Makita Spare Parts for Cordless Rotary Hammer Drill BHR162
Makita Original spare parts sourced from the manufacturer, at the lowest price on the web, with after-sales service, for to make maintenance or repair deteriorated parts for Cordless Rotary Hammer Drill BHR162.In the following table, look for the model of the Rotary Hammer and the respective parts of the code.
| BHR162 CORDLESS ROTARY HAMMER 16MM | ||
| # | Part Num. | Description |
| 001 | 286263-4 | CAP 35 |
| 002 | 233940-9 | RING SPRING 19 |
| 003 | 419220-9 | CHUCK COVER |
| 004 | 257241-1 | RING 21 |
| 005 | 345187-4 | GUIDE WASHER |
| 006 | 233916-6 | CONICAL COMP. SPRING 21-29 |
| 007 | 921923-8 | HEX. BOLT M8X120 |
| 008 | 417911-6 | GRIP BASE |
| 009 | 154842-5 | GRIP 36 COMPLETE |
| C10 | 931402-8 | HEX. NUT M8 |
| 010 | 266053-1 | TAPPING SCREW 4X35 |
| 011 | 162242-5 | CHANGE LEVER COMPLETE |
| 012 | 233459-8 | COMPRESSION SPRING 3 |
| 013 | 419192-8 | LOCK BUTTON |
| 014 | 213278-8 | O RING 17 |
| 015 | 213956-0 | OIL SEAL 25 |
| 016 | 211375-4 | BALL BEARING 6805LLB |
| 017 | 211012-0 | BALL BEARING 606ZZ |
| 018 | 154840-9 | GEAR HOUSING COMPLETE |
| 019 | 961135-1 | RETAINING(EXT) WR-25 |
| 020 | 267304-5 | FLAT WASHER 25 |
| 021 | 233457-2 | COMPRESSION SPRING 25 |
| 022 | 331707-0 | SPUR GEAR 46 |
| 026 | 154843-3 | TOOL HOLDER COMPLETE |
| 027 | 216022-2 | STEEL BALL 7.0 |
| 028 | 213183-9 | X RING 13 |
| 029 | 324611-0 | IMPACT BOLT |
| 030 | 257275-4 | RING 11 |
| 031 | 233942-5 | RING SPRING 22 |
| 032 | 267175-0 | FLAT WASHER 24 |
| 033 | 345681-6 | JOINT PLATE |
| 034 | 324613-6 | STRIKER |
| 035 | 213182-1 | O RING 14 |
| 036 | 331708-8 | PISTON CYLINDER |
| 037 | 267130-2 | FLAT WASHER 9 |
| 038 | 324612-8 | PISTON JOINT |
| 039 | 267130-2 | FLAT WASHER 9 |
| 040 | 227152-4 | SPUR GEAR 10 |
| 041 | 331706-2 | CLUTCH CAM |
| 042 | 219019-0 | SWASH BEARING 9 |
| 043 | 226623-8 | HELICAL GEAR 22 |
| 044 | 423346-1 | SEAL RING |
| 045 | 233458-0 | COMPRESSION SPRING 32 |
| 046 | 268147-8 | PIN 4 |
| 047 | 443123-5 | FELT 4X3 |
| 048 | 345645-0 | CHANGE PLATE |
| 049 | 233460-3 | COMPRESSION SPRING 3 |
| 050 | 345654-9 | STOPPER PLATE |
| 051 | 211012-0 | BALL BEARING 606ZZ |
| 052 | 154841-7 | INNER HOUSING COMPLETE |
| 053 | 213953-6 | O RING 24 |
| 054 | 619182-3 | ARMATURE |
| 055A | 266282-6 | TAPPING SCREW ST3X10 |
| 055-1A | 911011-9 | PAN HEAD SCREW M3X10 |
| 055-1C | 911011-9 | PAN HEAD SCREW M3X10 |
| 056A | 689136-4 | FET SPACER |
| 057 | 638446-6 | YOKE UNIT |
| 058 | 638445-8 | ENDBELL COMPLETE |
| 059 | 419457-8 | F/R CHANGE LEVER |
| 060 | 421957-6 | SWITCH COVER |
| 061 | 419456-0 | HOLDER CAP COVER |
| 062 | 213953-6 | O RING 24 |
| 063 | 643929-3 | BRUSH HOLDER CAP |
| 064 | 191971-3 | CARBON BRUSH CB-430 |
| 065A | 650578-9 | SWITCH TG553FSB-6 |
| 065-1A | 638879-5 | SWITCH UNIT |
| 065-1C | 638879-5 | SWITCH UNIT |
| 066 | 862842-8 | BHR162 NAME PLATE |
| 067 | 265995-6 | TAPPING SCREW 4X18 |
| 068-1A | 188233-8 | HOUSING SET |
| 068-2A | 187379-7 | HOUSING SET |
| 068-2C | 187379-7 | HOUSING SET |
| 069 | 631711-2 | LIGHT CUIRCUIT |
| 070-1A | 188233-8 | HOUSING SET |
| 070-2A | 187379-7 | HOUSING SET |
| 070-2C | 187379-7 | HOUSING SET |
| 071A | 643847-5 | TERMINAL |
| 071-1A | 643867-9 | TERMINAL |
| 071-1C | 643867-9 | TERMINAL |
| A01 | 415486-9 | DEPTH GAUGE |
| A02-1C | 195584-2 | DC18RC FAST CHARGER |
| A03-5C | 194065-3 | BATTERY BL1430 SET |
| A03-6C | 194065-3 | BATTERY BL1430 SET |
| A04-4C | 141074-3 | PLASTIC CARRYING CASE COMPLET |
| C10 | 324667-3 | SHAFT |
| C20 | 413098-2 | PLATE |
| C30 | 417724-5 | LATCH |
| C40 | 419215-2 | PLASTIC CASE LID |
| C50 | 419216-0 | HANDLE |
| A05C | 804775-1 | BHR162RFE PLASTIC CASE LABEL |
| A06C | 450128-8 | BATTERY COVER |
| E01 | 689098-6 | HEAT SINK |
