Makita Cordless Chainsaw UC015G Parts
€42.85
Tax included
Makita Cordless Chainsaw UC015G Spare Parts
Fix Your Cordless Chainsaw UC015G. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Makita Cordless Chainsaw UC015G Spare Parts
Fix Your Cordless Chainsaw UC015G. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following table, look for the model of the Cordless Chain Saw and the respective parts of the code.
| MAKITA UC015G 350MM CORDLESS CHAIN SAW Spare Parts | ||
| # | Parts Num. | Description |
| 001 | 327932-9 | FRONT HANDLE |
| 002 | 911218-7 | PAN HEAD SCREW M5X14 |
| 003 | 911218-7 | PAN HEAD SCREW M5X14 |
| 004 | 122A77-2 | TANK CAP ASSEMBLY |
| D10 | INC. 5 | |
| 005 | 213080-9 | O RING 29.5 |
| 006 | 422835-3 | OIL TUBE 3-117 |
| 007 | 266326-2 | TAPPING SCREW 4X18 |
| 008 | 142857-4 | OIL PUMP COMPLETE |
| 009 | 961011-9 | STOP RING E-4 |
| 010 | 226884-0 | WORM GEAR |
| 011 | 422836-1 | OIL TUBE 3-108 |
| 012 | 231975-4 | SPRING |
| 013 | 452666-6 | NIPPLE |
| 014 | 911228-4 | PAN HEAD SCREW M5X18 |
| 015 | 413C89-1 | MOTOR HOUSING |
| 016 | 620H71-5 | CONTROLLER |
| 016-1 | 620P46-2 | CONTROLLER |
| 017 | 266490-9 | TAPPING SCREW PT 2X6 |
| 018 | 687B69-9 | STOPPER |
| 019 | 620H75-7 | CONTROLLER B |
| 020 | 652031-1 | PAN HEAD SCREW M3X6 |
| 021 | 629B00-9 | STATOR |
| 022 | 632T19-7 | LEAD UNIT |
| 023 | 413C90-6 | BAFFLE PLATE |
| 024 | 266326-2 | TAPPING SCREW 4X18 |
| 025 | 210016-9 | BALL BEARING 698ZZ |
| 026 | 519732-3 | ROTOR ASS'Y |
| D10 | INC. 25,27 | |
| 026-1 | 519732-3 | ROTOR ASS'Y |
| D10 | INC. 25,27 | |
| 027 | 210059-1 | BALL BEARING 6000DDW |
| 028 | 911118-1 | PAN HEAD SCREW M4X12 |
| 029 | 413C92-2 | FRONT HAND GUARD RETAINER |
| 030 | 213594-8 | O RING 7 |
| 031 | 141J69-6 | FRONT HAND GUARD COMPLETE |
| C10 | 8050E6-6 | CAUTION LABEL |
| 033 | 136612-4 | HOUSING BASE ASSEMBLY |
| C10 | 263002-9 | RUBBER PIN 4 |
| 034 | 313398-9 | HAND GUARD GUIDE |
| 035 | 234210-9 | COMPRESSION SPRING 3 |
| 036 | 413D07-5 | GUARD A |
| 037 | 422834-5 | GROMMET A |
| 038 | 413D08-3 | GUARD B |
| 039 | 347924-2 | CHAIN CATCHER |
| 040 | 266034-5 | TAPPING SCREW CT 4X16 |
| 041 | 347925-0 | SPIKE BUMPER |
| 042 | 266034-5 | TAPPING SCREW CT 4X16 |
| 045 | 227496-2 | STRAIGHT BEVEL GEAR 14 |
| 046 | 326310-0 | ADJUST PIN |
| 047 | 327958-1 | ADJUST SCREW |
| 048 | 413F29-7 | COVER |
| 049 | 266427-6 | TAPPING SCREW 4X12 |
| 049-1 | 265C54-4 | TAPPING SCREW 4X12 |
| 050 | 141E60-4 | LINK PLATE COMPLETE |
| 051 | 232452-9 | COMPRESSION SPRING 7 |
| 052 | 347922-6 | BRAKE BAND COMPLETE |
| 053 | 213060-5 | O RING 10 |
| 054 | 162979-4 | BRAKE DRUM |
| 055 | 191V91-5 | SPROCKET 7 SET |
| 056 | 961013-5 | STOP RING E-7 |
