Meccanica Benassi Spare Parts for Hoe-Tiller RL 328 Special
€6.83
Tax included
Meccanica Benassi Spare Parts for Hoe-Tiller RL 328 Special
Meccanica Benassi Genuine spare parts or replacement parts for to repair Hoe-Tiller RL 328 Special.Fix Your Hoe-Tiller RL 328 Special. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Meccanica Benassi Spare Parts for Hoe-Tiller RL 328 Special
Fix Your Hoe-Tiller RL 328 Special All Spares are original and can be supplied at Low and discounted prices For Shipping Our Spares are Genuine Parts and Come with a Full Guarantee
In the following table, look for the model of the Tiller and the respective parts of the code
| Hoe-Tiller RL 328 Special | ||
| RL 328 GRUPPO SCATOLA CAMBIO Pag.1 |
||
| 1 | 6GQ024001 | POWER TAKE-OFF PROTECTION |
| 2 | 6GP03400 | STUD BOLT M 10x35 |
| 3 | 37101060 | WAVY WASHER Ø6 |
| 4 | 39312220 | SCREW TE M 6x14 |
| 5 | 6HC00150 | FIBER WASHER 6-10 |
| 6 | 39703900 | SCREW TC M 6x10 |
| 7 | 6CO050002 | CENTRAL BODY COVER |
| 8 | 3322105T | SELF-LOCKING NUT M 10 |
| 9 | 3730106T | GROWER WASHER Ø10 |
| 11 | 3290105T | NUT M 7 |
| 12 | 6FT01300 | CLAMP |
| 13 | 6FU15400 | SPRING |
| 15 | 6GP09400 | PRISONER M 10x37 |
| 16 | 6DS07370 | UPPER CUTTER GASKET |
| 17 | 37101080 | WAVY WASHER Ø 8 |
| 18 | 3290106T | NUT M 8 |
| 19 | 6FL09200 | RM LEVER |
| 20 | 6HP00600 | THICKNESS 12x20xSp0,3-0,5 |
| 21 | 6FL06800 | SAFE STICK RM |
| 22 | 30201150 | SEAL RING OR115 |
| 23 | 6GP03800 | PRISONER M 8x26 |
| 24 | 6GP02800 | PRISONER M 8x36 |
| 24 | 6GP00800 | PRISONER M 8x40 (15LD315 / 350) Honda |
| 25 | 3730105T | GROWER WASHER Ø8 |
| 26 | 6BQ02400 | LEVER HOLDER BUSH |
| 27 | 6FU031T0 | SPRING |
| 28 | 6HH002T0 | BALL SEEDS |
| 29 | 38201150 | ELASTIC SPINE |
| 30 | 31801090 | DUST CAP |
| 31 | 6DF05800 | FORK |
| 32 | 6BF12100 | FORK HOLDER ROD |
| 33 | 6FL09300 | CLUTCH LEVER |
| 34 | 5HG014T0 | M ARCE SELECTOR |
| 36 | 3931290T | SCREW TE M 8x20 |
| 37 | 6DT020T0 | WIRE GUIDE |
| 38 | 6HC04100 | FIBER WASHER 8/14/3 |
| 39 | 6DS04460 | M OTOR GASKET |
| 40 | DOTAZTAPPO | SEAL 16/22/2 |
| 41 | 30601030 | BREATHER TUBE |
| 42 | 6CS01900 | LEVER HOLDER RING |
| 43 | 6FL084T0 | LEVER CAM BIO M ARCE |
| 44 | 6GL005T0 | FIXING PLATE |
| 45 | 6CT044T0 | DISTANCE |
| 46 | 6HP00200 | THICKNESS 8x14 |
| 47 | 6BF044001 | FORK HOLDER PIN |
| 48 | 38101100 | BALL 1/4 |
| 49 | 6FU00900 | SPRING |
| 50 | 5DF00900 | FORK 1 ° E RM |
| 51 | 5DF01000 | FORK 2 ° AND 3 ° |
| 52 | 6GP02900 | PRISONER M 8x31 |
