Makita Spare Parts for Chainsaw EA3500S40B
MAKITA service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Chainsaw EA3500S40B.
In the following table, look for the model of Chainsaw and the respective parts of the code.
| EA3500S40B - CHAINSAW 35CC 40CM MAKITA pag.1 | ||
| # | Part Num. | Description |
| 22 | 266478-9 | SCREW 5,5X16 (TORX) |
| 35 | 452020-4 | CATCH LEVER PS32CTLC |
| 36 | 452019-9 | THROTTLE LEVER PS32CTLC |
| 37 | 231866-9 | TORSION SPRING 10 PS32CTLC |
| 38 | 452021-2 | GRIP SHELL PS32CTLC |
| 41 | 452018-1 | FUEL NIPPLE PS32CTLCP01 |
| 42 | 424456-7 | SUCTIOON LINE PS32CTLC |
| 43 | 965452660 | TUBE 5,5X3 L = 93MM |
| 44 | 163447-0 | GASOLINE FILTER X DCS230T |
| 46 | 422065-6 | TUBE 2,5X55 PS32CTLC |
| 48 | 234189-4 | COMPRESSION SPRING 12 PS32CTLC P01 |
| 49 | 266605-8 | SCREW M5X16 PS32CTLC |
| 73 | 452036-9 | TUBOLAR HANDLE PS32CTLCP20 |
| 80 | 213586-7 | O-RING 11.5 PS32CTLC |
| 91 | 168823-3 | TANK CAP ASS'Y PS32CTLC |
| 117 | 346517-2 | CUP WASHER 6 PS32CTLC |
| 200 | 195758-5 | TANK ASSEMBLY A BLUE EA3201S35A |
| 201 | 170175010 | VENT VALVE SET |
| 202 | 213080-9 | O-RING 29.5 PS32CTLC |
| 301 | 266478-9 | SCREW 5,5X16 (TORX) |
| 302 | 266478-9 | SCREW 5,5X16 (TORX) |
| EA3500S40B - CHAINSAW 35CC 40CM MAKITA pag.2 | ||
| 3 | 422066-4 | TUBE 2,5X72 PS32CTLC |
| 18 | 125131040 | INTAKE HOSE |
| 19 | 346413-4 | BUSH 17 |
| 20 | 452030-1 | INTAKE MANIFOLD PS32CTLC |
| 21 | 424173-9 | DAMPING PLUG PS32CTLC |
| 23 | 423414-0 | AIR FILTER PS32CTLC |
| 24 | 452031-9 | AIR FILTER COVER PS32CTLC |
| 25 | 266607-4 | SCREW M5X20 PS32CTLC |
| 26 | 125131052 | INTERMEDIATE FLANGE -> CT23-2 |
| 27 | 264044-6 | SNAP NUT M5 PS32CTLC |
| 28 | 318634-8 | FLANGE RING PS32CTLC |
| 29 | 908004406 | H.L. SOCKET HEAD BOLT |
| 30 | 346290-4 | CONTACT SPRING PS32CTLC |
| 45 | 168398-2 | PRIMER PUMP X DCS230T |
| 47 | 422067-2 | TUBE 2,5X55 PS32CTLC |
| 60 | 266421-8 | SCREW 3X10 HR2800 |
| 63 | 346304-9 | MUFFLER GASKET PS32CTLC |
| 64 | 038174410 | CONNECTING LINL L=39,5MM |
| 65 | 266480-2 | H.L. SOCKET HEAD BOLT M5X55 |
| 66 | 346764-5 | COOLING PLATE |
| 71 | 125118010 | FILTER COVER |
| 82 | 424618-7 | PLUG |
| 94 | 125174100 | MUFFLER |
| 114 | 233971-8 | RING SPRING PS32CTLC |
| 203 | 125174170 | SPARK CATCHER |
| 300 | 168829-1 | CARBURETOR |
| 303 | 266478-9 | SCREW 5,5X16 (TORX) |
| 311 | 266605-8 | SCREW M5X16 PS32CTLC |
| 317 | 266605-8 | SCREW M5X16 PS32CTLC |
| EA3500S40B - CHAINSAW 35CC 40CM MAKITA pag.3 | ||
| 4 | 962210092 | NEEDLE CAGE KV9x12x11,5S |
| 5 | 960102131 | BALL BEARING 6201 |
| 6 | 213141-5 | OIL SEAL AS 12X20X4,5 |
| 10 | 266608-2 | SCREW 5X40 PS32CTLC |
| 31 | 452025-4 | CHOKE LEVER PS32CTLC |
| 34 | 452022-0 | THROTTLE LINKAGE CPL. PS32CTLC |
| 70 | 168504-9 | VENT VALVE PS32CTLC |
| 83 | 125132030 | PISTON PIN |
| 84 | 232302-8 | PACKING RING |
| 85 | 125120100 | CRANKSHAFT |
| 115 | 346301-5 | SPIKE BAR PS32CTLC |
| 118 | 125111070 | CRANKCASE LEFT |
| 119 | 125111080 | CRANKCASE RIGHT |
| 120 | 125111090 | CRANK CASE GASKET |
| 121 | 908405255 | SCREW M5X25 (TORX) |
| 122 | 266960-8 | SCREW X DCS6401 |
| 125 | 346760-3 | CYLINDER GASKET |
| 126 | 258038-1 | CLAMPING PIN |
