Makita Spare Parts for Backpack Brusch Cutter EM4350RH
€31.72
Tax included
Makita Spare Parts for Backpack Brusch Cutter EM4350RH
We are MAKITA original spare parts Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Backpack Brusch Cutter EM4350RH.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Makita Spare Parts for Backpack Brusch Cutter EM4350RH
We are MAKITA original spare parts Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Backpack Brusch Cutter EM4350RH.
In the following table, look for the model of Brusch Cutter and the respective parts of the code.
| Makita EM4350RH 4-stroke Petrol Backpack Brush Cutter Spare Parts pag.1 | ||
| # | Part Num. | Description |
| 1 | 166136-6 | BAG X EM4350RH |
| 2 | 126513-4 | BAND ASSEMBLY EM4350RH |
| 3 | 165752-1 | FRAME X EM4350RH |
| 4 | 455305-7 | SPRING holder A EM4350RH |
| 5 | 922228-9 | HEX BOLT M5X18 EM2651LH/RBH253 -+ EBH341U |
| 6 | 234346-4 | COMPRESSION SPRING 17 |
| 7 | 455306-5 | SPRING holder B |
| 8 | 319181-2 | bracket EM4350RH |
| 9 | 922228-9 | HEX BOLT M5X18 EM2651LH/RBH253 - EBH341U |
| 10 | 922312-0 | CAP HD SCREW M6X12 2414B |
| 11 | 346816-2 | BEARING BOX X EM4350RH |
| 12 | 211220-3 | ball BEARING 6202ZZ |
| 13 | 941251-5 | FLAT WASHER 10 |
| 14 | 921541-2 | HEX BOLT M10X25 |
| Makita EM4350RH 4-stroke Petrol Backpack Brush Cutter Spare Parts pag.2 | ||
| 15 | 417764-3 | holder 10-33 X EM4350RH |
| 16 | 126510-0 | FLEXIBLE SHAFT ASSEMBLY EM4350RH |
| 17 | 196897-4 | LOOP HANDLE SET EM4350RH |
| 18 | 922244-1 | H.S.H.BOLT M5X25 WITH WG |
| 19 | 455316-2 | CLAMP COVER EM4350RH |
| 20 | 346468-9 | CLAMP 33 BUX360Z |
| 21 | 455315-4 | LOOP HANDLE EM4350RH |
| 22 | 346817-0 | CLAMP 28 EM4350RH |
| 23 | 424646-2 | PIPE HOLDER COVER EM4350RH |
| 24 | 319182-0 | PIPE HOLDER EM4350RH |
| 25 | 326436-8 | SPINDLE EM4350RH |
| 26 | 211148-5 | BALL BEARING 6001LLB - GD0800C |
| 27 | 961052-5 | EXT DIN 471 CIRCLIP-12 |
| 28 | 961108-4 | INTERNAL RETAINING RING-2* |
| 29 | 922248-3 | H.S.H.BOLT M5X28 WITH WR |
| 30 | 922352-8 | HEX. SOCKET HEAD BOLT M6X30 |
| 31 | 922212-4 | CAP HD SCREW M5X12 |
| 32 | 326447-3 | FLEXIBLE SHAFT |
| 33 | 455304-9 | GUARD |
| 34 | 922228-9 | HEX BOLT M5X18 EM2651LH/RBH253 |
| 40 | 443146-3 | FELT RING 8 EBH341U |
| 44 | 142838-8 | SHAFT PIPE COMPLETE EM4350RH |
| 45 | 326574-6 | TRANSMISSION SHAFT EM4350RH |
| 46 | 413143-3 | WASHER MS335.4C |
| 47 | 452259-9 | PROTECTOR EBH341U |
| 48 | 266326-2 | TAPPING SCREW M4X18 BHR2* |
| 49 | 347050-7 | CUTTER EM2651LH/EBH253L/341U |
| 50 | 135753-3 | PROTECTOR EXTENSION ASSY |
| 51 | 346072-4 | PROTECTOR CLAMP EBH341U - EBH341U |
| 52 | 451090-0 | PROTECTOR COVER EBH341U |
| 53 | 266280-0 | HEX SOCKET HD BOLT M6X30 EBH |