| 53 | 6CI16000 | CENTRAL BODY |
| 54 | 3322104T | SELF-LOCKING NUT M 8 |
| 55 | 30101150 | SEAL RING 12/22/7 |
| 56 | 6FU16000 | SPRING |
| 57 | 39311250 | SCREW TE M 4x6 |
| 58 | 37301010 | ELASTIC WASHER |
| RL 328 GRUPPO CAMBIO Pag.2 |
||
| 1 | 30101500 | SEAL RING 17x40x7 |
| 2 | 38011400 | SEEGER I 40 |
| 3 | 38001170 | SEEGER E 17 |
| 4 | 6HP03800 | THICKNESS 30x398 |
| 5 | 32501250 | BEARING 6203 |
| 6 | 6HP02200 | THICKNESS 17x30 |
| 7 | 38001210 | SEEGER E 21 |
| 8 | 6FC17000 | GEAR 1st AND RM Z / 35 |
| 9 | 6FC169001 | GEAR 2nd AND 3rd Z / 28/31 |
| 10 | 6HP03050 | THICKNESS 218x35x08 |
| 11 | 30701150 | INNER RING LR 25x30x20,5 |
| 12 | 31901600 | ROLLER CASE HK3020 |
| 13 | 6GS12700 | SECONDARY SHAFT Z / 7 |
| 14 | 6FC38000 | PRIMARY SHAFT Z / 17/13/9/10 |
| 15 | 6BQ11000 | BUSH |
| 16 | 32801080 | THRUST BEARING AX614 |
| 17 | 38001120 | SEEGER E 12 |
| 18 | 32801090 | THRUST BEARING AX1226 |
| 19 | 36871090 | RALLA CP1426 |
| 20 | 6FU12700 | SPRING |
| 21 | 6HP01200 | THICKNESS 14x24 |
| 22 | 6GH08200 | PIN CM |
| 23 | 31901150 | ROLLER CASE HK1412 |
| 24 | 6FC34000 | GEAR RM Z / 17 |
| 25 | 6FC38100 | GEAR RM Z / 30 |
| 26 | 6LD02800 | PLUG |
| 27 | 38101120 | BALL 9/32 |
| 28 | 6HP06600 | THICKNESS 6x16 |
| RL 328 GRUPPO SUPPORTO FRESA Pag.3 |
||
| 1 | 38001190 | Seeger E 19 |
| 2 | 6HP02600 | Thickness 20x30x02-03-05 |
| 3 | 6CC12400 | Cutter return crown z-26 |
| 5 | 32501600 | Ball bearing 6205 25x52x15 |
| 6 | 6CI13100 | Cutter support |
| 7 | 3322105T | Self-locking nut M 10 h10 |
| 8 | 37301060 | Grower washer Ø10 |
| 9 | 6GP09400 | Stud M 10x37 |
| 10 | 32501450 | Ball bearing 6304 20x52x15 |
| 11 | 6DS17400 | Cutter support gasket |
| 12 | 6CI13200 | Crown holder |
| 13 | 6BB021001 | Cutter holder shaft |
| 14 | 6HP04450-60- | Thickness 405x52x02-03 |
| 15 | 38011520 | Seeger I 52 |
| 16 | 30111110 | Sealing ring |
| 17 | 6HC10400 | Felt washer |
| 18 | 6CO117T0 | Dust cover |
| 19 | 6HP036T0 | Thickness 26x32x03 |
| 20 | 6CC12500 | Cutter control crown z-24 |
| 21 | 6HC00830 | Fiber gasket 16x22x15 |
| 22 | 6LD013T0 | Oil plug |
| 23 | 6GS12800 | Conical pinion z-7 |
| RL 328 GRUPPO FRIZIONE PER MOTORI LOMBARDINI 15LD225-15LD315 E LGA226 Pag.4 |
||
| 1 | 32801120 | AX 2542 thrust bearing |
| 2 | 36871140 | Slewing ring CP 3/25/42 |
| 3 | 6FV07700 | Clutch release hub |
| 4 | 6HC13600 | Thickness 1,2 |
| 5 | 6CU00400 | Thickness disc 3 |
| 6 | 33601020 | Clutch disc |
| 7 | 6HM 00700 | Push hard |
