Metabo Spare Parts for Combination Hammer KHE 2444
€1.92
Tax included
Metabo Spare Parts for Combination Hammer KHE 2444
We have the original Spares METABO for Combination Hammer KHE 2444 - 06154000, the Repair information, Exploded Diagram, parts list and tool repair that help you need to get your tools running like new again.Fix Your Combination Hammer KHE 2444. All Spares are original and can be supplied at Cheap and discounted prices.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Metabo Spare Parts for Combination Hammer KHE 2444
Fix Your Combination Hammer KHE 2444 - 06154000. All Spares are original and can be supplied at Cheap and discounted prices. Our Spares are Genuine Parts Guaranteed.
In the following table, look for the model of the Drill and the respective parts of the code.
| Combination Hammer KHE 2444/06154000 | ||
| # | Part Num. | Description |
| 1 | 34409939 | Rubber cap |
| 2 | 34202234 | Circlip |
| 3 | 34343292 | Adjusting ring |
| 4 | 33900765 | Washer |
| 5 | 34200389 | Pressure spring |
| 6 | 14311533 | Ball |
| 7 | 31605295 | Gear housing compl. |
| 8 | 34170481 | Screw |
| 9 | 34101321 | Supporting disc |
| 10 | 14118129 | Circlip |
| 11 | 34207034 | Cup spring |
| 12 | 33900487 | Friction washer |
| 13 | 34000409 | Spur gear |
| 14 | 33900638 | friction slice |
| 15 | 34105923 | coupling sleeve |
| 16 | 31605303 | Drill driving sleeve compl. |
| 17 | 34121061 | Piston |
| 18 | 34116156 | O-ring,11.9X2.62 |
| 19 | 34121060 | Damping ring |
| 20 | 14319464 | O-ring |
| 21 | 34105931 | Catching sleeve |
| 22 | 14319392 | O-ring |
| 23 | 14118184 | Circlip |
| 24 | 34409314 | Sealing ring |
| 25 | 31604801 | Striker compl. |
| 26 | 34121080 | exciter sleeve compl. |
| 27 | 34202235 | sealing ring |
| 28 | 31605304 | Gear flange compl. |
| 29 | 34407067 | Felt seal |
| 30 | 34409592 | Rubber buffer |
| 31 | 14111602 | Self-tap fill h screw |
| 32 | 14311530 | Thrust washer |
| 33 | 14311550 | Axial needle bearing |
| 34 | 34116152 | Intermediate gear compl. |
| 35 | 14115492 | Cup spring |
| 36 | 33900768 | Washer |
| 37 | 31605299 | Control knob compl. |
| 38 | 34339834 | Seal |
| 39 | 14311223 | Ball bearing, 6x19x6 |
| 40 | 31001066 | Armature compl.,230V |
| 41 | 14311506 | Ball bearing, 8X 22X 7 |
| 42 | 34339831 | Sealing washer |
| 43 | 31501348 | Motor housing |
| 44 | 34409222 | Rubber plug |
| 45 | 31604561 | Shift element compl. |
| 46 | 34449914 | Strand |
| 47 | 34449915 | Strand |
| 48 | 34340985 | Electronic switch |
| 49 | 34325456 | Suppressor |
| 50 | 34336249 | Cable clip |
| 51 | 34409938 | Cable sleeve |
| 52 | 31101203 | Field coil compl.,230V |
| 53 | 34448906 | Cable with plug |
| 54 | 34151163 | Depth stop |
| 55 | 31400084 | Support handle cpl. |
| 56 | 31605180 | Carbon brushes complete |
| 57 | 33805898 | Rating plate |
| 58 | 31605493 | Maintenance kit |
| 59 | 31604570 | safety clutch cpl. |
| 60 | 31605302 | Gear-box compl. |
| 880 | 34413080 | Grease FG 126 |
| 890 | 34413056 | Grease SF 011 50Gr 1,8oz |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Metabo websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Metabo brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
