Makita Chainsaw EA3200S Parts
€2.84
Tax included
Makita Spare Parts for Chainsaw EA3100T
Makita genuine spare parts or replacement parts for to repair Chainsaw EA3200S.Fix Your Chainsaw EA3200S. All Spares are Ready at discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Makita Spare Parts for Chain Saw EA3200S
Fix Your Chainsaw EA3200S. All Spares are Ready at discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following table, look for the model of Brusch Cutter and the respective parts of the code.
| MAKITA EA3200S PETROL CHAIN SAW Spare Parts List | ||
| Pag.1 | ||
| # | Part Num | Description |
| 1 | 168823-3 | TANK CAP PS32CTLC |
| 2 | 213080-9 | RING 29.5 PS32CTLC |
| 3 | 163447-0 | FUEL FILTER FOR DCS230T |
| 4 | 195758-5 | TANK CPL BLUE EA3201S35A |
| 5 | 266651-1 | SCREW 5.5X16 PS32CTLC |
| 6 | 452021-2 | GRIP COVER PS32CTLC |
| 7 | 452020-4 | RELEASE LEVER PS32CTLC |
| 8 | 231866-9 | TORSION SPRING 10 PS32CTLC |
| 9 | 452019-9 | ACCELERATOR LEVER PS32CTLC |
| 10 | 195762-4 | BREATHER VALVE PS32CTLC |
| 11 | 452018-1 | FUEL CONNECTOR PS32CTLC |
| 12 | 213586-7 | RING 11.5 PS32CTLC |
| 13 | 424456-7 | FUEL PIPE PS32CTLC |
| 14 | 869077-2 | |
| 17 | 452036-9 | FRONT HANDLE PS32CTLC |
| 18 | 346517-2 | CUP WASHER 6 PS32CTLC |
| 19 | 234189-4 | COMPRESSION SPRING 12 PS32CTLC |
| 20 | 266605-8 | SCREW M5X16 PS32CTLC |
| 21 | 266651-1 | SCREW 5.5X16 PS32CTLC |
| 22 | 891898-4 | |
| 23 | 266651-1 | SCREW 5.5X16 PS32CTLC |
| Pag.2 | ||
| 24 | 452031-9 | FILTER COVER PS32CTLC |
| 25 | 423414-0 | AIR FILTER PS32CTLC |
| 26 | 452030-1 | BOTTOM PS32CTLC |
| 27 | 266604-0 | SCREW M4X40 PS32CTLC |
| 28 | 424173-9 | SHOCK ABSORBER PS32CTLC |
| 29 | 168398-2 | PRIMING PUMP FOR DCS230T |
| 30 | 422067-2 | PIPE 2.5X55 PS32CTLC |
| 31 | 422065-6 | PIPE 2.5X55 PS32CTLC |
| 32 | 422068-0 | PIPE 3X70 PS32CTLC |
| 33 | 422066-4 | PIPE 2.5X72 PS32CTLC |
| 34 | 318634-8 | FLANGE PS32CTLC |
| 35 | 346413-4 | BUSH 17 PS32CTLC |
| 36 | 452024-6 | INTERMEDIATE FLANGE PS32CTLC |
| 37 | 424340-6 | INTAKE SLEEVE PS32CTLC |
| 38 | 233971-8 | CIRCUIT RING PS32CTLC |
| 39 | 266651-1 | SCREW 5.5X16 PS32CTLC |
| 40 | 264044-6 | PLATE M5 PS32CTLC |
| 41 | 168849-5 | CARBURETOR PS32CTLC |
| 42 | 266421-8 | SCREW 3X10 HR2800 |
| 43 | 346290-4 | CONTACT PS32CTLC |
| 44 | 266651-1 | SCREW 5.5X16 PS32CTLC |
| 45 | 452023-8 | COVER PS32CTLC |
| 46 | 266607-4 | SCREW M5X20 PS32CTLC |
| 47 | 325938-1 | CONNECTOR L PS32CTLC |
| 48 | 346306-5 | INSULATION PLATE PS32CTLC |
| 49 | 325939-9 | BUSH PS32CTLC |
| 50 | 346304-9 | MUFFLER GASKET PS32CTLC |
| 51 | 266605-8 | SCREW M5X16 PS32CTLC |
| 52 | 168604-5 | MUFFLER PS32CTLC |
| 53 | 346294-6 | SPARK GUARD PS32CTLC |
| 54 | 266606-6 | SCREW M5X40 PS32CTLC |
| 55 | 266605-8 | SCREW M5X16 PS32CTLC |
| Pag.3 | ||
| 56 | 196384-3 | CYLINDER AND PISTON PS32CTLC |
| 57 | 195760-8 | PISTON CPL PS32CTLC |
