Makita Spare Parts for Drill Hammer HR5001C
€182.66
Tax included
Makita Spare Parts for Rotary Hammer HR5001C
Makita original spare parts for to replace broken parts for to fix Rotary Hammer HR5001C.Fix Your Rotary Hammer HR5001C. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Makita Spare Parts for Rotary Hammer HR5001C
Fix Your Rotary Hammer HR5001C. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following table, look for the model of Hammer and the respective parts of the code.
| Rotary Hammer HR5001C | ||
| # | Part Num. | Description |
| 1 | 286250-3 | TOOL HOLDER CAP HR5001C |
| 2 | 416568-0 | CHUCK COVER HR5001C |
| 3 | 150836-8 | RANK HOUSING COVER COMPLETE HR5001C |
| 4 | 233217-2 | COMPRESSION SPRING HR5001C |
| 5 | 231984-3 | O-RING X HR50001C |
| 6 | 961232-3 | RETAINING RING |
| 7 | 267735-8 | WASHER X HR5001C |
| 8 | 232180-6 | RING X HR5001C |
| 9 | 323767-6 | PIN X HR5001C |
| 10 | 323773-1 | CHUCK HOLDER X HR5001C |
| 11 | 233218-0 | COMPRESSION SPRING HR5001C |
| 12 | 323772-3 | TOOL HOLDER HR5001C |
| 13 | 256265-4 | PIN X HR5001C |
| 14 | 416572-9 | SLEEVE X HR5001C |
| 15 | 233216-4 | COMPRESSION SPRING HR5001C |
| 16 | 416573-7 | LOCK SLEEVE B X HR5001C |
| 17 | 267180-7 | WASHER X HR5001C |
| 18 | 262543-2 | RING X HR5001C |
| 19 | 267180-7 | WASHER X HR5001C |
| 20 | 211751-2 | BEARING X HR5001C |
| 21 | 962351-8 | RETAINING RING |
| 22 | 961234-9 | RETAINING RING HR5001C |
| 23 | 213618-0 | OIL SEAL 48 X HR5001C |
| 24 | 213715-2 | O-RING 67 HR5001C |
| 25 | 416565-6 | SEAL CASE X HR5001C |
| 26 | 323768-4 | IMPACT BOLT HR5001C |
| 27 | 213394-6 | RUBBER RING X HR5001C |
| 28 | 213394-6 | RUBBER RING X HR5001C |
| 29 | 213522-3 | O-RING 36 HR5001C |
| 30 | 323771-5 | TOOL HOLDER A X HR5001C |
| 31 | 322908-1 | KEY 8 X HM1100C |
| 32 | 267734-0 | WASHER X HR5001C |
| 33 | 213431-6 | O-RING 23 HR5001C |
| 34 | 213431-6 | O-RING 23 HR5001C |
| 35 | 323817-7 | O-RING X HR5001C |
| 36 | 421623-5 | RUBBER RING X HR5001C |
| 37 | 331530-3 | COLLAR SLEEVE 22 X HR5001C |
| 38 | 416566-4 | SLIDE SLEEVE X HR5001C |
| 39 | 331531-1 | RING 45 X HR2400 |
| 40 | 233215-6 | COMPRESSION SPRING 45 X HR5001C |
| 41 | 267736-6 | WASHER |
| 42 | 323769-2 | STRIKER X HR5001C |
| 43 | 213482-9 | O-RING 34 HR5001C |
| 44 | 231985-1 | RING SPRING 43 X HR5001C |
| 45 | 331534-5 | CYLINDER 40 HR5001C |
| 46 | 256295-5 | PIN X HR5001C |
| 47 | 213510-0 | O-RING 36 HR2010 |
| 48 | 213482-9 | O-RING 34 HR5001C |
| 49 | 416563-0 | PISTON HR5001C |
| 50 | 213460-9 | O-RING 35 HK / HR1800 / HM12 |
| 51 | 416564-8 | ROD HR5001C |
| 52 | 226761-6 | SPIRAL BEVEL GEAR 41 HR5001C |
| 53 | 922361-7 | SCREW M6x40 X HM1303 |
| 54 | 416561-4 | CRANK CAP X HR5001C |
| 55 | 213510-0 | O-RING 36 HR2010 |
| 56 | 150831-8 | CRANK HOUSING COMPLETE HR5001C |
| 57 | 323774-9 | CRANKSHAFT X HR5001C |
| 58 | 267181-5 | WASHER X HR5001C |
| 59 | 254229-2 | KEY 5 X HR4000C |
| 60 | 211470-0 | NEEDLE ROLLER BEARING |
| 61 | 254202-2 | KEY 4 |
| 62 | 962303-9 | RETAINING RING |
| 63 | 226493-5 | HELICAL GEAR 50 X HR5001C |
| 64 | 226490-1 | GEAR X HR5001C |
| 65 | 961054-1 | RETAINING RING S14 |