| 54 | 266865-2 | H.S.H.BOLT M5X14 WITH WR |
| 55 | 123835-3 | GEAR CASE ASSEMBLY |
| 56 | 213459-4 | O RING 32 DA4031/4157KB/5903R - HR3850B |
| 57 | 183K07-8 | CUTTER SHAFT SET |
| 58 | 210059-1 | BALL BEARING 6000 HR2010 |
| 59 | 211062-5 | BALL BEARING 6000 X9524NB |
| 60 | 961006-2 | EXT DIN 471 CIRCLIP-10* |
| 61 | 962105-3 | INTERNAL RETAINING RING |
| 62 | 922353-6 | CAP HD SCREW M6X30 - HM1202C |
| 63 | 265590-2 | HEX BOLT M8x10 EBH253L/EBH341U |
| 64 | 210081-8 | BALL BEARING 629ZZ EBH341U |
| 68 | 210116-5 | BALL BEARING 6201LLU EBH341U |
| 69 | 962151-6 | RETAINING RING R-32 BPJ141/81 |
| 70 | 332114-0 | RECEIVE WASHER - EM4350RH |
| 71 | 346355-2 | CLAMP WASHER |
| 72 | 168526-9 | CUP EBH253L/EBH341L&U/BBC231URD |
| 73 | 264025-0 | HEX NUT M10-17 EBH251U.BBC231 |
| 307 | 455588-9 | WIRE CLAMP |
| Makita EM4350RH 4-stroke Petrol Backpack Brush Cutter Spare Parts pag.3 | ||
| 32 | 126512-6 | CONTROL LEVER ASSEMBLY - EM4350RH |
| 81 | 266130-9 | TAPPING SCREW BIND 3X 16 - 6203/13 / 6313DW |
| 82 | 451595-0 | SWITCH COVER MS335.4C |
| 83 | 451594-2 | SWITCH LEVER MS335.4C |
| 84 | 232251-9 | LEAF SPRING EBH341U |
| 85 | 188831-8 | LEVER CASE SET MS335.4C |
| 86 | 346249-1 | PIPE CLAMP 28 MS335.4C |
| 87 | 922218-2 | HEX BOLT M5X14 ER2550/EBH341U |
| 88 | 451593-4 | LOCK LEVER MS335.4C |
| 89 | 233541-3 | TORSION SPRING 7 EBH341U |
| 90 | 168871-2 | CONTROL CABLE EM4350RH |
| 91 | 233540-5 | TORSION SPRING 11 EBH341U |
| 92 | 451592-6 | THROTTLE LEVER MS335.4C |
| 93 | 632D64-6 | LEAD UNIT EM4350RH |
| 94 | 632D65-4 | LEAD UNIT EM4350RH |
| 95 | 455311-2 | CORRUGATE TUBE EM4350RH |
| 96 | 266326-2 | TAPPING SCREW M4X18 BHR2* MT601 |
| Makita EM4350RH 4-stroke Petrol Backpack Brush Cutter Spare Parts pag.4 | ||
| 101 | 922233-6 | HEX SOCKET HD BOLT M5X20 DCS23 - DCS230T |
| 102 | 424302-4 | PLUG CAP ER2650LH/2651LH - EH7500S |
| 103 | 455103-9 | CYLINDER COVER BLUE |
| 104 | 922233-6 | HEX SOCKET HD BOLT M5X20 DCS23 - DCS230T |
| 105 | 453536-2 | MUFFLER COVER X EM4351UH |
| 106 | 265995-6 | PT SCREW 4X18 KP0810C* |
| 107 | 922332-4 | HEX. SOCKET HEAD BOLT M6X20 - SC161 |
| 108 | 168715-6 | EXHAUST MUFFLER EM4351UH |
| 109 | 346574-0 | MUFFLER GASKET EM4351UH |
| 110 | 331987-8 | EXHAUST PORT SPACER EM4351UH |
| 111 | 922226-3 | HEX SOCKET HD BOLT M5X18 EBH25 4341FCT |
| 112 | 318850-2 | ROCKER COVER OUTER EM4351UH |
| 113 | 422091-5 | TUBE 5-160 EM4351UH |
| 114 | 454424-6 | CORRUGATE TUBE EM4351UH |
| 115 | 453529-9 | ROCKER COVER INNER EM4351UH |
| 116 | 162335-8 | ROCKER COVER GASKET EM4351UH |
| 117 | 324891-8 | PLUG CAP SPRING ER2650LH/BHX25 EBH341 |
| 118 | 0650109950 | SPARK PLUG CMR6A X MS251.A |
| 119 | 422090-7 | TUBE 3-85 X EM4351UH |
