Makita Battery Grass Trimmer UR101CZ Spare Parts
€90.31
Tax included
Makita Battery Powered Grass Trimmer UR101CZ Spare Parts
We have the original Spares MAKITA for Battery Powered Grass Trimmer UR101CZ, the Repair information, Exploded Diagram, parts list and tool repair that help you need to get your tools running like new again.Fix Your Battery Powered Grass Trimmer UR101CZ. All Spares our Spares are Genuine Parts.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Makita Battery Powered Grass Trimmer UR101CZ Spare Parts
We have the original Spares MAKITA for Battery Powered Grass Trimmer UR101CZ, the Repair information, Exploded Diagram, parts list and tool repair that help you need to get your tools running like new again.
Fix Your Battery Powered Grass Trimmer UR101CZ. All Spares are original and can be supplied at Cheap and discounted prices. Our Spares are Genuine Parts Guaranteed.
In the following table, look for the model of the Cordless Brushcutter and the respective parts of the code.
| UR101CZ BATTERY POWERED GRASS TRIMMER 43CM18VX2 BL X | ||
| # | Part Num. | Description |
| 001 | 123853-1 | GEAR CASE ASSEMBLY |
| 002 | 265590-2 | +HEX.BOLT M8X10 WITH R |
| 003 | 232350-7 | RING SPRING 6 |
| 004 | 210030-5 | BALL BEARING 627ZZ |
| 005 | 221484-1 | SPIRAL BEVEL GEAR 19 |
| 006 | 136233-2 | CUTTER SHAFT ASS'Y |
| 007 | 211228-7 | BALL BEARING 6202DDW |
| 008 | 257432-4 | RETAINING RING R-35 |
| 009 | 144312-2 | RECEIVE WASHER COMPLETE |
| 010 | 347104-0 | CLAMP WASHER |
| 011 | 457274-8 | CUP US |
| 012 | 252236-9 | HEX. LOCK NUT M10-17 |
| 013 | 136235-8 | SPIRAL BEVEL GEAR ASS'Y |
| 014 | 210049-4 | BALL BEARING 609ZZ |
| 015 | 257986-1 | RETAINING RING (EXT) S-9 |
| 016 | 257987-9 | RETAINING RING (INT)R-24 |
| 017 | 922216-6 | HEX. SOCKET HEAD BOLT M5X14 |
| 018 | 922242-5 | HEX. SOCKET HEAD BOLT M5X25 |
| 019 | 251513-6 | H.S.H.BOLT M5X25 |
| 020 | 347107-4 | PROTECTOR CLAMP 24 |
| 021 | 922216-6 | HEX. SOCKET HEAD BOLT M5X14 |
| 022 | 191B54-1 | PROTECTOR U 430 SET MG |
| 024 | 144316-4 | PROTECTOR U EXT. 420-450 COMP |
| 024 | 346696-6 | HOOK |
| 025 | 459765-5 | CUTTER EXTENSION |
| 026 | 347115-5 | CUTTER |
| 027 | 266459-3 | TAPPING SCREW 5X25 |
| 028 | 140J61-9 | HANDLE 22 COMPLETE |
| 029 | 168796-0 | KNOB 57 |
| 030 | 144313-0 | UPPER HANDLE HOLDER COMPLETE |
| 030 | 263005-3 | RUBBER PIN 6 |
| 031 | 319517-5 | LOWER HANDLE HOLDER |
| 032 | 233309-7 | COMPRESSION SPRING 17 |
| 033 | 319959-3 | PIPE HOLDER |
| 034 | 318426-5 | PIPE CLAMP |
| 035 | 922241-7 | HEX. SOCKET HEAD BOLT M5X25 |
| 036 | 140S82-5 | SHAFT PIPE COMPLETE I |
| 036 | 819312-8 | MAKITA LOGO LABEL |
| 036 | 819J22-7 | CAUTION LABEL |
| 037 | 327056-1 | SHAFT |
| 038 | 412305-0 | PIPE HOLDER 24 |
| 039 | 183L60-0 | GRIP SET |