| 8 | 35801080 | Diaphragm spring loaded Kg 120 |
| 9 | 32801070 | Thrust bearing Ø30x47x208 |
| 10 | 6CD02900 | Clutch drum |
| 11 | 6BQ01300 | Centering bush |
| 12 | 31901380 | Needle roller case |
| 13 | 37301050 | Grower washer Ø8 |
| 14 | 39403700 | TB M 8x25 screw |
| 15 | 6FU12800 | Ring spring Ø wire 2,5 |
| 16 | 38011900 | Seeger I90 |
| RL 328 GRUPPO FRIZIONE PER MOTORI HONDA GX160 E SINOPOWER 168F Pag.5 |
||
| 1 | 6DS18100 | Packing |
| 2 | 6DI10800 | Motor flange |
| 3 | 6CD03300 | Clutch Drum |
| 4 | 39382010 | Allen screw 5/16 24/7/8 L = 222 |
| 5 | 6FU12800 | Ring spring Ø25 |
| 6 | 35801080 | Diaphragm spring Kg 120 |
| 7 | 6HM00700 | Push hard |
| 8 | 33601020 | Clutch disc Ø83 |
| 9 | 6CU00400 | Clutch disc Th3 |
| 10 | 38011900 | Seeger I 90 |
| 11 | 6FV07700 | Clutch release hub |
| 12 | 36871140 | Slewing ring CP 3/25/42 |
| 13 | 32801120 | thrust bearing X 2542 |
| 15 | 31901380 | needle roller case HK 2012 |
| 16 | 32801070 | Reg Bearing AX 3047 |
| 17 | 37101080 | Corrugated washer Ø8 |
| 18 | 31401200 | Key 473x473x375 |
| 19 | 39342300 | Screw TE 5/16 24 FIL 1-1 / 4 L = 317 |
| RL 328 GRUPPO FRIZIONE PER MOTORE KAMA-KD70 Pag.6 |
||
| 1 | 6BQ11300 | Centering bush |
| 2 | 6CD02900 | Clutch bell |
| 3 | 37301050 | Grower washer Ø8 |
| 4 | 39403700 | TCB M 8x25 screw |
| 5 | 31901380 | Needle roller case |
| 6 | 32801070 | Thrust bearing Ø30x47x28 |
| 7 | 6FU12800 | Ring spring |
| 8 | 32801120 | Reg Bearing AX 2542 25x42x28 |
| 9 | 6CU01000 | Thick disc |
| 10 | 36871140 | Slewing ring CP 3/25/42 |
| 11 | 6FV07700 | Clutch hub |
| 12 | 38011900 | Seeger I90 |
| 13 | 33601020 | Clutch disc Ø83 |
| 14 | 6HM00700 | Push hard |
| 15 | 35801080 | Diaphragm spring Kg 120 |
| RL 328 GRUPPO SUPPORTO MANUBRIO Pag.7 |
||
| 1 | 6FU008T0 | Lever spring |
| 2 | 6CS008T0 | Threaded bush |
| 5 | 5HT39200 | Handlebar support |
| 6 | 36501100 | Rod guide cable gland |
| 7 | 36601010 | Knob for rod Ø10 |
| 8 | 6DT033T0 | Wire guide |
| 9 | 6HC04100 | 8/14/3 fiber washer |
| 10 | 5BF027T0 | Gear control rod |
| 11 | 3320103T | Nut M 6 |
| 12 | 3950245T | VIT AND TSPEI M 6x25 |
| 13 | 3700107T | Beveled washer Ø10 |
| 14 | 3930430T | screw M 10x75 |
| 15 | 3320105T | Self-locking nut M 10 h12 |
| 19 | 3701120T | Common washer Ø6-18 |
| 20 | 3931225T | Screw TE M 6x10 |
| 21 | 5BS00600 | Tool bag |
| 22 | 6GQ07900 | Red casing |
| RL 328 GRUPPO MANUBRIO PER MOTORI LOMBARDINI LGA226 HONDA GX160 E SINOPOWER 168F Pag.8 |
||