| 120 | 452049-0 | SPACER EX2650LH |
| 121 | 197493-1 | CYLINDER BLOCK ASSEMBLY SET EM4350RH |
| 122 | 424200-2 | SPACKER ER2650LH/EM2651LH EBH341U |
| 123 | 424201-0 | CHECK VALVE ER2650LH/EBH251L EBH341U |
| 124 | 922342-1 | CAP HD SCREW M6X25 BUX360* EX2650LH |
| 125 | 422099-9 | PIPE EX2650LH |
| 126 | 282020-8 | HOSE CLAMP ER2650LH/EM2651LH EBH341U |
| 127 | 424301-6 | OIL TUBE EX2650LH |
| 129 | 162337-4 | OIL VASE GASKET EM4351U |
| 130 | 266760-6 | H.S.H.BOLT M5X18 WITH WRM |
| 131 | 452047-4 | OIL TANK CAP X BHX2501 |
| 132 | 424343-0 | GASKET X BHX2501 |
| 133 | 453538-8 | OIL PIPE EM4351UH |
| 134 | 162338-2 | OIL PIPE GASKET EM4351UH |
| 135 | 318854-4 | OIL CASE EM4351UH |
| 136 | 922226-3 | HEX SOCKET HD BOLT M5X18 EBH25 4341FCT |
| 137 | 346305-7 | GASKET EX2650LH |
| 138 | 266611-3 | HEX BOLT M6X8 EM2651LH/ER2650L EX2650LH |
| 139 | 346398-4 | LEAD VALVE EM4351UH |
| 140 | 135638-3 | RETAINER PLATE ASS'Y EM4350RH |
| 141 | 922226-3 | HEX SOCKET HD BOLT M5X18 EBH25 4341FCT |
| 143 | 168876-2 | TUBE COMPLETE EM4350RH |
| 144 | 412129-4 | TUBE 3-105 X EM4350RH |
| 145 | 163518-3 | GASOLINE FILTER EX2650LH |
| 146 | 282020-8 | HOSE CLAMP EBH341U |
| 148 | 123632-7 | ROPE ASSEMBLY |
| 149 | 126524-9 | STARTER COVER ASSEMBLY EM4350RH |
| 150 | SG00000029 | SCREW 6X12 |
| 151 | 455433-8 | CAM PLATE EM4350RH |
| 152 | SG00000028 | REEL COMPLETE EM4350RH |
| 153 | SG00000014 | SPIRAL SPRING EM4351UH |
| 154 | 454522-6 | STARTER GRIP EA3600F |
| 156 | SG00000031 | STARTER ROPE EM4350RH |
| 157 | 455423-1 | STARTER COVER EM4350RH |
| 158 | 922233-6 | HEX SOCKET HD BOLT M5X20 DCS23 DCS230T |
| 159 | 424673-9 | GUARD EM4350RH |
| 160 | 126116-4 | ROCKER ARM ASSEMBLY EM4351UH |
| 161 | 331990-9 | COTTER EM4351UH |
| 162 | 331991-7 | RETAINER EM4351UH |
| 163 | 234238-7 | COMPRESSION SPRING 11 |
| 164 | 256200-2 | PIN 5 2704 |
| 165 | 256866-8 | ROD 2.5 EBH341U |
| 166 | 268238-5 | PIN 5 EBH341U |
| 167 | 313236-5 | CAM LIFTER EM4351UH |
| 168 | 256186-0 | PIN 5 MS43 ** / EM43 ** |
| 169 | 126571-0 | CAM GEAR |
| 170 | 261127-3 | TEFLON WASHER 10 X PW5000CH |
| 171 | 326575-4 | EXHAUST VALVE X EM4351UH |
| 172 | 326157-2 | INTAKE VALVE EM4351UH |
| 173 | 196667-1 | PISTON RING SET |
| 174 | 233983-1 | CLIP EBH341 |
| 175 | 197455-9 | PISTON CPL |
| 176 | 268285-6 | PISTON PIN EM4351UH |
| 177 | 213685-5 | OIL SEAL 12 X EM4351UH |
| 178 | 126121-1 | CRANKSHAFT ASSEMBLY EM4351UH |
| 179 | 254040-2 | WOODRUFF KEY 3 ER2650LH/EM2651 - EBH341U |
| 180 | 267425-3 | FLAT WASHER 26 EBH341U |
| 181 | 213537-0 | OIL SEAL 12 EBH341U |
| 182 | 266086-6 | HEX BOLT M5X16 JR3020 |
| 183 | 318856-0 | CAM GEAR COVER EM4351UH |
| 184 | 162334-0 | CAM GEAR COVER GASKET EM4351UH |
