Makita Spare Parts for Power Cutters EK8100WS
€2.76
Tax included
Makita Spare Parts for Power Cutter EK8100WS
We have the original Spares MAKITA for Power Cutter EK8100WS, the Repair information, Exploded Diagram, parts list and tool repair that help you need to get your tools running like new again.Fix Your Power Cutter EK8100WS. All Spares are original and can be supplied at Cheap and discounted prices. Our Spares are Genuine Parts Guaranteed.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Makita Spare Parts for Power Cutters EK8100WS
We have the original Spares MAKITA for Power Cutter EK8100WS, the Repair information, Exploded Diagram, parts list and tool repair that help you need to get your tools running like new again.
In the following table, look for the model of Power Cutter and the respective parts of the code.
| EK8100WS - POWER CUTTER 81CC 400mm pag.1 | ||
| # | Part Num. | Description |
| 5 | 394114101 | SCREW PLUG |
| 11 | 163532-9 | FILTER |
| 12 | 010114020 | REPAIR KIT FILTER HP-450 |
| 14 | 965404913 | FUEL HOSE PC7314 |
| 15 | 395310600 | BRACKET BLACK DCP8132 |
| 16 | 424695-9 | RUBBER BUFFER |
| 17 | 424695-9 | RUBBER BUFFER |
| 18 | 424695-9 | RUBBER BUFFER |
| 19 | 424695-9 | RUBBER BUFFER |
| 20 | 319268-0 | AXLE |
| 21 | 319268-0 | AXLE |
| 22 | 319268-0 | AXLE |
| 23 | 346870-6 | WASHER DPC8132 |
| 24 | 346870-6 | WASHER DPC8132 |
| 25 | 266687-0 | SCREW 5,5X45 |
| 26 | 266687-0 | SCREW 5,5X45 |
| 27 | 266687-0 | SCREW 5,5X45 |
| 28 | 913455204 | SCREW 5,5X20 (TORX) |
| 29 | 266606-6 | SCREW M5X40 PS32CTLC |
| 30 | 395310020 | POT BLACK DPC8132 |
| 31 | 143097-7 | FRONT HANDLE |
| 32 | 395250020 | LOWER SUPPORT |
| 33 | 980115215 | MAKITA LABEL DPC8112 |
| 34 | 266687-0 | SCREW 5,5X45 |
| 35 | 394114272 | STAND WITH WHEELS |
| 37 | 394114230 | WHEEL X SUPPORT IMP DPC7311 |
| 38 | 394114240 | BUSHING DPC7311 |
| 79 | 395114603 | BLUE TANK |
| 80 | 455820-1 | THROTTLE LEVER X DCS9000 |
| 81 | 170175010 | VENT VALVE KSET |
| 83 | 395117011 | THROTTLE LINKAGE |
| 208 | 266660-0 | SCREW M6X35 |
| 209 | 908905165 | SCREW M5X16 FOR PS-460/500 |
| 214 | 346871-4 | WASHER PC8116 |
| 215 | 395114300 | ANGULAR UNION ASSEMBLYDPC8132 |
| 216 | 168823-3 | TANK CAP PS32CTLC |
| 217 | 213080-9 | RING 29.5 PS32CTLC |
| 297 | 395114040 | PLUG |
| 298 | 170118031 | ADJUSTING GUIDE H / L PS3410TH |
| EK8100WS - POWER CUTTER 81CC 400mm pag.2 | ||
| 39 | 395118122 | FILTER COVER |
| 41 | 395118010 | FIXING DPC8132 |
| 45 | 424703-6 | RUBBER COVER DPC8132 |
| 47 | 395173081 | PRE FILTER - NEW 424700-2 |
| 48 | 424697-5 | PACKING RING |
| 49 | 424701-0 | AIR FILTER |
| 50 | 395173020 | INNER FILTER DPC8132 |
| 51 | 123308-6 | HOOD CPL. BLACK |
| 54 | 908605505 | SCREW M5X50 DPC7311 |
| EK8100WS - POWER CUTTER 81CC 400mm pag.3 | ||
| 59B | 123310-9 | INTAKE MANIFOLD CPL. DPC8132 |
| 60 | 346867-5 | GUIDE RING X 9000 |
| 63 | 346874-8 | GASKET |
| 64 | 908204555 | SCREW M4X55 |
