Makita Spare Parts for Hedge Trimmer EH561
Distribution and Sale at attractive prices of MAKITA Original Spare Parts & Accessories. Low prices and a professional Assistance guaranteed. We are a Repair service able to advise you on the purchase the most suitable spare parts to quickly solve any maintenance or issue for Hedge Trimmer EH561.
In the following table, look for the model of the Trimmer and the respective parts of the code.
| EH561 - HEDGE TRIMMER 56CM MAKITA 21,7CC pag.1 | ||
| # | Part Num. | Description |
| 1 | 1181550000 | FRONT HANDLE HT2256D |
| 2 | 0301080000 | REINFORCING PLATE HT2256D- |
| 3 | 1361410000 | DRUM CPL HT2256D-HT2276E |
| 4 | 1181410000 | UPPER CASE HT2256D |
| 5 | 162050000K | FLANGE NUT M5 X HT2256D-HT2276E |
| 6 | 054060150K | HEX BOLT M6X15 X HT2256D-HT2276 |
| 7 | 055001000R | GREASING NIPPLE M6 X HT2256D-HT2276E |
| 8 | 354060010K | BALL BEARING HT2256D |
| 9 | 351006080K | BALL BEARING 608Z HT2256 |
| 10 | 150060000K | HEX NUT M6 X HT2256D |
| 11 | 1361420000 | PINION GEAR HT2256D- |
| 12 | 1360030000 | GEAR CRANK ASSY HT2256D - |
| 13 | XOC0000018 | CONNECTING ROD HTR5600 |
| 14 | 283026000K | RETAINING RING HT2256D - |
| 15 | 055060350K | HEX. BOLT M6X35 HT2256D |
| 16 | 351006080K | BALL BEARING 608Z HT2256 |
| 17 | 010030050K | PAN HD SCREW M3X5 X HT2256D-HT2276E |
| 18 | 0301100000 | ROD SLIDING PLATE HT2256D-HT2276E |
| 19 | 1181010000 | FELT X HT2256D-HT2276E |
| 20 | 1181040000 | LOWER CASE HT2256D |
| 21 | 054050160K | HEX. BOLT M5X16 X HT2256D-HT2276 |
| 22 | 054050200K | HEX. BOLT M5X20 X HT2256D-HT2276 |
| 23 | 164060000K | HEX NUT M6 HT2256D |
| 24 | 164060000K | HEX NUT M6 HT2256D |
| 25 | 1181520000 | BLADE GUARD X HT2256D |
| 26 | 031050200K | FLAT HEAD SCREW M5X20 HT2256D |
| 27 | 0082500000 | BLADE SLIDING WASHER HT2256D- |
| 28 | 0082470000 | BLADE SLIDING SCREW HT2256D-HT2276E |
| 29 | 1181260000 | BLADE SUPPORT BAR X HT2256D |
| 32 | 150060000K | HEX NUT M6 X HT2256D |
| 33 | 055060400K | HEX. BOLT M6X40 X HT2256D |
| 34 | 055060500K | HEX. BOLT M6X50 X HT2256D |
| 35 | 0082480000 | BLADE SLIDING SCREW HT2256D-HT2276E |
| 36 | 028002039A | BLADE COVER |
| 37 | 1181540000 | LEAF SPRING HT2256D |
| 38 | XOC0000033 | STOPPER |
| 39 | 112040100K | TAPPING SCREW M4X10 HT2256D |
| 40 | 1181210000 | CABLE HOLDER HT2256D |
| 41 | 1181110000 | WIRE END HT2256D |
| 42 | 005044004A | SLIDE SWITCH HT2256D |
| 43 | 1181150000 | LEVER X HT2256D |
| 44 | 280002500K | RETAINING RING ETW 2.5 HT2256D |