| 58 | 325991-7 | PISTON RING 38 PS32CTLC |
| 59 | 325992-5 | PISTON PIN PS32CTLC |
| 60 | 233988-1 | PIN RING PS220CTLC |
| 61 | 213084-1 | OIL SEAL 12 PS32CTLC |
| 62 | 211341-1 | BEARING 6201 PS32CTLC |
| 63 | 212086-4 | ROLLER CAGE 810 PS32CTLC |
| 64 | 197539-3 | CRANKSHAFT PS32CTLC |
| 65 | 211341-1 | BEARING 6201 PS32CTLC |
| 66 | 213084-1 | OIL SEAL 12 PS32CTLC |
| 67 | 424872-3 | GASKET PS32CTLC |
| 68 | 318633-0 | LOWER COVER PS32CTLC |
| 69 | 168823-3 | TANK CAP PS32CTLC |
| 70 | 213080-9 | RING 29.5 PS32CTLC |
| 71 | 452629-2 | VALVE PS32CTLC |
| 72 | 266651-1 | SCREW 5.5X16 PS32CTLC |
| 73 | 234189-4 | COMPRESSION SPRING 12 PS32CTLC |
| 74 | 816917-5 | |
| 75 | 452025-4 | AIR LEVER PS32CTLC |
| 76 | 452022-0 | LEVERAGE PS32CTLC |
| 77 | 266608-2 | SCREW 5X40 PS32CTLC |
| 78 | 325946-2 | SOCKET 6 PS32CTLC |
| 79 | 234189-4 | COMPRESSION SPRING 12 PS32CTLC |
| 80 | 266651-1 | SCREW 5.5X16 PS32CTLC |
| 81 | 234189-4 | COMPRESSION SPRING 12 PS32CTLC |
| 82 | 266651-1 | SCREW 5.5X16 PS32CTLC |
| 83 | 266651-1 | SCREW 5.5X16 PS32CTLC |
| 84 | 168504-9 | VENT VALVE PS32CTLC |
| 85 | 346301-5 | HORN PS32CTLC |
| 86 | 346385-3 | INSULATION PLATE PS32CTLC |
| Pag.4 | ||
| 87 | 444029-0 | INSULATING TUBE |
| 88 | 346445-1 | SPARK PLUG CONTACT |
| 89 | 168599-2 | CMR7A-5 SPARK PLUG |
| 90 | 452670-5 | INSULATING WASHER |
| 91 | 126270-4 | COIL |
| 92 | 266631-7 | M5X20 SCREW |
| 93 | 168601-1 | CABLES |
| 94 | 266651-1 | 5.5X16 SCREW |
| 95 | 891900-3 | |
| 96 | 161328-2 | EA3201S35A BLUE CPL STARTER |
| 97 | 453783-5 | STARTER KNOBS |
| 98 | 267847-7 | SQUARE WASHER 4 |
| 99 | 444038-9 | STARTER ROPE |
| 100 | 195955-3 | REWIND SPRING |
| 101 | 455919-2 | STARTER SPOOL |
| 102 | 234253-1 | TORSION SPRING 20 |
| 103 | 453786-9 | CAM |
| 104 | 266777-9 | 5X12 SCREW |
| 105 | 452026-2 | DEFLECTOR |
| 106 | 264053-5 | M8X1 NUT |
| 107 | 267822-3 | SPRING WASHER 8 PS32CTLC |
| 108 | 140480-9 | FLYWHEEL PS32CTLC |
| 109 | 195761-6 | STARTER PAWL PS32CTLC |
| 151 | 453784-3 | SPRING COVER PS32CTLC |
| 152 | 195955-3 | REWIND SPRING PS32CTLC |
| Pag.5 | ||
| 110 | 452032-7 | HAND PROTECTION PS32CTLC |
| 111 | 810075-9 | SAFETY LABEL FOR DCS230T |
| 112 | 266627-8 | SCREW 4.7X16 PS32CTLC |
| 113 | 267066-5 | FLAT WASHER 5 X6811DW |
| 114 | 313212-9 | GUIDE PS32CTLC |
| 115 | 234210-9 | COMPRESSION SPRING 6 PS32CTLC |
| 116 | 231868-5 | TENSION SPRING 10 PS32CTLC |
| 117 | 163500-2 | LEVER PS32CTLC |
| 118 | 325947-0 | BUSH 6 |
| 119 | 346299-6 | SPACER PS32CTLC |
| 120 | 961011-9 | RETAINING RING E4 |
| 121 | 452033-5 | COVER PS32CTLC |
| 122 | 266421-8 | SCREW 3X10 HR2800 |
| 123 | 452035-1 | WORM SCREW PS32CTLC |
| 124 | 168645-1 | SUCTION PIPE PS32CTLC |
| 125 | 234207-8 | COMPRESSION SPRING 6 PS32CTLC |
| 126 | 452666-6 | OIL PIPE CAP PS32CTLC |
| 127 | 424342-2 | DElivery PIPE PS32CTLC |
| 128 | 161346-0 | OIL PUMP PS32C - EA3201S |
