Makita Spare Parts for Pruning Scissor DUP361Z

€733.40
Tax included

Makita Spare Parts for Pruning Shear DUP361Z

Makita original spare parts for the replacement of damaged parts or to repair electrical or mechanical components of the Pruning Shear DUP361Z.
ITEM CODE: 123458-7
Quantity
on 7/10 Business Days Approx

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Makita Spare Parts for Pruning Shear DUP361Z

Makita original spare parts for the replacement of damaged parts or to repair electrical or mechanical components of the Pruning Shear DUP361Z.

In the following table, look for the model of the Prining Scissor and the respective parts of the code.
Pruning Shear DUP361Z

Pruning Scissor DUP361Z
# Part Num. Description
1 251490-2 SCREW M5X14
3 456209-6 UPPER CASING X DUP361Z
5 251474-0 SCREW M8
6 197366-8 UPPER BLADE X DUP361Z
7 197367-6 LOWER BLADE X DUP361Z
8 213034-6 O RING 3 DA3010F
9 346940-1 BLOCK PLATE X DUP361Z
10 266557-3 SCREW HS M3X8 X DUP361Z
11 264118-3 NUT M8
12 266786-8 TAPPING SCREW PT2X10
13 456218-5 CAP B X DUP361Z
14 961011-9 STOP RING, HR2450
15 347165-0 CON-ROD
16 256568-6 PIN
17 251484-7 M3X4 SCREW
18 456215-1 LEVER X DUP361Z
19 216031-1 STEEL BALL 2.3AN911H
20 233491-2 COMPRESSION SPRING 2AN911H
21 688189-0 MAGNET X DUP361Z
22 266999-1 M3X4 SCREW
23 231397-8 COMPRESSION SPRING 4, 2414NB
24 123536-3 SWITCH LEVER X DUP361Z
25 456217-7 COVER FOR X DUP361Z
26 123458-7 JOINT X DUP361Z
27 912012-0 M3X10 SCREW
28 227390-8 GEAR 48 X DUB361Z
29 227389-3 GEAR 18
30 253810-6 FLAT WASHER 12 HR4000C
31 911006-2 PAN HEAD SCREW M3*8, HR240D
32 319349-0 DUP361Z MOTOR SUPPORT
33 629160-5 DC X DUP361Z MOTOR
34 620459-1 CABLE CONNECTION X DUP361Z
35 456211-9 LOWER CASING X DUP361Z
36 911028-2 SCREW M3X16
37 143935-3 FRONT CASING X DUP361Z
38 266980-2 SCREW M3X16 X DUP361Z
58 266786-8 TAPPING SCREW PT2X10
41 183B69-2 CONTROL CASING X DUP361Z
42 232267-4 PLATE SPRING X DUP361Z
43 687053-2 CORD CLAMP, 9523NB
44 265995-6 TAPPING SCREW 4X18, 4100NH
45 643523-1 BATTERY TERMINAL
46 620461-4 RF UNIT X DUP361Z
47 620458-3 REGULATOR X DUP361Z
49 265995-6 TAPPING SCREW 4X18, 4100NH
50 183B76-5 DUP361Z SWITCH HOUSING
51 699086-5 POWER SUPPLY CABLE DUP361Z
52 687053-2 CORD CLAMP, 9523NB
53 265995-6 TAPPING SCREW 4X18, 4100NH
54 651536-8 SWITCH 1941.1451 X DUP361Z
55 620460-6 CIRCUIT DUB361Z
57 266429-2 TAPPING SCREW PT 3*16, 6935FD
59 661445-3 CONNECTION CORD
60 630999-1 HOLDER BATTERY
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Dolmar websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Dolmar brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
