Makita UH6580 Hedge Trimmer Parts

€8.90
Tax included

Makita UH6580 Corded Hedge Trimmer Spare Parts

Makita genuine spare parts or replacement parts for to repair Makita UH6580 240v Corded Hedge Trimmer.
ITEM CODE: 450444-8
Quantity
Usually Ships in: 7/10 Business Days Approx.

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Makita UH6580 Corded Hedge Trimmer Spare Parts

Makita genuine spare parts or replacement parts for to repair Makita UH6580 240v Corded Hedge Trimmer.

In the following table, look for the model of the Trimmer and the respective parts of the code.
Makita Electric Hedge Trimmer UH6580

MAKITA UH6580 - HEDGE TRIMMER 650MM 670w
# Part Num. Description
1 450444-8 SWITCH LEVER B
2 233157-4 COMPRESSION SPRING 9
3 450442-2 FRONT GRIP
4 158629-7 PROTECTOR COMPLETE X UH5570
4-1 141J42-6 PROTECTOR COMPLETE
4-2 1410D7-6 PROTECTOR COMPLETE
C10 8074L2-3 CAUTION LABEL
5 265995-6 TAPPING SCREW 4X18
6 911253-5 PAN HEAD SCREW M5X30
8 188569-5 HOUSING SET
9 417740-7 INSULATION CAP
10 233288-9 COMPRESSION SPRING 8
11 268077-3 PIN 5
12 417727-9 CAP HOLDER
13 417736-8 LIFTER
14 417735-0 PUSHER CAP
15 268078-1 PIN 3
16 417781-3 PIN HOLDER
17 233156-6 COMPRESSION SPRING 5
18 257934-0 STOP RING E-4
19 417737-6 LINK
20 417739-2 ROD
21 233156-6 COMPRESSION SPRING 5
22 417731-8 SWITCH LEVER C
23 265995-6 TAPPING SCREW 4X18
24 687063-9 CORD CLAMP
25 450443-0 SWITCH LEVER A
26 233156-6 COMPRESSION SPRING 5
27 417738-4 LEVER
28 643936-6 BRUSH HOLDER
29 191962-4 CARBON BRUSH CB-419
30 594578-8 FIELD ASS'Y 220-240V
C10 654069-2 RECEPTACLE
30-1 599126-8 FIELD ASSY 220-240V
C10 654069-2 RECEPTACLE
31 211032-4 BALL BEARING 608ZZ
32 516499-4 ARMATURE ASS'Y 220-240V
33 241858-0 FAN 70
34 211062-5 BALL BEARING 60ZZ
35 650522-6 SWITCH
35-1 650593-3 SWITCH
36 645185-1 NOISE SUPPRESSOR
36-1 645105-5 NOISE SUPPRESSOR
37 654531-7 TERMINAL BLOCK 2P
38 666246-4 POWER SUPPLY CORD 1.5-2-0.3
39 682503-2 CORD GUARD 8-90
40 265995-6 TAPPING SCREW 4X18
41 450445-6 TOP COVER
42 188569-5 HOUSING SET
43 865786-1 UH6580 NAME PLATE
44 265995-6 TAPPING SCREW 4X18
45 318257-2 GEAR HOUSING
46 135217-7 GEAR ASS'Y
47 443142-1 DUST GUARD
48 194673-0 SHEAR BLADE ASS'Y SET
C10 252184-2 HEX.LOCK NUT M5-8
C20 257717-8 SLEEVE 5
C30 265181-9 +TRUSS HEAD SCREW M5X20
C40 345205-8 BRANCH CATCHER
C50 911208-0 PAN HEAD SCREW M5X10
C60 188605-7 OIL VESSEL SET
49 263002-9 RUBBER PIN 4
50 318265-3 GEAR HOUSING COVER
51 265182-7 + PAN HEAD SCREW M5X25
52 450440-6 UNDER COVER
53 911148-2 PAN HEAD SCREW M4X25
A1 194677-2 CORD HOLDER COMPLETE SET
A2 158024-1 HOOK COMPLETE
A3 450490-1 BLADE COVER
F4 194679-8 ARM BAND COMPLETE SET
F5 194681-1 CHIP RECEIVER ASS'Y SET
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
