at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Polisher PV7000C.
In the following table, look for the model of Polsher and the respective parts of the code.![]()
| Polisher Makita PV7000C | ||
| Pos. | Codice | Descrizione |
| 1 | 743053-3 | PAD 165 X 9227CB |
| 2 | 324079-0 | POST X PV7000C |
| 3 | 152690-6 | RETAINING BEARING X PV7000C |
| 4 | 211129-9 | BALL BEARING 6201DD |
| 5 | 152691-4 | GEAR BOX CPL PV7000C |
| 6 | 257707-1 | SOCKET temporary locking X PV7000C |
| 7 | 226536-3 | GEAR TWISTED PV7000C |
| 8 | 253215-0 | ROND. FLAT 8 6510PBL / LVR |
| 9 | 226141-6 | GEAR CPL X PV7000C |
| 10 | 273649-1 | KNOB SIDE X PV7000C |
| 11 | 266211-9 | SCREW 5 X 40 X HK0500 |
| 12 | 442132-1 | SEAL X PV7000C |
| 13 | 152692-2 | COVER CARC. CPL X PV7000C |
| 14 | 210005-4 | BALL BEARING 608DDW |
| 15 | 240020-4 | FAN 65 X PV7000C |
| 16 | 419721-7 | VANE X PV7000C |
| 17 | 516433-4 | ARMATURE X PV7000C |
| 18 | 266056-5 | SCREW M 5 X 45 |
| 19 | 599013-1 | STATOR 220 X PV7000C |
| 20 | 681660-3 | INSULATING WASHER X PV7000C |
| 21 | 253139-0 | FLAT WASHER 8 |
| 22 | 210005-4 | BALL BEARING 608DDW |
| 23 | 265995-6 | SCREW M4X18 X 6408 / 6221DW |
| 24 | 417450-6 | COVER HANDLE X PV7000C |
| 25 | 631427-9 | CONTROL X PV7000C |
| 26 | 417449-1 | LEVER X PV7000C |
| 27 | 232201-4 | SPRING FLAT X PV7000C |
| 28 | 183300-4 | HOUSING MOTOR X PV7000C |
| 32 | 643750-0 | PLUG BRUSH HOLDER |
| 33 | 191963-2 | CARBON BRUSHES CB-303 |
| 34 | 651297-0 | SWITCH X PV7000C |
| 35 | 682559-5 | SAVE CABLE X 6822 |
| 37 | 687063-9 | RETAINER X 4304T |
| 38 | 265995-6 | SCREW M4X18 X 6408 / 6221DW |
| 39 | 645253-0 | CAPACITOR X 6408 |
| 40 | 685722-9 | SPONGE X 4302C |
| 41 | 265995-6 | SCREW M4X18 X 6408 / 6221DW |
| 42 | 265995-6 | SCREW M4X18 X 6408 / 6221DW |