| 185 | 632D66-2 | LEAD UNIT EM4350RH |
| 186 | 632D67-0 | LEAD UNIT EM4350RH |
| 187 | 444021-6 | TUBE EX2650LH |
| 188 | 168714-8 | IGNITION COIL EM4351UH |
| 189 | 266602-4 | HEX SOCKET HD BOLT M4X2 EM2651 EX2650LH |
| 190 | 126122-9 | FLYWHEEL COMPLETE EM4351UH |
| 191 | 264039-9 | FLANGE NUT EX2650LH |
| 192 | 127112-5 | FUEL TANK CAP ASSY |
| 195 | 424081-4 | BUFFER RUBBER ER2650LH/RBX260L - DBC260U |
| 198 | 922233-6 | HEX SOCKET HD BOLT M5X20 DCS23 DCS230T |
| 199 | 261152-4 | RUBBERWASHER 8 |
| 200 | 331988-6 | SPACER X EM4351UH |
| 201 | 455308-1 | FUEL TANK EM4350RH |
| 202 | 922332-4 | HEX. SOCKET HEAD BOLT M6X20 SC161 |
| 203 | 319180-4 | CLUTCH CASE EM4350RH |
| 204 | 266597-1 | SHOULDER HEX. BOLT M8 |
| 205 | 267832-0 | WAVE WASHER 10 EBH341U |
| 206 | 313238-1 | CLUTCH SHOE EM4351UH |
| 207 | 232290-9 | TENSION SPRING 5 X EM4351UH |
| 208 | 267428-7 | FLAT WASHER 8 |
| 209 | 313239-9 | CLUTCH BASE EM4351UH |
| 210 | 346576-6 | FAN PLATE EM4351UH |
| 211 | 266461-6 | H.S.BUTTON HEAD SCREW M5X8 AT450H |
| 212 | 453530-4 | MUFFLER PLATE EM4351UH |
| 213 | 266760-6 | H.S.H.BOLT M5X18 WITH WRM |
| 214 | 345918-1 | HOSE CLAMP ER2550/ER2650LH - EBH341U |
| 288 | 455102-1 | CHANGE PLATE |
| 289 | 266385-6 | TAPPING SCREW 4X14 GA9020S |
| 295 | 455317-0 | CORRUGATE TUBE EM4350RH |
| 296 | 168857-6 | CLUTCH DRUM X EM4350RH |
| 297 | 424659-3 | KNOB COVER EM4350RH |
| 298 | 168873-8 | KNOB BOLT COMPLETE |
| 299 | 922228-9 | HEX BOLT M5X18 EM2651LH/RBH253 EBH341U |
| 300 | 455307-3 | CLUTCH CASE COVER EM4350 |
| 301 | 961057-5 | EXT DIN 471 CIRCLIP-17 |
| 302 | 210126-2 | BALL BEARING 6003LLU |
| 303 | 962153-2 | RETAINING RING R-35 HP1631/415 |
| 304 | 911209-8 | PAN HEAD SCREW M5X10 |
| 305 | 455310-4 | UNDER COVER EM4350RH |
| 306 | 424556-3 | FILTER CAP |
| Makita EM4350RH 4-stroke Petrol Backpack Brush Cutter Spare Parts pag.5 | ||
| 215 | 126523-1 | CLEANER COVER ASSEMBLY EM4350RH |
| 216 | 266743-6 | HEX.SOCKET HEAD BOLT M5X20 |
| 218 | 442181-8 | AIR CLEANER ELEMENT EM4351UH |
| 219 | 266601-6 | HEX. SOCKET HEAD BOLT M5X60 |
| 220 | 443196-8 | AIR CLEANER ELEMENT EM4350RH |
| 221 | 126563-9 | CLEANER PLATE ASSEMBLY EM4350RH |
| 222 | 162371-4 | SEPARATOR PLATE EM4350RH |
| 223 | 352020-3 | SEPARATOR MESH ER2650LH |
| 224 | 266007-8 | PT SCREW 3X10 TRIBULAR HP2030 |
| 225 | 453865-3 | SEPARATOR CASE EX2650LH |
| 226 | 424316-3 | CHECK VALVE EBH341U |
| 227 | 454425-4 | SPIRAL TUBE 6-100 X EM4351UH |
| 228 | 422074-5 | TUBE 3-120 X EM4351UH |
| 229 | 168398-2 | PRIMER PUMP X DCS230T |
| 230 | 442196-5 | CARBURETOR GASKET EM4351P02 |
| 231 | 126561-3 | CARBURETOR ASSEMBLY EM4350RH |
| 234 | 442197-3 | CARBURETOR GASKET EM4351P02 |
| 235 | 266814-9 | HEX SOCKET HEAD BOLT M5X20 RBC2510 |