| 039 | 252180-0 | HEX. LOCK NUT M5-8 |
| 040 | 140K36-4 | INDICATION CIRCUIT COMPLETE G |
| 041 | 140W06-5 | SWITCH CIRCUIT COMPLETE G |
| 041 | 819J26-9 | SWITCH LABEL |
| 042 | 651436-2 | SWITCH C3JW-1A-P-2 |
| 043 | 233540-5 | TORSION SPRING 11 |
| 044 | 459145-5 | SWITCH LEVER |
| 045 | 233101-1 | COMPRESSION SPRING 4 |
| 046 | 459146-3 | LOCK OFF LEVER |
| 047 | 183L60-0 | GRIP SET |
| 047 | 252180-0 | HEX. LOCK NUT M5-8 |
| 048 | 699132-4 | POWER SUPPLY CORD UNIT |
| 049 | 687260-7 | STRAIN RELIEF |
| 050 | 266326-2 | TAPPING SCREW 4X18 |
| 051 | 266326-2 | TAPPING SCREW 4X18 |
| 052 | 911258-5 | PAN HEAD SCREW M5X35 |
| 053 | 232589-2 | TORSION SPRING 12 |
| 054 | 183N86-4 | CONNECTOR HOLDER SET |
| 055 | 266511-7 | + FLAT FILLISTER HEAD SCREW M5 |
| 056 | 699146-3 | POWER SUPPLY CORD UNIT |
| 057 | 183N86-4 | CONNECTOR HOLDER SET |
| 058 | 266429-2 | TAPPING SCREW 3X16 |
| 059 | 922244-1 | H.S.H.BOLT M5X25 WITH WG |
| 060 | 412302-6 | CORD HOLDER |
| 061 | 457458-8 | CLAMP |
| 062 | 457458-8 | CLAMP |
| 063 | 319919-5 | PIPE BRACKET |
| 064 | 911233-1 | PAN HEAD SCREW M5X20 |
| 065 | 263002-9 | RUBBER PIN 4 |
| 066 | 325811-5 | SPINDLE HUB |
| 067 | 211131-2 | BALL BEARING 6001DDW |
| 068 | 226931-7 | HELICAL GEAR 29 |
| 069 | 211150-8 | BALL BEARING 6901ZZ |
| 070 | 266459-3 | TAPPING SCREW 5X25 |
| 071 | 136231-6 | GEAR BOX ASS'Y |
| 072 | 213961-7 | O RING 22 |
| 073 | 226932-5 | HELICAL GEAR 10 |
| 074 | 210005-4 | BALL BEARING 608DDW |
| 075 | 519587-6 | ROTOR ASS'Y |
| 076 | 210062-2 | BALL BEARING 607ZZ |
| 077 | 266326-2 | TAPPING SCREW 4X18 |
| 078 | 459764-7 | BAFFLE PLATE |
| 079 | 266326-2 | TAPPING SCREW 4X18 |
| 080 | 687124-5 | STRAIN RELIEF |
| 081 | 687051-6 | STRAIN RELIEF |
| 082 | 183N25-4 | HOUSING COVER SET |
| 083 | 183N71-7 | HOUSING SET |
| 084 | 687149-9 | STRAIN RELIEF |
| 085 | 266326-2 | TAPPING SCREW 4X18 |
| 086 | 459763-9 | MOTOR HOUSING |
| 087 | 620C66-8 | CONTROLLER |
| 088 | 629471-8 | STATOR |
| 089 | 347620-2 | PIASTRA |
| 090 | 911102-6 | VITE M4X6 |
| 091 | 183N25-4 | HOUSING COVER SET |
| 092 | 266326-2 | TAPPING SCREW 4X18 |
| 093 | 922211-6 | H.S.H.BOLT M5X12 WITH W |
| 094 | 922233-6 | H.S.H.BOLT M5X20 WITH WR |
| 095 | 183N71-7 | HOUSING SET |
| 096 | 266326-2 | TAPPING SCREW 4X18 |
| 097 | 856S03-4 | UR101C NAME PLATE |
| 099 | 922211-6 | H.S.H.BOLT M5X12 WITH W |
| 100 | 922233-6 | H.S.H.BOLT M5X20 WITH WR |
| A01 | 782238-6 | BOX WRENCH 17 |
| A02 | 783202-0 | HEX. WRENCH 4 |
| A03 | 197243-4 | BAND ASSEMBLY SET |
| A04 | 831304-7 | ACCESSORY BAG |
| A05 | 198345-9 | CUTTER BLADE 255-2 SET ME |
| A06 | 144392-8 | TOOL COVER 2T |
| A07 | 197804-0 | TRIMMER HEAD 95-M10L SET M |
| A08 | 198384-9 | PLASTIC BLADE 255 SET M |
| A09 | 195246-2 | SAFETY GOGGLE |