| 129 | 161346-0 | OIL PUMP PS32C - EA3201S |
| 130 | 266627-8 | SCREW 4.7X16 PS32CTLC |
| 131 | 267430-0 | WASHER 10 PS32CTLC |
| 132 | 267431-8 | WASHER 10 PS32CTLC |
| 133 | 168607-9 | CLUTCH PS32C-EA3201S |
| 134 | 231873-2 | TENSION SPRING 5 PS32CTLC |
| 135 | 140980-9 | CLUTCH DRUM ASSY PS32C |
| 136 | 267451-2 | WASHER 8 PS32CTLC |
| 137 | 259033-4 | SAFETY WASHER X UC |
| 138 | 347363-6 | BRAKE SPRING |
| 139 | 140A07-1 | CLUTCH SIDE CASE EA3200S |
| 140 | 199032-3 | CHAIN TENSIONER CPL |
| 141 | 213594-8 | RING 7 |
| 142 | 227744-9 | GEAR 18 |
| 143 | 227743-1 | SCREW FOR CHAIN TENSIONER 11 |
| 144 | 452667-4 | COVER |
| 145 | 346300-7 | SLIDE |
| 146 | 452668-2 | CHAIN TENSIONER PLATE EA3200S |
| 147 | 266421-8 | SCREW 3X10 HR2800 |
| 148 | 346518-0 | GUIDE PLATE PS32CTLC |
| 149 | 452044-0 | PINION CASE |
| 150 | 264055-1 | NUT M8 |
| Pag.6 | ||
| 170 | WJ00096166 | SCREW PS32CTLC |
| 171 | WJ00213750 | COVER PS32CTLC |
| 172 | WJ00096369 | IDLE SCREW PS32CTLC |
| 173 | WJ00098356 | SPRING PS32CTLC |
| 174 | WJ00096475 | SCREW PS32CTLC |
| 175 | WJ00183519 | THROTTLE LEVER PS32CTLC |
| 176 | WJ00983585 | SPRING PS32CTLC |
| 177 | WJ00223556 | THROTTLE VALVE PS32CTLC |
| 178 | WJ00098494 | SPRING PS32CTLC |
| 179 | WJ01023908 | SCREW L PS32CTLC |
| 180 | WJ01024001 | SCREW H PS32CTLC |
| 181 | WJ00098404 | SPRING PS32CRLC |
| 182 | WJ00136152 | WASHER PS32CTLC |
| 183 | WJ00016105 | RING PS32CTLC |
| 184 | WJ00062150 | CHOKE VALVE PS32CTLC |
| 185 | WJ00983270 | SPRING PS32CTLC |
| 186 | WJ00166114 | LEVER PS32CTLC |
| 187 | WJ00014477 | PIN FOR DCS230T |
| 188 | WJ00008282 | VALVE FOR DCS230T |
| 189 | WJ00963226 | SCREW PS32CTLC |
| 190 | WJ00088271 | PIVOT PS32CTLC |
| 191 | WJ00021158 | COVER FOR DCS230T |
| 192 | ZJ00000013 | DIAPHRAGM |
| 193 | 442183-4 | SEAL FOR RBL250-RBC225-25 |
| 194 | WJ00223784 | THROTTLE SHAFT PS32CTLC |
| 195 | WJ00013690 | WASHER PS32CTLC |
| 196 | WJ00016682 | LEVER PS32CTLC |
| 197 | WJ00983584 | SPRING PS32CTLC |
| 198 | WJ00001673 | RETAINING RING PS32CTLC |
| 199 | WJ00183366 | LEVER PS32CTLC |
| 200 | WJ00983164 | SPRING PS32CRLC |
| 201 | ZJ00000005 | CARBURETOR PUMP |
| 202 | WJ00088229 | PLUG PS32CTLC |
| 203 | WJ00014070 | CARBURETOR FILTER FOR DCS230T |
| 204 | WJ00343439 | VALVE PS32CTLC |
| 205 | WJ00009589 | PUMP DIAPHRAGM PS32CTLC |
| 206 | WJ00092225 | GASKET PS32CTLC |
| 207 | WJ00096589 | SCREW PS32CTLC |
| 208 | WJ00096475 | SCREW PS32CTLC |
| 209 | WJ00096475 | SCREW PS32CTLC |
| 210 | WJ00096475 | SCREW PS32CTLC |
| 211 | WJ00001673 | RETAINING RING PS32CTLC |
| Pag.7 | ||
| A01 | 165246-6 | GUIDE BAR 14 |
| A02 | 419559-0 | CHAIN PROTECTION COVER 330 |
| A03 | 511291752 | SAW CHAIN 3/8LP 0.43" L52 CC D |
| A04 | 196741-5 | SAW CHAIN SET |
| A05 | 782026-1 | UNIVERSAL WRENCH 13/16 |
| A06 | 783012-5 | SCREWDRIVER |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