| 1 | 35401160 | Complete engine stop |
| 2 | 35601060 | Knob |
| 3 | 6HB004T | Register M 8 |
| 4 | IN DOTAZ | Barrel |
| 5 | 35701020 | Throttle Lever |
| 6 | 35401170 | Full lever |
| 7 | 3710106T | Corrugated washer Ø6 |
| 8 | 3320103T | Self-locking nut M 6 |
| 9 | 6HP07500 | Thickness |
| 10 | 6DG04300 | Reverse safe wire |
| 11 | 6HZ01200 | Sup p toothed garden |
| 12 | 5HR13900 | handlebar |
| 13 | 6HC025T0 | Washer |
| 14 | 6DG15000 | Clutch wire |
| 15 | 39601740 | TCIC M 4x6 screw |
| 16 | 36801030 | Stop button |
| 17 | 6FB06200 | Engine stop wire |
| 18 | 3380121T | Cable tie |
| 19 | 3970325T | Screw TCCI M 5x16 |
| 20 | 3290103T | Nut M 5 h5 |
| RL 328 GRUPPO MANUBRIO PER MOTORI LOMBARDINI 15LD225 E 15LD315 Pag.9 |
||
| 1 | 35401160 | Complete engine stop |
| 2 | 35601060 | Knob |
| 3 | 6HB004T0 | Register M 8 |
| 4 | IN DOTAZ | Barrel |
| 5 | 35701020 | Throttle Lever |
| 6 | 35401170 | Full lever |
| 7 | 3710106T | Corrugated washer |
| 8 | 3320103T | Self-locking nut M 6 h 78 |
| 10 | 6DT009T0 | Stop thread |
| 11 | 6FU006T0 | Spring |
| 12 | 6HB01000 | Register M 6x30 |
| 13 | 6HZ01200 | Toothed support |
| 14 | 5HR13900 | handlebar |
| 15 | 6HC025T0 | Washer |
| 16 | 6DG15000 | Clutch wire |
| 17 | 35851010 | terminal |
| 18 | 6DG20600 | Engine stop cable |
| 19 | 6HP07500 | Thickness |
| 20 | 6DG04300 | RM secure wire |
| 21 | 33801210 | Cable tie |
| 22 | 3970325T | Screw TCCI M 5x16 |
| 23 | 3290103T | Nut M 5 h5 |
| RL 328 GRUPPO MANUBRIO PER MOTORE KAMA KD 70 Pag.10 |
||
| 1 | 6HB011T O | Register M 6 |
| 2 | 3295104T | Register nut M 6 h4 |
| 3 | 2290103T | Nut M 5 h5 |
| 4 | 33801210 | Cable tie |
| 5 | 3970325T | screw M 5x16 |
| 6 | 35601060 | Knob |
| 7 | 3710106T | Corrugated washer Ø6 |
| 8 | 3320103T | Self-locking nut M 6 |
| 9 | IN DOTAZ | Barrel |
| 10 | 35701020 | Throttle Lever |
| 11 | 35401170 | LEVER ASSY |
| 12 | 6HP07500 | Thickness |
| 13 | 6HB004TO | Register M 8 |
| 14 | 6DG04300 | RM secure cable |
| 15 | 35851010 | terminal |
| 16 | 6DG20600 | Engine stop cable |
| 17 | 35401160 | Complete engine stop |
| 18 | 6DG15000 | Cable com clutch |
| 19 | 6HC025T0 | Special washer |
| 20 | 5HR139C0 | Handlebars |
| 21 | 6HZ01200 | Toothed support |
| RL 328 GRUPPO ATTACCO SPERONE Pag.11 |
||
| 1 | 3294107T | Nut M 6 h10 |
| 2 | 3730106T | Grower washer Ø10 |
| 3 | 3930400T | screw M 10x45 |
| 4 | 3931220T | screw M 6x12 |
| 5 | 3700104T | Beveled washer Ø6 |
| 6 | 3290104T | Nut M 6 |
| 7 | 6GQ062001 | Guard extension |