| 66 | 961052-5 | RETAINING RING S12 |
| 67 | 253744-3 | HARD WASHER 12 24B / 12N / 14 |
| 68 | 150835-0 | GEAR X HR5001C |
| 69 | 253744-3 | HARD WASHER 12 24B / 12N / 14 |
| 70 | 421622-7 | SEAL RING HR5001C |
| 71 | 150832-6 | GEAR HOUSING COMPLETE HR5001C |
| 72 | 211129-9 | BALL BEARING NSK 6201DD |
| 73 | 213160-1 | OIL SEAL 14 XHR3850 / B |
| 74 | 922351-0 | SCREW M6 X 30 X HM1100C |
| 75 | 911223-4 | PAN HD HEAD SCREW M5X16 |
| 76 | 256286-6 | PIN X HR5001C |
| 77 | 210024-0 | BEARING X HR5001C |
| 78 | 322951-0 | CHANGE KEY X HR4000C |
| 79 | 253314-8 | WASHER 15 X6906 / HR3850B |
| 80 | 416571-1 | CHANGE LINK HR5001C |
| 81 | 253810-6 | WASHER 12 X HR4000C |
| 82 | 256263-8 | PIN X HR5001C |
| 83 | 322963-3 | GUIDE PIN 2 X HR4000C |
| 84 | 233180-9 | COMPRESSION SPRING 3 X HR4000C |
| 85 | 416289-4 | SLIDE PLATE X HR4000C |
| 86 | 961052-5 | RETAINING RING S12 |
| 87 | 267113-2 | FLAT WASHER 12 X 8412DWH |
| 88 | 150986-9 | CLUTCH ASS'Y HR5001C |
| 89 | 267113-2 | FLAT WASHER 12 X 8412DWH |
| 90 | 211109-5 | BEARING 6201 X HM1303 |
| 91 | 226760-8 | SPIRAL BEVEL GEAR HR5001C |
| 92 | 256122-6 | PIN 4 X HR4000C |
| 93 | 323973-3 | PIN 4 X HR5001C |
| 94 | 213304-3 | O-RING 20 X 6904VH |
| 95 | 416287-8 | CHANGE LEVER X HR4000C |
| 97 | 233188-3 | SPRING 2.4 X HR4000C |
| 98 | 417340-3 | LOCK BUTTON X HR400 |
| 99 | 417167-1 | COVER HANDLE HR5001C |
| 100 | 265995-6 | SCREW M4X18 X 6408 / 6221DW |
| 101 | 265995-6 | SCREW M4X18 X 6408 / 6221DW |
| 102 | 687063-9 | BOOT X 4304T |
| 103 | 922351-0 | SCREW M6 X 30 X HM1100C |
| 104 | 416126-2 | GUIDE X HR4000C |
| 105 | 421583-1 | SPONGE SHEET X HR4000C |
| 106 | 650677-7 | SWITCH C3PA-1112 |
| 107 | 416284-4 | SWITCH LEVER X HR4000C |
| 108 | 417166-3 | GRIP X HR5001C |
| 109 | 682560-0 | CABLE SLEEVE X HM1202C / 9079S |
| 111 | 416285-2 | ACRYLIC PIN 5 X HR4000C |
| 112 | 265995-6 | SCREW M4X18 X 6408 / 6221DW |
| 113 | 416562-2 | FIX ROD HR5001C |
| 114 | 240016-5 | FAN X HR5001C |
| 115 | 253165-9 | FLAT WASHER 8 |
| 116 | 931402-8 | NUT M8 X LS1013 |
| 117 | 416570-3 | COVER X HR5001C |
| 118 | 266021-4 | 5X20 SCREW |
| 119 | 265995-6 | SCREW M4X18 X 6408 / 6221DW |
| 120 | 416292-5 | PLATE X HR4000C |
| 121 | 263002-9 | RUBBER PIN 4 |
| 122 | 643650-4 | BRUSH HOLDER CAP |
| 123 | 181048-2 | CARBON BRUSHE SET CB-155 (CB-161) |
| 125 | 911223-4 | HEAD SCREW CILIND. M5X16 |
| 126 | 416575-3 | GEAR HOUSING COVER HR5001C |
| 127 | 266095-5 | SCREW 5 X 55 HR5001C |
| 128 | 416569-8 | BAFFLE PLATE X HR5001C |
| 129 | 516778-0 | ARMATURE HR5001C |
| 130 | 626078-1 | STATOR 220 X HR5001C |
| 131 | 416567-2 | DUST GUIDE X HR5001C |
| 132 | 681642-5 | WASHER X LS1013 |
| 133 | 211088-7 | BEARING 6000-9527PB 9528PB |
| 134 | 150833-4 | MOTOR HOUSING CPL X HR5001C |
| 135 | 631273-0 | CONTROLLER X HR5001C |
| 136 | 265439-6 | SCREW M8X150 X HM1100C |
| 137 | 417003-1 | SIDE HANDLE X HM1202C |
| 138 | 252640-2 | HANDLE KNOB M8 |
| 139 | 151549-4 | GRIP HOLDER X HR5001C |
| 140 | 417002-3 | SIDE HANDLE CAM HM1202C |
| 141 | 654019-7 | RING TERMINAL 84 |
| 999 | 193392-5 | SERVICE KIT HR5001C |