| 204 | 143323-4 | CYLINDER |
| 205 | 197479-5 | PISTON |
| 206 | 257366-1 | PISTON RING Ø 38 |
| 304 | 266478-9 | SCREW 5,5X16 (TORX) |
| 305 | 266478-9 | SCREW 5,5X16 (TORX) |
| 306 | 266478-9 | SCREW 5,5X16 (TORX) |
| 308 | 234189-4 | COMPRESSION SPRING 12 PS32CTLC |
| 309 | 234189-4 | COMPRESSION SPRING 12 PS32CTLC |
| 310 | 234189-4 | COMPRESSION SPRING 12 PS32CTLC |
| 315 | 168823-3 | TANK CAP PS32CTLC |
| 316 | 213080-9 | O-RING 29.5 PS32CTLC |
| EA3500S40B - CHAINSAW 35CC 40CM MAKITA pag.4 | ||
| 11 | 0650109950 | SPARK PLUG CMR6A X MS251.A |
| 12 | 264022-6 | NUT |
| 13 | 267822-3 | SPRING WASHER 8 PS32CTLC |
| 14 | 126270-4 | IGNITION COIL PS32CTLC |
| 15 | 168601-1 | CABLE HARNESS PS32CTLC |
| 16 | 452670-5 | ISOLATING WASHER PS32CTLC |
| 72 | 266472-1 | SCREW |
| 86 | 140480-9 | FLYWHEEL PS32CTLC |
| 92 | 161328-2 | STARTER ASS'Y BLUE EA3201S35A |
| 98 | 424522-0 | SPARK PLUG CAP |
| 99 | 125143040 | ISOLATING HOSE |
| 124 | 326210-4 | SPRING |
| 207 | 195761-6 | STARTER RATCHET CPL. PS32CTLC |
| 208 | 452026-2 | AIR GUIDE PLATE PS32CTLC |
| 209 | 266777-9 | SCREW 5X1 PS32CTLC |
| 210 | 453786-9 | CAM PLATE PS32CTLC |
| 211 | 234253-1 | TORSION SPRING 20 PS32CTLC |
| 212 | 455919-2 | CABLE DRUM CPL. |
| 213 | 195955-3 | REWIND SPRING PS32CTLC |
| 214 | 453783-5 | STARTER GRIP PS32CTLC |
| 215 | 267847-7 | SQUARE WASHER 4 PS32CTLC |
| 216 | 444038-9 | STARTER ROPE PS32CTLC |
| 307 | 266478-9 | SCREW 5,5X16 (TORX) |
| EA3500S40B - CHAINSAW 35CC 40CM MAKITA pag.5 | ||
| 32 | 267833-8 | CUP WASHER 8 PS32CTLC ---> CT28-2 |
| 33 | 259033-4 | SAFETY WASHER X UC |
| 51 | 452032-7 | HAND GUARD PS32CTLC |
| 52 | 313212-9 | HAND GUARD GUIDE PS32CTLC |
| 53 | 234210-9 | COMPRESSION SPRING 6 PS32CTLC |
| 54 | 346298-8 | BRAKE BAND PS32CTLC |
| 55 | 231868-5 | TENSION SPRING 10 PS32CTLC |
| 56 | 346299-6 | SPACER SHEET METAL PS32CTLC |
| 57 | 325947-0 | BUSH 6 |
| 58 | 257934-0 | STOP RING E-4 X UH6580 |
| 59 | 452033-5 | BRAKE COVER PS32CTLC |
| 61 | 452044-0 | SPROCKET GUARD CPL. |
| 62 | 264055-1 | NUT M8 |
| 67 | 452035-1 | PUMP DRIVE PS32CTLC |
| 68 | 267430-0 | WASHER 10 PS32CTLC |
| 69 | 424342-2 | OIL PRESSURE LINE PS32CTLC |
| 74 | 346300-7 | TENSION SLIDE |
| 75 | 227743-1 | HELICAL GEAR 11 |
| 76 | 227744-9 | HELICAL GEAR 18 |
| 78 | 452667-4 | GEAR COVER |
| 79 | 213594-8 | O-RING 7 |
| 81 | 143549-8 | ENGINE CASING ---> CT23-2 |
| 88 | 168607-9 | CLUTCH COMPLETE PS32C-EA3201S |
| 89 | 140M30-8 | CLUTCH DRUM COMPLETE ---> CT32-2 |
| 93 | 163500-2 | LINK PLATE COMPLETE PS32CTLC |
| 95 | 161346-0 | OIL PUMP COMPLETE PS32C - EA3201S |
| 96 | 168645-1 | OIL SUCTION LINE COMPLETE PS32CTLC |
| 97 | 267431-8 | FLAT WASHER 10 PS32CTLC |
| 112 | 346518-0 | GUIDE PLATE PS32CTLC |
| 113 | 913447134 | SELF-CUTTING SCREW 4,7X13 DCS4 |
| 116 | 925305000 | WASHER 5/12X0.5 ES-31A |
| 217 | 231873-2 | TENSION SPRING 5 PS32CTLC |
| 218 | 234207-8 | COMPRESSION SPRING 6 PS32CTLC |
| 219 | 452666-6 | NIPPLE PS32CTLC |
| 238 | 183H51-7 | CHAIN TENSIONER CPL. |
| 312 | 266605-8 | SCREW M5X16 PS32CTLC |
| 313 | 266421-8 | SCREW 3X10 HR2800 |
| 314 | 266421-8 | SCREW 3X10 HR2800 |
| 318 | 424631-5 | RUBBER SLEEVE ---> CT23-2 |
