Makita Spare Parts for Demolition Hammer HM1304B

We have the original Spares MAKITA for Demolition Hammer HM1304B the diagram, parts list and tool repair that help you need to get your tools running like new again.

Fix Your Demolition Hammer HM1304B. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.

CODICE ARTICOLO: 322478-0

322478-0
266010-9
233083-7
322560-5
262098-7
213388-1
324166-5
262099-5
213721-7
421975-4
324165-7
324738-6
213443-9
267232-4
317448-2
213617-2
317447-4
268066-8
213572-8
267233-2
261121-5
331600-8
324102-1
317444-0
941252-3
266276-1
273518-6
252005-8
266298-1
416228-4
345279-9
252633-9
253194-2
922221-3
257196-0
211373-8
316730-6
265366-7
254001-2
324100-5
212261-2
253196-8
922326-9
213720-9
213510-0
416561-4
911221-8
345278-1
262003-4
643700-5
191957-7
922227-1
345319-3
922371-4
941151-9
153438-9
213406-5
414665-6
643711-0
183557-7
317623-0
626124-0
265428-1
253794-8
211087-9
681635-2
516864-7
241870-0
211228-7
418000-0
266310-7
317446-6
211214-8
226450-3
421780-9
317445-8
256111-1
421779-4
265995-6
183546-2
941152-7
331212-7
211104-5
226449-8
211109-5
645105-5
685725-3
415805-9
417544-7
415806-7
651922-3
650677-7
421778-6
231457-6
682560-0
687052-4
922361-7
256219-1
322477-2
322550-8
951272-9
824826-4
163467-4
195201-4
181490-7
197148-8
197168-2

Quantity

Usually Ships in: 7/10 Business Days Approx.

Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Description
Product Details
Attachments

Makita Spare Parts for Demolition Hammer HM1304B

Fix Your Demolition Hammer HM1304B. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.

In the following table, look for the model of Hammer and the respective parts of the code.