| 8 | 5HT33900 | Spur support |
| 9 | 5GQ033001 | Left Protection |
| 10 | 5GQ032001 | Right Protection |
| 11 | 6FU117T0 | Splint |
| 12 | 6HL011T0 | Towing pin |
| RL 328 GRUPPO SPERONE Pag.12 |
||
| 1 | 3931395T | screw M 10x45 |
| 2 | 3290107T | Nut M 10 |
| 3 | 5BT 05500 | Spur arm |
| 4 | 3320105T | Self-blocking dice |
| 5 | 6HO01400 | SPUR |
| 6 | 3931385T | TE M 10x35 screw |
| RL 328 GRUPPO FRESA Pag.13 |
||
| 1 | 39313800 | screw M 10x30 |
| 2 | 3730106T | Grower washer Ø10 |
| 3 | 32901070 | Nut M 10 |
| 5 | 5CU034001 | Side disk Ø240 |
| 6 | 5FV112001 | INNER blade holder hub |
| 7 | 5FV113001 | Blade holder hub 2nd p os |
| 8 | 5FV114001 | Blade holder hub 3rd p os |
| 9 | 6CM14200 | Left blade Ø320 |
| 10 | 6CM014300 | Right blade Ø320 |
| 11 | 5LF15100 | Pin L = 605 |
| 12 | 5LF15200 | Pin L = 855 |
| 13 | 5LF15300 | Pin L = 1105 |
| 14 | 6HC04500 | Washer |
| 15 | 3296103T | Nut M 12x15 |
| RL 328 GRUPPO COFANO MOTORI LOMBARDINI 15LD225 – 15LD315 Pag.14 |
||
| 1 | 5CH13400 | Engine COVER |
| 2 | 6GL00200 | Rubber fixing plate |
| 3 | 3970335T | Screw TC M 5x20 |
| 4 | 3320102T | Self-locking nut M 5 h68 |
| 5 | 6CR00100 | Rubber HINGE |
| 6 | 3971336T | TCBB M 5x20 screw |
| 7 | 5HT40100 | Hood support |
| 8 | 6CT 21900 | Threaded spacer h25 |
| 9 | 3931283T | Screw TE M 8x14 |
| 10 | 3710108T | Corrugated washer Ø8 |
| 11 | 3030115T | Antivibrante |
| 12 | 3322104T | Self-locking nut M 8 |
| RL 328 GRUPPO PARAURTI PER MOTORE LOMBARDINI 15LD225 Pag.15 |
||
| 1 | 5GG09100 | Bumper |
| 2 | 3290106T | Nut M 8 |
| 3 | 3701130T | WASHER 8-24 |
| 4 | 39313050 | screw M 8x35 |
| 5 | 3322104T | Self-locking nut M 8 h83 |
| 6 | 38101200 | BALL 19/32 |
| 7 | 3931300T | screw M 8x30 |
| 8 | 38201200 | Elastic PIN |
| 9 | 5BT 05800 | HOE-Tiller support arm |
| 10 | 6DG02000 | THROTTLE wire |
| 11 | 5GQ03700 | GUARD |
| 13 | 3930335T | TE M 8x50 screw |
| 14 | 6FU04600 | Spring |
| RL 328 GRUPPO PARAURTI PER MOTORE LOMBARDINI 15LD315 Pag.16 |
||
| 1 | 5GG09100 | Bumper |
| 2 | 3290106T | Nut M 8 |
| 3 | 3701130T | WASHER |
| 4 | 39313050 | screw M 8x35 |
| 5 | 3322104T | Self-locking nut M 8 h83 |
| 6 | 38101200 | BALL 19/32 |
| 7 | 3931300T | screw M 8x30 |
| 8 | 38201200 | Elastic PIN |
| 9 | 5BT 05800 | HOE-TILLER support arm p a |
| 10 | 6DG02000 | THROTTLE wire |
| 11 | 5GQ03400 | GUARD |
| 12 | 6HC05500 | Washer |
| 13 | 3930335T | TE M 8x50 screw |
| 14 | 6FU04600 | Spring |
| RL 328 GRUPPO PARAURTI PER MOTORI HONDA GX160 E SINOPOWER 168F Pag.17 |