| 057 | 413C95-6 | BRAKE COVER |
| 058 | 266034-5 | TAPPING SCREW CT 4X16 |
| 059 | 413C88-3 | BATTERY COVER |
| 060 | 8117L7-5 | UC015G NAME PLATE |
| 061 | 136689-9 | HOUSING L ASSEMBLY |
| D10 | INC. 59,62 | |
| 061-1 | 137024-4 | HOUSING L ASSEMBLY |
| D10 | INC. 59,62 | |
| 062 | 266326-2 | TAPPING SCREW 4X18 |
| 063 | 266326-2 | TAPPING SCREW 4X18 |
| 064 | 620J22-0 | SWITCH CIRCUIT COMPLETE |
| C10 | 810D46-0 | SWITCH LABEL |
| 065 | 232733-1 | TORSION SPRING 10 |
| 065-1 | 232850-7 | TORSION SPRING 10 |
| 066 | 413C94-8 | CATCH LEVER |
| 066-1 | 141V01-2 | LOCK OFF LEVER COMPLETE |
| 067 | 650024-2 | SWITCH C3JR-4B-PAND4-1 |
| 068 | 632T50-3 | SWITCH UNIT |
| 069 | 413C93-0 | SWITCH LEVER |
| 070 | 632L49-0 | SWITCH UNIT |
| 071 | 8117M0-6 | UC015G SERIAL NO. LABEL |
| 072 | 632T07-4 | TERMINAL UNIT |
| 073 | 652031-1 | PAN HEAD SCREW M3X6 |
| 074 | 266326-2 | TAPPING SCREW 4X18 |
| 075 | 266326-2 | TAPPING SCREW 4X18 |
| 076 | 183V16-3 | TERMINAL BOX SET |
| C10 | 263005-3 | RUBBER PIN 6 |
| 080 | 911228-4 | PAN HEAD SCREW M5X18 |
| 081 | 136674-2 | HOUSING R ASSEMBLY |
| C10 | 8025F3-0 | XGT LOGO LABEL |
| 081-1 | 137216-5 | HOUSING R ASS'Y |
| C10 | 8025F3-0 | XGT LOGO LABEL |
| 084 | 413F27-1 | GUARD C |
| 085 | 413F28-9 | GUARD D |
| 086 | 422833-7 | GROMMET |
| 087 | 422832-9 | CHIP GUIDE |
| 088 | 413F26-3 | INNER COVER |
| 089 | 266427-6 | TAPPING SCREW 4X12 |
| 089-1 | 265C54-4 | TAPPING SCREW 4X12 |
| 090 | 266427-6 | TAPPING SCREW 4X12 |
| 090-1 | 265C54-4 | TAPPING SCREW 4X12 |
| 091 | 413F24-7 | SPROCKET COVER |
| 092 | 142235-8 | NUT COMPLETE |
| 093 | 413F25-5 | NUT COVER |
| 094 | 263002-9 | RUBBER PIN 4 |
| 095 | 142665-3 | DRIVE GEAR COMPLETE |
| 096 | 183W23-2 | SPROCKET COVER SET |
| D10 | INC. 45-49,84-95 | |
| A01 | 191T87-4 | GUIDE BAR 14 SET |
| A02 | 419288-5 | CHAIN COVER |
| A02-1 | 419288-5 | CHAIN COVER |
| A03 | 199897-3 | OIL VESSEL SET |
| A04 | 191T91-3 | SAW CHAIN 14 SET |
| A05 | 782023-7 | WRENCH 13-16 |
| A07 | 412393-7 | BATTERY COVER |
| A08 | ***DC40RA | DC40RA FAST CHARGER |
| D10 | COMPO-PARTS | |
| A09 | 191B36-3 | BATTERY BL4025 SET |
| E01 | 8050E9-0 | SOUND LABEL |
| F01 | 191G24-0 | GUIDE BAR 14 SET |
| F02 | 191G25-8 | GUIDE BAR 16 SET |
| F03 | 191G26-6 | GUIDE BAR 18 SET |
| F04 | 191H11-5 | SAW CHAIN 14 SET |
| F05 | 191H12-3 | SAW CHAIN 16 SET |
| F06 | 191H13-1 | SAW CHAIN 18 SET |
| F13 | 191V90-7 | SPROCKET 6 SET |
| F14 | 191V91-5 | SPROCKET 7 SET |
| F17 | 195093-1 | CHAIN OIL SET |
| F18 | 198457-8 | CHAIN EDGER SET |
| F18-1 | D-70948 | FILE HOLDER SET 4.0MM(5/32") |
| A09 | 191L47-8 | BATTERY BL4050F SET |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
