Makita Spare Parts for Angle Grinder GA4541R

€17.65
Tax included

Makita Spare Parts for Angle Grinder GA4541R

Makita genuine spare parts or replacements parts for to repair Angle Grinder GA4541R.
ITEM CODE: 123144-0
Quantity
on 7/10 Business Days Approx.

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Makita Spare Parts for Angle Grinder GA4541R

Makita genuine spare parts or replacements parts for to repair Angle Grinder GA4541R.

In the following table, look for the model of the Angle Grinder and the respective parts of the code.
Makita GA4541R

Angle Grinder GA4541R
1 319310-7 GEAR BOX
2 252186-8 NUT M6 X 9554NB
3 253077-6 FLAT WASHER 6 4300 / 01BV
4 227591-8 GEAR 10 FOR GA
5 211142-7 BEARING 6001LLB X GD0800C
6 141981-0 GEARCASE COVER
7 234230-3 COMPRESSION SPRING 33
8 141515-9 BRAKE SUPPORT
9 326132-8 BRAKE PLATE
12 515394-5 ARMATURE 240V
13 681656-4 INSULATING WASHER X GD0810C
14 253823-7 FLAT WASHER 7 X JS1600
15 210027-4 BEARING 627DDW X 9561CV
16 421738-8 RING 22 X 9561CV
20 455351-0 SPACER
22 453375-0 DEFLECTOR B
23 266258-3 SCREW 4 X 70 X 9564
24 344871-8 CHECK X GD0800C
25 626649-4 GA SERIES STATOR
27 194074-2 CARBON BRUSH CB-325 X 9554NB
28 266007-8 SCREW M3 X10 HP2030
29 643770-4 BRUSH HOLDER
30 453376-8 MOTOR HOUSING B
31 266326-2 SCREW 4X18 X MT601
32 687169-3 CABLE CLAMP HP1620
33 632K98-1 SWITCH SUPPORT
35 682559-5 CORD GUARD X 6822
36 266326-2 SCREW 4X18 X MT601
38 453365-3 REAR COVER C
39 620786-6 REGULATOR
40 651418-4 SWITCH ST115A-40 X 9541
42 233071-4 COMPRESSION SPRING 4 X 9541
43 453847-5 SWITCH LEVER
44 453377-6 SWITCH BUTTON B
45 346557-0 SWITCH PLATE
46 453369-5 BUTTON
47 234057-1 COMPRESSION SPRING 6 GA5021C
48 266467-4 SCREW 4X50 FS2500K
49 213032-0 RING 4 X GA4530
50 256535-1 PIN 6 FOR GA
51 263002-9 RUBBER PIN 4
52 210026-6 BALL BEARING 696ZZ
53 961005-4 RETAINING RING S9
54 253180-3 FLAT WASHER 10 X 6221DW
55 310683-1 JOINT
56 346556-2 PLATE C FOR GA
57 227592-6 GEAR 38 FOR GA
58 313228-4 JUNCTION FOR GA
59 210302-8 6903ZZ BEARING FOR GA
60 253744-3 FLAT WASHER 12 24B / 12N / 14
61 263002-9 RUBBER PIN 4
62 213641-5 RING 51 FOR GA
63 318839-0 BEARING BOX B
64 265490-6 SCREW M4 X 16 X 9561CV
65 211129-9 BEARING BEARING 6201DD NSK
66 267279-8 FLAT WASHER 21 X HR2450FT
67 443124-3 FELT RING 17 GD0600
68 285854-8 RETAIRER BEARING 20-33
69 962105-3 R26 RETURN RING
70 326133-6 SHAFT
71 310514-4 SHAFT FLANGE
72 123144-0 SPARK GUARD
73 224447-6 INTERNAL FLANGE 42B
74 224554-5 EXTERNAL FLANGE 14-45 X 9541
75 135555-7 CPL JOINT

All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
