Maruyama Pruner PP2430 Parts
€45.78
Tax included
Maruyama Parts for Pruner PP2430
Maruyama Genuine spare parts or replacement parts for to repair Pruner PP2430.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Maruyama Parts for Pruner PP2430
Maruyama Genuine spare parts or replacement parts for to repair Pruner PP2430.
In the following tables, look for the spare part and its respective code.
| Maruyama Pruner PP2430 Parts | ||
| Main Body Pag.1 | ||
| # | Part Num. | Description |
| 1-1 | 364669 | PP2430 |
| 1-2 | 221473 | Clutch Case Ass'y |
| 1-3 | 221474 | Clutch Case |
| 1-4 | 016405 | Bearing |
| 1-5 | 013825 | Snap Ring |
| 1-6 | 261612 | Cap Screw |
| 1-7 | 219435 | Driveshaft Tube |
| 1-8 | 226399 | Driveshaft Ass'y |
| 1-9 | 229091 | Clutch Drum |
| 1-10 | 235078 | Throttle Trigger |
| 1-11 | 215533 | Hanging Bracket Ass'y |
| 1-12 | 261762 | Cap Screw |
| 1-13 | 238190 | Grip |
| 1-14 | 239431 | Label |
| 1-15 | 238749 | Label |
| 1-16 | 225384 | Label |
| 1-17 | 261250 | Cap Screw |
| 1-18 | 220533 | Hanging Strap Ass'y |
| 1-19 | 231657 | Hook |
| Head Pruner Pag.2 | ||
| 2-1 | 234082 | Pruner Head Ass'y |
| 2-2 | 231855 | Gearcase A |
| 2-3 | 227990 | Bearing |
| 2-4 | 231856 | Gear Shaft |
| 2-5 | 231857 | Gear |
| 2-6 | 231858 | Worm Wheel |
| 2-7 | 231859 | Pinion Shaft |
| 2-8 | 227992 | Bearing |
| 2-9 | 227993 | Bearing |
| 2-10 | 228477 | Snap Ring |
| 2-11 | 140270 | Snap Ring |
| 2-12 | 231860 | Oil Pump |
| 2-13 | 231861 | Seal |
| 2-14 | 231862 | Screw |
| 2-15 | 231863 | Pipe, Oil |
| 2-16 | 231864 | Strainer |
| 2-17 | 234084 | Gearcase B |
| 2-18 | 227991 | Bearing |
| 2-19 | 231866 | Sprocket |
| 2-20 | 231867 | Washer |
| 2-21 | 231868 | Bolt |
| 2-22 | 125588 | Bolt |
| 2-23 | 234085 | Screw |
| 2-24 | 231870 | Adjuster |
| 2-25 | 231871 | Bolt |
| 2-26 | 234086 | Oil Tank Ass'y |
| 2-27 | 231873 | Breather |
| 2-28 | 231874 | Tank Cap Ass'y |
| 2-29 | 092580 | Bolt |
| 2-30 | 231875 | Chain Cover Comp |
| 2-31 | 126756 | Nut |
| 2-32 | 089819 | Bolt |
| 2-33 | 261246 | Cap Screw |
| 2-34 | 215993 | Cap Screw |
| 2-35 | 234087 | Chain Cover |
| 2-36 | 234088 | Guide Bar |
| 2-37 | 289536 | Chain |
| Engine Pag.3 | ||
| 3-1 | 875037 | Engine |
| 3-2 | 289639 | Cylinder |
| 3-3 | 289643 | Gasket |
| 3-4 | 267290 | Cap Screw |
| 3-5 | 272744 | Insulator |
| 3-6 | 267049 | Gasket |
| 3-7 | 269826 | Screw |
| 3-8 | 278096 | Muffler Comp |
| 3-9 | 266402 | Cap Screw |
| 3-10 | 273262 | Gasket |
| 3-11 | 276868 | Under Cover |
| 3-12 | 269827 | Screw |
| 3-13 | 277673 | Top Cover |
| 3-14 | 280144 | Tapping Screw |
| 3-15 | 273674 | Crankcase |
| 3-16 | 280488 | Bearing |
| 3-17 | 261492 | Oil Seal |
| 3-18 | 261386 | Oil Seal |
| 3-19 | 055185 | Snap Ring |
| 3-20 | 261612 | Cap Screw |
| 3-21 | 272204 | Piston |
| 3-22 | 264891 | Piston Ring |