| 48 | 1181500000 | REAR HANDLE HT2256D |
| 49 | 017040160K | PAN HD SCREW M6X16 X HT2256D |
| 50 | 017040300K | PAN HD SCREW M6X30 X HT2256D |
| 51 | 1181490000 | REAR HANDLE RH HT2256D |
| 52 | 150040000K | HEX NUT M4 X HT2256D |
| 53 | 126493-4 | HANDLE PIN EH561 |
| 54 | 229060000K | WAVE WASHER X HT2256D |
| 55 | 0566079970 | CLAMP RBC520 |
| 100 | 6018505400/KIT | BLADE ASSY HT2256D-HTR5600 |
| EH561 - HEDGE TRIMMER 56CM MAKITA 21,7CC pag.2 | ||
| 56 | 5251003000 | CRANKCASE ASSY HT2256D |
| 57 | 424447-8 | CRANKCASE GASKET RBC2510 |
| 58 | 0140059500 | SCREW M5X25 X RBC225-255 |
| 59 | 5252002002 | CRANKSHAFT COMPLETE |
| 60 | 5212500700 | PISTON X RBC221-225 |
| 61 | 5982500000 | PISTON RING RBC221-225 |
| 62 | 5212500801 | PISTON PIN RBC221-225 |
| 63 | 233976-8-4 | CLIP EBH252L (4pcs) |
| 64 | 442171-1 | CYLINDER GASKET RBC2510 |
| 66 | 0119059730 | HEX. BOLT RBC 260/230/225/255 |
| 67 | 5253500200 | INSULATOR GASKET HT2256D |
| 68 | 141056-5 | INSULATOR |
| 69 | 0140059500 | SCREW M5X25 X RBC225-255 |
| 70 | 5253500102 | MUFFLER GASKET HT2256D |
| 71 | 5253010001 | EXAUST MUFFLER HT2256D-HT2276E |
| 72 | 0031005000 | WASHER M5 RBC230 / 410 / RBK410 |
| 73 | 0119059660 | SOCKET HEAD BOLT RBC350-RBC420 - |
| 74 | 5257001010 | MAGNETO FLYWHEEL HT2256D |
| 75 | 5257001020 | IGNITION COIL HT2256D-HT2276E |
| 76 | 0140049920 | SCREW M4X20 X RBC225-255 |
| 77 | 5257500300 | GROMMET HT2256D-HT2276E |
| 78 | 324891-8 | PLUG CAP SPRING EBH341 |
| 79 | 5237503301 | PLUG CAP XRBC225-255 |
| 80 | 0650149721 | SPARK PLUG RBK250 |
| 81 | 5238500500 | CLUTCH SPRING RBC225-255 |
| 82 | 6252500801 | CLUTCH SHOE RBC225-255 |
| 83 | 267429-5 | WASHER 6 |
| 84 | 267817-6 | WASHER 8 EBH252L |
| 85 | 266457-7 | SHOULDER HEX BOLT M6X25 EBH252L |
| 86 | 6202500000 | HOLDER HT2256D-HT2276E |
| 87 | 5253500500 | MUFFLER COVER X HT2256D |
| 88 | 0043705160 | SET SCREW HT2256D-HT2276E |
| 89 | 5255001000 | RECOIL STARTER HT2256D |
| 90 | 5255001020 | SET SCREW HT2256D-HT2276E |
| 91 | 5505001030 | FRICTION PLATE RBC 310 / RBC520 |
| 92 | 5105015050 | FRICTION SPRING RBC 310/520 |
| 93 | 5105015020 | STARTER RATCHET RBC 310 / RBC520 |
| 94 | 5105015060 | SPRING RETURN X RBC310 / RBC520 |
| 95 | 5025001010 | REEL RBC 310 |
| 96 | 5235024022 | STARTER ROPE RBK250-RBC225-2 |
| 97 | 232257-7 | SPIRAL SPRING EBH341U |
| 98 | 5225004020 | STARTER KNOB HT2256D |
| 99 | 911218-7 | SCREW ASSY M5X14 |
| 100 | 0200070010 | WASHER X HT2256D-HT2276E |