| 65 | 970502050 | INSULATING HOSE (M) |
| 67 | 394150042 | CHOKE SHAFT |
| 68 | 965452382 | FUEL TUBE 1mt Diam. 3/5 |
| 69 | 424696-7 | RUBBER GROMMET |
| 72 | 346876-4 | GASKET X PS6100 |
| 73 | 346868-3 | COOLING PLATE |
| 74 | 266960-8 | SCREW X DCS6401 |
| 83 | 395117011 | CYLINDRICAL PIN |
| 86 | 455808-1 | CHOKE SHAFT |
| 205 | 267821-5 | SPRING WASHER 5 |
| 213 | 266946-2 | SCREW M5X12 (TORX) |
| 266 | 264108-6 | SQUARE NUT X DCS6401 |
| 268B | 395171025 | FUEL HOSE |
| 269 | 038131070 | SPRING CLAMP X TUBE |
| 271 | 394131210 | SUCTION LINE DPC8132 |
| 286 | 395174200 | MUFFLER |
| 287 | 395174140 | SPARK ARREST SCREEN |
| 288 | 913242100 | SCREW 4X9.7 |
| 294 | 324616-0 | HOSE CLAMP X DCS230T - PS220TH |
| EK8100WS - POWER CUTTER 81CC 400mm pag.4 | ||
| 232 | 394151160 | PUMP COVER CPL. PC8116 |
| 233 | 144150170 | SCREW PC8116 |
| 234 | 395151120 | DIAPHRAGM COVER DPC8132 |
| 235 | 378151220 | SCREW PS3400TH |
| 236 | 957151180 | SET DIAPHRAGM / GASKETS PC8116 |
| 237 | 394151150 | PUMP DIAPHRAGM PC8116 |
| 240 | 394151315 | BUSHING PC8116 |
| 241 | 394151315 | BUSHING PC8116 |
| 242 | 394151330 | PACKING RING PC8116 |
| 243 | 394151320 | THROTTLE SHUTTER PC8116 |
| 245 | 394151660 | SCREW PC8116 |
| 246 | 394151330 | PACKING RING PC8116 |
| 247 | 394151400 | DISC PC8116 |
| 248 | 108151350 | SHAFT CLIP |
| 250 | 395151265 | CHOKE SHUTTER |
| 256 | 957151191 | CONTROL PARTS SET PC8116 |
| 257 | 021151180 | SCREEN |
| 258 | 394151040 | COVER DISC PC8116 |
| 259 | 394151510 | LOCKING BALL PC8116 |
| 267 | 378151220 | SCREW PS3400TH |
| 273 | 161315-1 | CARBURETOR |
| 274 | 395151130 | THROTTLE SHAFT.DPC8132 |
| 275 | 395151170 | CHOKE SHAFT DPC8132 |
| 276 | 395151110 | FAST IDLE LEVER DPC8132 |
| 277 | 395151190 | TORSION SPRING DPC8132 |
| 278 | 119151350 | SHAFT CLIP |
| 279 | 395151180 | CHOKE LEVER DPC8132 |
| 280 | 394151660 | SCREW PC8116 |
| 281 | 395151140 | IDLE STOP SCREW DPC8132 |
| 282 | 395151150 | TORSION SPRING DPC8132 |
| 283 | 394151660 | SCREW PC8116 |
| 284 | 170151290 | WASHER DPC8132 |
| EK8100WS - POWER CUTTER 81CC 400mm pag.5 | ||
| 84 | 346869-1 | CONTACT SPRING |
| 116 | 929314100 | SNAP RING 14X1 |
| 117 | 122164010 | STARTER ROPE X DCS9000 |
| 120 | 267821-5 | SPRING WASHER |
| 123 | 266607-4 | SCREW M5X20 PS32CTLC |
| 125 | 031166010 | STARTER RATCHET CPL. |
| 126 | 920208024 | NUT X DCS6401 |
| 127 | 926208001 | SPRING WASHER 8 |
| 130 | 266607-4 | SCREW M5X20 PS32CTLC |
| 132 | 424696-7 | RUBBER GROMMET |
| 134 | 957604260 | SPARK PLUG CAP CPL. |
| 135 | 168648-5 | SPARK PLUG X RBC350-RBC420-PB500R |
| 210 | 394141090 | FLYWHEEL ASSY DPC8132 |
| 223 | 123357-3 | STARTER ASSY. BLUE DPC8132 |
| 224 | 395160630 | HOUSING BLUE |
| 225 | 452458-3 | STARTER GRIP |
| 226 | 181163050 | REWIND SPRING |
| 227 | 143098-5 | CABLE DRUM COMPLETE DPC8132 |
| 228 | 395118170 | AIR GUIDE PLATE DPC8132 |
| 289 | 161310-1 | IGNITION COIL |
| 290 | 965605514 | CABLE WITH PLUG |
