Makita Angle Grinder 9029 Parts
€8.75
Tax included
Makita Spare Parts for Angle Grinder 9029
Best Offers on Makita Original Spare Parts and Accessories for Repair your Angle Grinder 9029 can be found only on this page.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Makita Spare Parts for Angle Grinder 9029
Best Offers on Makita Original Spare Parts and Accessories for Repair your Angle Grinder 9029 can be found only on this page.
Open PDF File in this page to check Spare Parts Makita 9016B.
| MAKITA 9029 Disc Grinder 230 mm | ||
| # | Part Num | Description |
| 1 | 211087-9 | BALL BEARING 6200DDW |
| 2 | 681630-2 | INSULATION WASHER |
| 3C1 | 636003-4 | FIELD 220V |
| 3C2 | 526013-8 | FIELD ASS'Y 220V X |
| C10 | 654098-5 | RECEPTACLE |
| 4 | 414989-0 | BAFFLE PLATE |
| 4-1 | 415647-1 | BAFFLE PLATE S |
| 5C2 | B33704 | ARMATURE ASS'Y 220V |
| 5C3 | 516593-2 | ARMATURE ASS'Y 220V O |
| D10 | INC. 1,2,6 | |
| 5C4 | 516658-0 | ARMATURE ASS'Y 220V X |
| D10 | INC. 1,2,6 | |
| 5C5 | 516593-2 | ARMATURE ASS'Y 220V O |
| D10 | INC. 1,2,6 | |
| 6 | 241859-8 | FAN 80 |
| 7 | 285672-4 | BEARING RETAINER 57 |
| 8 | 211132-0 | BALL BEARING 6301DDW |
| 9 | 221398-4 | SPIRAL BEVEL GEAR 12 |
| 10 | 961005-4 | RETAINING RING S-9 |
| 11 | 911263-2 | PAN HEAD SCREW M5X40 |
| 12 | 421421-7 | TOOL REST |
| 13 | 414990-5 | PIN CAP |
| 14 | 233031-6 | COMPRESSION SPRING 12 |
| 15 | 265977-8 | HEX.SOCKET HEAD BOLT M5X20 |
| 15-1 | 266464-0 | HEX. SOCKET HEAD BOLT M5X20 O |
| 16 | 256431-3 | PIN 6 |
| 17-1 | 152492-0 | GRIP 36 COMPLETE |
| 18 | 265976-0 | HEX.SOCKET HEAD BOLT M5X10 |
| 19 | 961057-5 | RETAINING RING S-17 |
| 20 | 221378-0 | SPIRAL BEVEL GEAR 50 |
| 21 | 962157-4 | RETAINING RING R-40 |
| 22 | 211278-2 | BALL BEARING 6203DDW |
| 23 | 316399-6 | BEARING BOX |
| 24A_ | 322512-6 | SPINDLE |
| 25 | 251383-3 | PAN HEAD SCREW M8X30 |
| 26 | 165000-8 | WHEEL COVER |
| 27B1 | 224298-7 | INNER FLANGE 42 |
| 27B2 | 224415-9 | INNER FLANGE 42 < |
| 28A_ | 224543-0 | LOCK NUT 14-45 |
| 28A1 | 192567-3 | LOCK NUT DIN |
| 29 | 254001-2 | WOODRUFF KEY 4 |
| 30 | 911223-4 | PAN HEAD SCREW M5X16 |
| 31 | 159469-6 | GEAR HOUSING |
| C10 | 212063-6 | NEEDLE BEARING 1012 |
| 32-2 | 125029-6 | MOTOR HOUSING ASS'Y |
| C10 | 643705-5 | BRUSH HOLDER |
| C20 | 632282-2 | SUPPORT UNIT |
| D10 | INC. 34,49 | |
| 32-3 | 125036-9 | MOTOR HOUSING ASS'Y S |
| C10 | 643705-5 | BRUSH HOLDER |
| C20 | 632282-2 | SUPPORT UNIT |
| D10 | INC. 34,39 | |
| 32-4 | 125036-9 | MOTOR HOUSING ASS'Y X |
| C10 | 643705-5 | BRUSH HOLDER |
| C20 | 632282-2 | SUPPORT UNIT |
| D11 | INC. 34,49 | |
| 32-5 | 182815-8 | MOTOR HOUSING X |
| C10 | 643705-5 | BRUSH HOLDER |
| C11 | 643707-1 | BRUSH HOLDER O |
| D11 | INC. 49 | |
| 33 | 856985-6 | NAME PLATE 9029 |
| 34 | 687010-0 | BAND |
| 35-1 | 911691-1 | PAN HEAD SCREW M5X70 |
| 36-1 | 182563-9 | HANDLE SET |
| D10 | INC. 45 | |
| 36-2 | 182607-5 | HANDLE SET S |
| D10 | INC. 45 | |
| 36-3 | 182824-7 | HANDLE SET S |
| D10 | INC. 45 | |
| 37-1 | 265016-4 | PAN HEAD SCREW M6X85 |
| 38 | 911148-2 | PAN HEAD SCREW M4X25 |
| 38-1 | 265999-8 | TAPPING SCREW 4X25 X |
| 39O_ | 666066-6 | POWER SUPPLY CORD 1.0-2-2.5 |
| 40A_ | 682503-2 | CORD GUARD 8-90 |
| 42C_ | 687063-9 | CORD CLAMP |
| 43A_ | 266121-0 | TAPPING SCREW FLANGE PF 4X18 |
| 43A1 | 265995-6 | TAPPING SCREW 4X18 O |
| 44 | 651146-1 | SWITCH 1267.5102 |
| 44-1 | 650100-2 | SWITCH TG08-1300-011 O |
| 45-1 | 182563-9 | HANDLE SET |
| D10 | INC. 36 | |
| 45-2 | 182607-5 | HANDLE SET S |
| D10 | INC. 36 | |
| 45-3 | 182824-7 | HANDLE SET S |
| D10 | INC. 36 | |
| 46 | 645214-0 | NOISE SUPPRESSOR |
| 46-1 | 645088-9 | NOISE SUPPRESSOR O |
| 47-1 | 191957-7 | A.C. CARBON BRUSH CB-204 |
| 47-2 | 194992-4 | CARBON BRUSH SET CB-204 O |
| 48 | 643700-5 | BRUSH HOLDER CAP 7-18 |
| 49-1 | 819095-0 | MAKITA MARK |
| 50 | 818160-2 | INDICATION LABEL |
| A01A_ | 782407-9 | LOCK NUT WRENCH 35 |
| A02 | 818161-0 | INDICATION LABEL |
| B04 | 134769-5 | MOTOR HOUSING ASS'Y 220V |
| D10 | INC. 3,32,34,E08-E10 | |
| B06 | 182942-1 | SPIRAL BEVEL GEAR SET |
| D10 | INC. 9,20 | |
| E12 | 125052-1 | LOCK NUT ASS'Y DIN 1 |
| F02 | 192227-7 | SUPER FLANGE |