| 101 | 5255500301 | CYLINDER COVER EH561 |
| 102 | 5503503001 | SPACER X HT2256D-HT2276E |
| 103 | 0140059490 | SCREW X HT2256D-HT2276E |
| 104 | 0031206000 | WASHER G.24 / 35-RBC225-255 |
| 105 | 0011306160 | BOLT ASSY RBC230 / 260/225/255 |
| 106 | 5215500300 | BAFFLE PLATE HT2256D |
| 107 | 5255500001 | BLOWER HOUSING HT2256D |
| 108 | 0043505160 | SCREW ASSY HT2556D-HT2276E |
| 109 | 5256012001 | TUBE CPL. HT2256D-HT2276E |
| 110 | 5256002000 | TANK PLATE CPL HT2256D |
| 111 | 163447-0 | FUEL FILTER DCS230T |
| 112 | 0043705160 | SCREW ASSY HT2256D-HT2276E |
| 113 | 5256025000 | FUEL TANK CPL HT2256D-HT2276 |
| 114 | 452920-8 | FUEL TANK CAP |
| 115 | 1181240000 | SPACER HT2256D-HT2276E |
| 116 | 0140059450 | SCREW M5X18 X RBK250-RBC225 / 25 |
| 117 | 6202006000 | BOLT X RBC310 |
| 118 | 5607005000 | WIRE CPL. RBC350-RBC420-HT225 |
| 119 | 213628-7 | OIL SEAL RBC2510 |
| 120 | 0600129920 | BALL BEARING MS5250 |
| 121 | 140436-2 | STRAP UNIT EBH341U |
| 153 | 0566059980 | CLAMP RBC525 |
| EH561 - HEDGE TRIMMER 56CM MAKITA 21,7CC pag.3 | ||
| 119 | 5256032000 | CARBURETOR X HT2256D-HT2276E |
| 120 | 5253020010 | AIR CLEANER RBC201 |
| 121 | 5203004010 | AIR FILTER ELEMENT HT2256D |
| 122 | 0043305650 | SCREW ASSY HT2256D-HT2276E |
| 123 | 5253003020 | AIR CLEANER HOUSING RBC201 |
| 124 | 5236061000 | O-RING RBC201 |
| 126 | 5256501900 | CABLE BRACKET EH620 |
| 127 | 5236018040 | SWIVEL RBC230-260-310-225- |
| 128 | 266581-6 | SCREW M3X8 EBH341U |
| 129 | 5256032010 | THROTTLE VALVE ASSY RBL250- |
| 130 | 5316005120 | STOP RING E3 RBC 260/230/310/225/2 |
| 131 | 5246001010 | O-RING RBC 260/230/310 |
| 132 | 5026004010 | JET HT2256D-HT2276E |
| 133 | 5246001030 | PUMP GASKET RBC260-230-310- |
| 134 | WJ00009599 | PUMP DIAPHRAGM X DCS230T |
| 135 | 5016004010 | INLET SCREEN RBC 260/230/310/225 |
| 136 | 5256007010 | PUMP BODY ASSY HT2256D |
| 137 | 442154-1 | METERING DIAPHRAGM GASKET EBH341U |
| 138 | 168574-8 | METERING DIAPHRAGM ASSY EBH341U |
| 139 | 5236046060 | AIR PURGE BODY ASSY. RBC350 |
| 140 | 424314-7 | PRIMER PUMP BULB EBH341 |
| 141 | 5236046050 | PUMP COVER X RBC350-RBC42 |
| 142 | 266582-4 | TAPPING SCREW 3X24 EBH341U |
| 143 | 442177-9 | SPACER GASKET |
| 144 | 5316020020 | CABLE ADJUST SCREW RBC321 |
| 145 | 5316005450 | CABLE ADJUST NUT M6 RBC260 / 310 |
| 146 | 0630029830 | CONTROL CABLE EH561 |
| 152 | 442177-9 | SPACER GASKET |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
