 | 34152034 | Pin |
| 12 | 34121094 | Drill driving sleeve,SDS |
| 13 | 34121113 | Roller |
| 14 | 14115673 | Retaining ring |
| 15 | 34411300 | Bellows |
| 16 | 34411301 | Bellows |
| 17 | 34101341 | Support ring |
| 18 | 14319577 | O-ring |
| 19 | 14319578 | O-ring |
| 20 | 14319579 | O-ring |
| 21 | 34121095 | Piston |
| 22 | 14319584 | O-ring |
| 23 | 33914754 | Washer |
| 24 | 34101342 | Spacing washer |
| 25 | 34121096 | Drill driving sleeve |
| 26 | 34344028 | Retaining ring |
| 27 | 34202263 | Spring |
| 28 | 33914755 | Washer |
| 29 | 34121097 | Striker |
| 30 | 14319581 | O-ring |
| 31 | 33914761 | Retaining sheet |
| 32 | 34121098 | dog clutch |
| 33 | 14112441 | Screw |
| 36 | 31605948 | Piston compl. |
| 37 | 14311572 | Ball |
| 38 | 34202403 | Spring |
| 39 | 34344029 | Control knob slide |
| 40 | 34407101 | Felt |
| 41 | 14319582 | O-ring |
| 42 | 31510548 | Gear housing |
| 43 | 34411271 | Sealing ring |
| 44 | 33901209 | Washer |
| 46 | 34202265 | Spring |
| 47 | 33914760 | Fork |
| 48 | 14118006 | RETAINING RING |
| 56 | 14116033 | Cylindrical pin |
| 58 | 32005401 | Bearing |
| 59 | 31606126 | Bearing cover compl. |
| 60 | 14112442 | Screw |
| 61 | 14112440 | Self-tap. fill. h. screw |
| 62 | 34411298 | Rubber buffer |
| 63 | 33915313 | Disc flange cover |
| 64 | 14112439 | Screw |
| 65 | 31101226 | Field w.coil |
| 66 | 31510752 | Housing |
| 67 | 31605942 | Brush holder compl. |
| 69 | 31606712 | Carbon brush |
| 70 | 34343647 | Motor cap |
| 71 | 34172218 | Screw |
| 74 | 32005402 | Bearing |
| 75 | 34411267 | Rubber bushing |
| 76 | 31606118 | Armature compl. |
| 77 | 34308482 | Electronic unit |
| 78 | 34344007 | Cover |
| 80 | 31605945 | Connecting set |
| 81 | 34411268 | Bellows |
| 83 | 34172219 | Screw |
| 84 | 34341059 | Switch compl. |
| 85 | 34344100 | CAP |
| 87 | 34344101 | Handle 2 part |
| 88 | 14319575 | O-ring |
| 89 | 34172220 | Screw |
| 90 | 34344024 | CABLE CLAMP |
| 91 | 34411269 | Rubber bushing |
| 92 | 34411270 | Cable sleeve |
| 93 | 34449992 | Cable with plug |
| 97 | 34202264 | Spring |
| 98 | 34344102 | Side support handle |
| 99 | 31606119 | Clamping piece cpl. |
| 100 | 31606120 | Change-over switch compl. |
| 105 | 34100624 | Bush |
| 107 | 31606121 | Maintenance kit |
| 110 | 33806370 | Rating plate |
| 120 | 31606122 | Spindle compl. |
| 880 | 63180000 | Special grease |
| 885 | 13601290 | Gear grease 100g tube |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Metabo websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Metabo brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