HM1304B DEMOLITION HAMMER
#	Part Num	Description
1	324345-5	TOOL HOLDER
2	322478-0	TOOL RETAINER
3	266010-9	HEX. SOCKET HEAD BOLT M8X30
4	233083-7	COMPRESSION SPRING 12
5	322560-5	RETAINER RING
6	262098-7	URETHAN RING 48
7	213388-1	O RING 24
8	324346-3	TOOL GUIDE
9	324166-5	IDLER
10	262099-5	RUBBER RING 52
11	324347-1	IMPACT BOLT
12	213721-7	O RING 61
12-1	421975-4	SEAL RING
13	213721-7	O RING 61
14	324165-7	SEAL HOLDER
14-1	324738-6	SEAL HOLDER
15	213443-9	X-RING 30
16	262098-7	URETHAN RING 48
17	267232-4	FLAT WASHER 48
18	317448-2	CONNECTING ROD
19	213617-2	O RING 47
20	317447-4	PISTON
21	268066-8	PIN 12
22	213572-8	O-RING 44
23	267233-2	FLAT WASHER 55
24	261121-5	NYLON WASHER 55
25	331600-8	CYLINDER LINER 54
26	213572-8	O-RING 44
27	324102-1	STRIKER
28	317444-0	BARREL
29	941252-3	FLAT WASHER 10
30	266276-1	HEX.SOCKET HEAD BOLT M10X4 0
31	273518-6	GRIP 37
32	252005-8	HEX. NUT M8-13
33	266298-1	SET BOLT M10X122
34	416228-4	HANDLE BASE
35	345279-9	SIDE HANDLE
36	416228-4	HANDLE BASE
37	252633-9	WING NUT M10
38	253194-2	FLAT WASHER 5
39	922221-3	HEX. SOCKET HEAD BOLT M5X16
40	252005-8	HEX. NUT M8-13
41	257196-0	RING 25
42	211373-8	BALL BEARING 6205LLU
43	316730-6	BEARING BOX
44	265366-7	HEX. SOCKET HEAD BOLT M6X22
45	254001-2	WOODRUFF KEY 4
46	324100-5	CRANK SHAFT
47	212261-2	NEEDLE BEARING 1715
48	253196-8	FLAT WASHER 6
49	922326-9	HEX. SOCKET HEAD BOLT M6X18
50	213720-9	O RING 67
51	819084-5	MAKITA LABEL
52	213510-0	O RING 36
53	416561-4	CRANK CAP
54	911221-8	PAN HEAD SCREW M5X16
55	345278-1	HOLDER CAP PLATE
56	262003-4	RUBBER RING 6
57	643700-5	BRUSH HOLDER CAP 7-18
58	191957-7	A.C. CARBON BRUSH CB-204
58-1	194992-4	CARBON BRUSH SET CB-204
59	922227-1	HEX. SOCKET HEAD BOLT M5X18
60	345319-3	REAR COVER
61	922371-4	HEX. SOCKET HEAD BOLT M6X50
61-1	922374-8	H.S.H.BOLT M6X50 WITH WG
62	941151-9	FLAT WASHER 6
63	153438-9	MOTOR HOUSING COMPLETE
C10	213406-5	O RING 30
C20	414665-6	FIX RING
C30	643711-0	BRUSH HOLDER
64	183557-7	CRANK HOUSING
64		INC. 51
64-1	317623-0	CRANK HOUSING
65	850406-0	NAME PLATE HM1304B
66	626124-0	FIELD 220-240V
67	265428-1	+ HEX. BOLT M5X65
68	253794-8	FLAT WASHER 18
69	211087-9	BALL BEARING 6200DDW
70	681635-2	INSULATION WASHER
71	516864-7	ARMATURE ASS'Y 220-240V
71		INC. 69,70,72,73
72	241870-0	FAN 80
73	211228-7	BALL BEARING 6202DDW
74	418000-0	BAFFLE PLATE
75	266310-7	HEX.SOCKET HEAD BOLT M6X45
76	317446-6	GEAR HOUSING COVER
77	211214-8	BALL BEARING 6302
78	226450-3	HELICAL GEAR 57
79	421780-9	SEAL RING B
80	317445-8	GEAR HOUSING
81	256111-1	PIN 6
82	421779-4	SEAL RING A
83	265995-6	TAPPING SCREW 4X18
84	183546-2	HANDLE SET
84		INC. 92
85	941152-7	FLAT WASHER 6
86	922371-4	HEX. SOCKET HEAD BOLT M6X50
87	256111-1	PIN 6
88	331212-7	SEAL
89	211104-5	BALL BEARING 6001
90	226449-8	HELICAL GEAR 34
91	211109-5	BALL BEARING 6201
92	183546-2	HANDLE SET
92		INC. 84
93	645105-5	NOISE SUPPRESSOR
94	685725-3	SPONGE SHEET
95	415805-9	LOCK BUTTON
96	417544-7	SWITCH LEVER
97	415806-7	LOCK PLATE
98	651922-3	SWITCH TG71B
98-1	650677-7	SWITCH C3PA-1112
98-2	651922-3	SWITCH TG71B
98-3	650677-7	SWITCH C3PA-1112
99	421778-6	SWITCH BOX
100	231457-6	COMPRESSION SPRING 3
101	682560-0	CORD GUARD 10
102	665883-1	POWER SUPPLY CORD 1.0-2-5.0
103	687052-4	STRAIN RELIEF
104	265995-6	TAPPING SCREW 4X18
105	922361-7	HEX. SOCKET HEAD BOLT M6X40
106	941152-7	FLAT WASHER 6
107	256219-1	PIN 4
108	322477-2	TOOL RETAINER POLE
109	322550-8	TOOL RETAINER SHAFT
110	951272-9	SPRING PIN 8-40
A01	183598-3	STEEL CARRYING CASE
C10	819140-1	MAKITA LOGO LABEL
A01-1	824826-4	PLASTIC CARRYING CASE
C10	163467-4	LATCH
B01	195201-4	HAMMER SERVICE KIT
C10	181490-7	HAMMER GREASE 30G
C11	1914C5-7	GREASE SET
B01		INC. 7,15,19,22,26,58
F08	197148-8	DUST EXTRACTOR ATTACHMENT SET
F10	197168-2	DUST EXTRACTOR ATTACHMENT SET