| 291 | 195143031 | ISOLATING WASHER |
| EK8100WS - POWER CUTTER 81CC 400mm pag.6 | ||
| 131 | 038132040 | PISTON PIN X DCS6401 |
| 136 | 395131041 | COOLING HOOD |
| 137 | 909005155 | SCREW M5X15 DPC8132 |
| 138 | 135794-9 | CYLINDER / PISTON CPL. D52 |
| 139 | 328132100 | PISTON D52 |
| 140 | 038132020 | PISTON RING X DCS6401 |
| 141 | 038132080 | PISTON RING |
| 142 | 455804-9 | DECOMPRESSION VALVE DPC8132P16 |
| 143 | 346873-0 | CYLINDER GASKET DPC7301 |
| 144 | 266473-9 | SCREW M5X23 PS4605-5105-5105D |
| 145 | 143109-6 | CRANKSHAFT |
| 146 | 212133-1 | PISTON PIN BEARING 12X16X13 X DCS6401 |
| 147 | 254042-8 | WOODRUFF-KEY 3X3,7 |
| 148 | 213814-0 | RADIAL RING 15 / 24X7 |
| 149 | 213814-0 | RADIAL RING 15 / 24X7 |
| 150 | 234366-8 | SNAP RING A 1616X1 |
| 151 | 346872-2 | SNAP RING |
| 152 | 346866-7 | GUIDE DISK |
| 153 | 395111110 | CRANKC., MAG. SIDE |
| 154 | 143225-4 | CRANKCASE CS CPL |
| 155 | 346877-2 | CRANK CASE GASKET DPC7301 P02 |
| 156 | 258038-1 | CLAMPING PIN |
| 157 | 266945-4 | SCREW M5X30 (TORX) |
| 158 | 211154-0 | BALL BEARING 6202 |
| 159 | 211154-0 | BALL BEARING 6202 |
| 160 | 161318-5 | CLUTCH DRUM PC8116 |
| 161 | 266947-0 | H.L. SOCKET HEAD BOLT M5X14 |
| 162 | 267389-1 | FLAT WASHER 12 PS350C / 4200 |
| 163 | 123305-2 | CLUTCH CPL |
| 164 | 181184020 | TENSION SPRING |
| 165 | 455832-4 | CLUTCH COVER (BLUE) DPC8132 |
| 167 | 424711-7 | POLI-V BELT 400-80 PC8116 |
| 168 | 965402870 | RUBBER PLATE DPC6401 |
| 204 | 962300017 | NEEDLE BUSH 309 |
| EK8100WS - POWER CUTTER 81CC 400mm pag.7 | ||
| 169 | 326341010 | PROTECTION HOOD SILVER PC8116 |
| 170 | 957342011 | PROT. HOOD MOUNTING, CPL. |
| 171 | 442169-8 | SLIDING DISC |
| 172 | 442169-8 | SLIDING DISC |
| 173 | 965404900 | RUBBER RING EXT. DPC6401 |
| 174 | 965404920 | RUBBER RING INT. DPC6401 |
| 175 | 346455-8 | IMPACT PLATE |
| 177 | 326211740 | CUTTING DEVICE ASSY. PC8116 |
| 178 | 394342190 | BOLT CPL. DPC7311 |
| 179 | 394211091 | SCREW PC8116 |
| 180 | 394228101 | AXLE DIAM 20 PC8116 |
| 180A | 326503-9 | SHAFT DIAM. 25.4MM |
| 182 | 213625-3 | RING 9 |
| 183 | 211490-4 | BALL BEARING 6203LLU X SG150-2 |
| 184 | 211490-4 | BALL BEARING 6203LLU X SG150-2 |
| 185 | 224443-4 | FLANGE 102 |
| 186 | 224443-4 | FLANGE 102 |
| 187 | 994290250 | SCREW M8X25 |
| 188 | 994290250 | SCREW M8X25 |
| 189 | 394228022 | SPACER |
| 190 | 394228022 | SPACER |
| 193 | 929240180 | SNAP RING DPC 6200 |
| 194 | 929240180 | SNAP RING DPC 6200 |
| 195 | 326211020 | BUSHING PC8116 |
| 196 | 908905125 | SCREW M5X12 PC8116-DPC8132 |
| 197 | 394213032 | TENSIONING SCREW PC8116 |
| 198 | 394342120 | PRESSURE SPRING |
| 199 | 921906004 | NUT |
| 200 | 264055-1 | NUT M8 |
| 202 | 394213021 | METAL SHEET DPC8132 |
| 206 | 326341301 | GRIP FOR PROTECTIVE HOOD |
| 207 | 908605165 | SCREW M5X16 DPC7311 |
| 218 | 455831-6 | MAKITA BLUE COVER DPC8132 |
| 220 | 455831-6 | MAKITA BLUE COVER DPC8132 |
| 222 | 222185-4 | BELT PULLEY DPC8132 |