| 236 | 424489-2 | GROMMET EM4351UH |
| 237 | 422080-0 | TUBE 3-35 X EM4351UH |
| 238 | 142851-6 | INSULATOR COMPLETE EM4350RH |
| 239 | 213642-3 | O-RING 18 X EM4351UH |
| 242 | 451825-9 | CLAMP EX2650LH |
| 243 | WJ00096589 | SCREW ASSEMBLY PS32CTLC |
| 244 | WJ00021158 | COVER-METERING DIAPHRAGM EA320 DCS230T |
| 245 | 168620-7 | METERING DIAPHRAGM ER2650LH BHX2501 |
| 246 | 442183-4 | METERING DIAPHRAGM GASKET RBL250-RBC225-25 |
| 247 | WJ00014477 | PIN DCS230T |
| 248 | WJ00016648 | LEVER DCS230T |
| 249 | WJ00983248 | SPRING X EM4350RH |
| 250 | 5416036160 | PLUG-WELCH EM4350RH |
| 251 | WJ00088229 | PLUG-CUP PS32CTLC |
| 252 | 5806084330 | STEEL BALL EM4350RH |
| 253 | WJ00160593 | ACCELERATOR PISTON ASSEMBLY EM4350RH |
| 254 | WJ00983305 | SPRING A EM4350RH |
| 255 | WJ00963240 | SCREW |
| 256 | WJ00343562 | THROTTLE VALVE EM4350RH P08 |
| 257 | WJ01023345 | HIGH SPEED NEEDLE H |
| 258 | WJ01023344 | IDLE NEEDLE EM4350RH |
| 259 | WJ00025162 | LIMITER CAP EM4350RH |
| 260 | 257964-1 | SROP RING E-3 ER2650LH/BHX2501 EBH341U |
| 261 | WJ00098494 | SPRING PS32CTLC |
| 262 | WJ00224392 | THROTTLE SHAFT ASSEMBLY EM4350RH |
| 263 | 413140-9 | WASHER EBH341U |
| 264 | 5246001210 | SWIVEL DBC260L/U/RBC260 DBC260U |
| 265 | 5016004110 | SCREW |
| 266 | WJ00008282 | VALVE X DCS230T |
| 267 | WJ00001673 | RING-RETAINING PS32CTLC |
| 268 | WJ00183585 | CHOKE LEVER EM4350RH |
| 269 | WJ00044456 | CHOKE SHAFT - EM4350RH |
| 270 | 5806122210 | SPRING |
| 271 | 5806122220 | BALL EM4350RH |
| 272 | WJ00343175 | CHOKE VALVE EM4350RH |
| 273 | WJ00096475 | SCREW PS32CTLC |
| 274 | 352010-6 | INLET SCREEN ER2650LH/BHX2501 |
| 275 | WJ00009589 | DIAPHRAGM-PUMP PS32CTLC |
| 276 | WJ00092228 | GASKET EM4350RH |
| 277 | 234183-6 | CONICAL COMPRESSION SPRING 5-9ER2650L 65-9 EBH341U |
| 278 | WJ00213867 | PUMP COVER ASSEMBLY EM4350RH |
| 279 | WJ00096166 | SCREW PS32CTLC |
| 280 | 5416036120 | SPRING EM4350RH |
| 281 | 5416036130 | SCREW-IDLE ADJUST EM4350RH |
| 290 | 267485-5 | FLAT WASHER 5 |
| 291 | 168719-8 | JOINT PIPE EM4350RH |
| 292 | 213021-5 | O- RING 5 LS1013 |
| 293 | 286284-6 | CAP X MS251.4 |
| 294 | 168872-0 | CONTROL CABLE EM4350RH |
| 500 | 197030-1 | CUTTER ASSEMBLY 154 SET |
| 501 | 782238-6 | BOX WRENCH 17 |
| 502 | 783232-1 | HEX. WRENCH 5 |
| 503 | 831304-7 | ACCESSORY BAG |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Makita EM4350RH
12 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 7/10 BUSINESS DAYS APPROX
- MORE INFO:
- info@bricoutensili.com
New
You might also like
Comments (0)
No customer reviews for the moment.
Viewed products
Customers who bought this product also bought:
16 other products in the same category:
