Makita Spare Parts for Die Grinder GD0600
€3.31
Tax included
Makita Spare Parts for Die Grinder GD0600
We supply original MAKITA spare parts on offer at unbeatable prices, we are a service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Die Grinder GD0600.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Makita Spare Parts for Die Grinder GD0600
We supply original MAKITA spare parts on offer at unbeatable prices, we are a service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Die Grinder GD0600.
In the following table, look for the model of the Die Grinder and the respective parts of the code.
| Die Grinder GD0600 | ||
| # | Part Num. | Description |
| 1 | 421943-7 | PROTECTION INSULATION GD0600 |
| 2 | 763664-8 | Dad0 6 GD0600 |
| 3 | 763620-8 | CLAMP 6MM X 906 |
| 4 | 324638-0 | SHAFT GD0600 |
| 5 | 317999-5 | RETAINING BEARING GD0600 |
| 6 | 443124-3 | FELT RING 17 GD0600 |
| 7 | 267329-9 | WASHER 18 GD0600 |
| 8 | 210106-8 | BEARING 6001LLB |
| 9 | 961052-5 | RETAINING RING S12 |
| 10 | 318000-9 | CASING FRONT GD0600 |
| 11 | 266361-0 | SCREW 4 X 30 X 9554NB |
| 12 | 210042-8 | BEARING FOR 629LLB GD0600 |
| 13 | 324639-8 | SCREW WING GD0600 |
| 14 | 421942-9 | DISTANCE GD0600 |
| 15 | 324639-8 | SCREW WING GD0600 |
| 16 | 267126-3 | FLAT WASHER 22 |
| 17 | 210042-8 | BEARING 629 LLB FOR GD0600 |
| 18 | 317821-6 | COVER SCAT.INGR. X 9554NB |
| 19 | 240076-7 | FAN 56 X 9554NB |
| 20 | 515679-9 | ARMATURE GD0600 |
| 21 | 681636-0 | INSULATION WASHER |
| 22 | 210034-7 | BEARING 607LLB X 9554NB |
| 23 | 421868-5 | RING RUBBER X 9554NB |
| 24 | 266345-8 | SCREW 4x80 X 9557NB |
| 25 | 418770-1 | BAFFLE X 9557NB |
| 26 | 621724-1 | STATOR GD0600 |
| 27 | 418838-3 | CASING MOTOR X 9557PB |
| 29 | 418729-8 | DISTANCE X 9557NB |
| 30 | 651947-7 | SWITCH-9527PB 9528PB |
| 31 | 645233-6 | CAPACITOR X 9554NB |
| 33 | 643760-7 | BRUSH X BO6040 |
| 34 | 194074-2 | CARBON BRUSHES CB-325 X 9554NB |
| 35 | 266007-8 | SCREW M3 X10 HP2030 |
| 36 | 266492-5 | SCREW M4x25-9527PB 9528PB |
| 37 | 345504-8 | X PLATE LEVER INTER.GD0600 |
| 38 | 154584-1 | LEVER B SWITCH 9557PB |
| 39 | 183943-2 | COVER POST. X 9557PB |
| 40 | 266326-2 | SCREW 4x18 X MT601 |
| 41 | 687169-3 | CLAMP CABLE stringy HP1620 |
| 42 | 682559-5 | SAVE CABLE X 6822 |
| 43 | 231252-4 | SPRING 6-9527PB 9528PB |
| 44 | 418842-2 | BUTTON LOCK X 9557PB |
| 46 | 266351-3 | SCREW 4 X 35 X 9557PB |
| 47 | 213445-5 | RING 26 X 9554NB |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