||
| 1 | 3930325T | screw M 8x40 |
| 2 | 5GG095C0 | Bumper |
| 3 | 3700106T | washer 84x17 |
| 4 | 6DT011T0 | Wire guide |
| 5 | 3290106T | Hex nut M 8 |
| 6 | 6DG02000 | THROTTLE wire |
| RL 328 GRUPPO PARAURTI PER MOTORE LOMBARDINI LGA 226 Pag.18 |
||
| 1 | 5GG08500 | Bumper |
| 2 | 3730105T | grower Ø8 |
| 3 | 3931285T | screw M 8x16 |
| 4 | 6DG02800 | THROTTLE wire |
| 5 | 3930330T | screw M 8x45 |
| 6 | 6CT 237T0 | Spacer |
| RL 328 GRUPPO PARAURTI PER MOTORE KAMA KD 70 pag.19 |
||
| 1 | 5GG094C0 | Bumper |
| 2 | 3290106T | Nut M 8 |
| 3 | 3701130T | WASHER Ø8-24 |
| 4 | 3930325T | screw M 8x24 |
| 5 | 3322104T | Self-locking nut M 8 |
| 6 | 38101200 | BALL Ø19 / 32 |
| 7 | 6FU046T0 | Spring |
| 8 | 3931300T | screw M 8x30 |
| 9 | 38201200 | Elastic PIN |
| 10 | 5BT058C0 | Tiller support arm |
| 11 | 6DG02000 | THROTTLE wire |
| 12 | 3931290T | screw M 8x20 |
| 13 | 3950295T | screw M 8x16 |
| 14 | 6HQ049C0 | Muffler fixing bracket |
| 15 | 6DS19500 | Motor flange gasket |
| 16 | 6DI11200 | Flange acc Engine |
| 17 | 3730105T | Grower washer Øi85 |
| 18 | 3940370T | Screw TCEI M 5x25 |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Alpina websites, which we consider as reliable Unfortunately, even the official documents may contain mistakes and printing errors we are not able to confirm that all of these data are precise and represent the facts Most of the manufacturers reserve the right to change the product characteristics or complement without notice We strongly recommend using the published information as a basic information subject to Alpina brand review Please refine the important parameters by the selling assistant when making a purchase All content included in this catalog is the intellectual property of wwwbricoutensilicom Any publication or copying (full or partial) without a reference to the source page is prohibited
Meccanica Benassi RL 328 Special
12 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10/15 BUSINESS DAYS APPROX.
- MORE INFO:
- info@bricoutensili.com
New
You might also like
Comments (0)
No customer reviews for the moment.
Viewed products
Customers who bought this product also bought:
16 other products in the same category:
Meccanica Benassi Spare Parts for Hoe-Tiller RL 328 Special
Meccanica Benassi Genuine spare parts or replacement parts for to repair Hoe-Tiller RL 328 Special.Fix Your Hoe-Tiller RL 328 Special. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