| 3-23 | 261036 | Piston Pin |
| 3-24 | 288520 | Bearing, Needle |
| 3-25 | 261576 | Clip,Piston |
| 3-26 | 267193 | Crankshaft/Conn.Rod Ass'y |
| 3-27 | 269168 | Clutch Ass'y |
| 3-28 | 269169 | Clutch Shoe |
| 3-29 | 269173 | Spring, Clutch |
| 3-30 | 269647 | Clutch Bolt |
| 3-31 | 269175 | Washer |
| 3-32 | 261777 | Wave Washer |
| 3-33 | 283386 | Fan Cover |
| 3-34 | 269831 | Screw |
| 3-35 | 272066 | Magneto Ass'y |
| 3-36 | 261356 | Rotor/Fan |
| 3-37 | 272067 | Ignition Coil Ass'y |
| 3-38 | 267401 | Coil |
| 3-39 | 272068 | Spark Plug Wire Ass'y |
| 3-40 | 272069 | Spark Plug Wire |
| 3-41 | 261074 | Plug Boot |
| 3-42 | 261075 | Connector |
| 3-43 | 261076 | Woodruff Key |
| 3-44 | 261417 | Nut,Rotor |
| 3-45 | 280381 | Spacer |
| 3-46 | 261256 | Cap Screw |
| 3-47 | 288264 | Spark Plug |
| 3-48 | 267492 | Lead |
| 3-49 | 282880 | Wire, Lead |
| 3-50 | 282404 | Recoil Starter Ass'y |
| 3-51 | 282405 | Recoil Ass'y |
| 3-52 | 283411 | Reel |
| 3-53 | 283412 | Cam Plate |
| 3-54 | 280930 | Spring |
| 3-55 | 280931 | Spiral Spring |
| 3-56 | 267213 | Screw |
| 3-57 | 280932 | Starter Rope Ass'y |
| 3-58 | 280933 | Starter Rope |
| 3-59 | 267219 | Starter Grip |
| 3-60 | 280934 | Starter Pawl Ass'y |
| 3-61 | 280489 | Screw |
| 3-62 | 269833 | Screw |
| 3-63 | 278100 | Label |
| 3-64 | 284587 | Label |
| Carburator - Fuel Tank Pag. 4 | ||
| 4-1 | 276663 | Carburetor -incl2-15 new gasket required |
| 4-2 | 274472 | Pump Body |
| 4-3 | 262991 | Purge Body |
| 4-4 | 262992 | Cover Plate |
| 4-5 | 261874 | Primer Bulb |
| 4-6 | 283905 | Diaphragm, Meterring |
| 4-7 | 262993 | Gasket |
| 4-8 | 262994 | Diaphragm,Fuel Pump |
| 4-9 | 282576 | Gasket |
| 4-10 | 289396 | Main Jet |
| 4-11 | 261871 | O-Ring |
| 4-12 | 261876 | E-Ring |
| 4-13 | 261658 | Swivel |
| 4-14 | 264682 | Screw |
| 4-15 | 262996 | Screw |
| 4-16 | 261864 | Gasket |
| 4-17 | 264691 | O-Ring |
| 4-18 | 266420 | Cleaner Ass'y |
| 4-19 | 264709 | Cover |
| 4-20 | 266433 | Housing |
| 4-21 | 264695 | Filter |
| 4-22 | 269834 | Screw |
| 4-23 | 276798 | Fuel Tank Ass'y |
| 4-24 | 273516 | Fuel Tank |
| 4-25 | 275306 | Fuel Tank Cap Ass'y |
| 4-26 | 274875 | Gasket |
| 4-27 | 261696 | Breather Ass'y |
| 4-28 | 265752 | Fuel Pipe Pick-up Ass'y |
| 4-29 | 264031 | Fuel Pipe Ass'y |
| 4-30 | 261115 | Grommet |
| 4-31 | 261690 | Fuel Pipe |
| 4-32 | 263038 | Return Pipe |
| 4-33 | 264653 | Filter Ass'y |
| 4-34 | 261117 | Clip |
| 4-35 | 261117 | Clip |
| 4-36 | 269828 | Screw |
| 4-37 | 281208 | Screw |
| Accessories Pag.5 | ||
| 5-1 | 219968 | Box Spanner |
| 5-2 | 219432 | Wrench |
| 5-3 | 234954 | Colgate Tube |
| 5-4 | 234955 | Band |
| 5-5 | 239435 | Instruction Manual |
| 5-6 | 239436 | Instruction Manual |
| 5-7 | 239437 | Instruction Manual |
| 5-8 | 239438 | Instruction Manual |
| 5-9 | 524387 | Parts List |
