Meccanica Benassi Spare Parts for Tiller RL 113
€5.24
Tax included
Meccanica Benassi Spare Parts for Tiller RL 113
Meccanica Benassu original replacement parts for to replace broken parts for to fix Rotary Tiller RL 113.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Meccanica Benassi Spare Parts for Tiller RL 113
Meccanica Benassu original replacement parts for to replace broken parts for to fix Petrol Rotary Tiller RL 113.In the following table, look for the model of the Tiller and the respective parts of the code.
| Rotary Tiller Meccanica Benassi RL 113 - Pag.1 | ||
| Pos. | Codice / code | Description |
| 1 | SI0600033 | Handle assembly |
| 2 | SI0200077 | Spring lever |
| 3 | SI0200076 | Threaded bush |
| 4 | SI0200075 | Saddle washer |
| 5 | SI0200074 | Toothed plate |
| 6 | SI0600050 | Girder |
| 7 | SI0200062 | Axle pin |
| 8 | SI0200067 | Screw M10x50 |
| 9 | SI0200068 | Nut M10 |
| 10 | SI0200061 | Drag strut |
| 11 | SI0200070 | Nut M10 |
| 12 | SI0200069 | Screw M10x40 |
| 13 | SI0200060 | Spur arm |
| 14 | SI0600067 | Flat washer Ø12 |
| 15 | SI0200063 | Cotter pin |
| 16 | SI0600065 | Screw M12x65 |
| 17 | SI0150211 | Nut M8 |
| 18 | SI0149011 | Flat washer Ø8 |
| 19 | SI0600002 | Gearbox assembly |
| 20 | SI0600060 | Bush |
| 21 | SI0200065 | Screw M8x45 |
| 22 | SI0600058 | Left support of blade cover |
| 23 | SI0600059 | Right support of blade cover |
| 24 | SI0210023 | Nut M12 |
| 25 | SI0210022 | Spring washer Ø12 |
| 26 | SI0152311 | Nut M8 |
| 27 | SI0149710 | Spring washer Ø8 |
| 28 | SI0600061 | Blade cover |
| 29 | SI0155310 | Screw M8x20 |
| 30 | SI0600062 | Front wheel support |
| 31 | SI0610055 | Left hold hoop |
| 32 | SI0600056 | Right hold hoop |
| 33 | SI0148910 | Screw M8x70 |
| 34 | SI0300029 | Nut M8 |
| 35 | SI0600049 | Wheel assembly |
| 36 | SI0210030 | Spring |
| 37 | SI0600064 | Screw |
| 38 | SI0600066 | Screw M10x1x25 |
| 39 | SI0210026 | Spring washer Ø10 |
| 40 | SI0600051 | Big washer |
| 41 | SI0600052 | Bush |
| 42 | SI0600045 | Friction disk assembly |
| 43 | SI0154610 | Screw M8x50 |
| 44 | SI0600068 | Key A4x5x20 |
| 45 | SI0600053 | Engine support flange |
| 46 | SI0600054 | Engine support bush |
| 47 | SI0156106 | Wheel support |
| 48 | SI0156311 | Bush |
| 49 | SI0210028 | Wheel |
| 50 | SI0156410 | Screw M8x75 |
| Rotary Tiller Meccanica Benassi RL 113 - Pag.2 | ||
| Pos. | Codice / code | Description |
| 1 | SI0200073 | Handle |
| 2 | SI0147006 | Handle grip |
| 3 | SI0600069 | Throttle lever |
| 4 | SI0600070 | Screw M6x45 |
| 5 | SI0200901 | Clutch lever |
| 6 | SI0600026 | Clutch wire |
| 7 | SI0600036 | Throttle wire |
| 8 | SI0062010 | Flat washer Ø6 |
| 9 | SI0147811 | Nut M6 |
| 10 | SI0148706 | Wire connector |
| 11 | SI0161810 | Screw M5x20 |
| 12 | SI0038311 | Nut M5 |
| Rotary Tiller Meccanica Benassi RL 113 - Pag.3 | ||
| Pos. | Codice / code | Description |
| 1 | SI0600018 | Seeger E18 |
| 2 | SI0600019 | Washer |
| 3 | SI0600029 | Friction disc |
| 4 | SI0600028 | Bearing 6006-2RS |
| 5 | SI0600027 | Upper disc |
| 6 | SI0600025 | Big washer |
| 7 | SI0400126 | Seeger E30 |
| 8 | SI0600024 | Steel ball Ø13 |
| 9 | SI0600023 | Screw M8x20 |
| 10 | SI0600022 | Lower disc |
| 11 | SI0600021 | Bush |
| 12 | SI0600017 | Oil seal 40x25x7 |
| 13 | SI0600015 | Locating pin |
| 14 | SI0600032 | Rubber plug |
| 15 | SI0600016 | Bearing 6005-2Z |
| 16 | SI0600007 | Left gearbox |
| 17 | SI0600012 | Locating sleeve |
| 18 | SI0300029 | Nut M8 |
| 19 | SI0600013 | Gasket |
| 20 | SI0600005 | Dust prevention cover |
| 21 | SI0600006 | Oil seal 47x25x10 |
| 22 | SI0600008 | Washer |
| 23 | SI0600010 | Bearing 30204 |
| 24 | SI0600011 | Wormwheel |
| 25 | SI0600075 | Shaft spring collar Ø28 |
| 26 | SI0600009 | Bearing 6205-2Z |
| 27 | SI0600073 | Output shaft |
| 28 | SI0600074 | Key A6x20 |
| 29 | SI0600020 | Wormscrew |
| 30 | SI0600014 | Right gearbox |
| 31 | SI0600004 | Screw M8x30 |
| 32 | SI0600003 | Screw M8x18 |
| 33 | SI0600030 | Screw M4x15 |
| 34 | SI0052306 | Flat washer Ø4 |
| 35 | SI0600031 | Spring |
| 36 | SI0200036 | Rubber plate |
| 37 | SI0200035 | Bolt |
| Rotary Tiller Meccanica Benassi RL 113 - Pag.4 | ||
| Pos. | Codice / code | Description |
| 1 | SI0600042 | Disc |
| 2 | SI0600071 | Axle pin |
| 3 | SI0150410 | Screw M8x25 |
| 4 | SI0149710 | Spring washer Ø8 |
| 5 | SI0152311 | M8 nut |
| 6 | SI0600040 | Blade L |
| 7 | SI0600041 | Blade R |
| 8 | SI0600039 | Blade support II |
| 9 | SI0600038 | Blade support I |
