Makita Spare Parts for Power Cutter DPC9500
€435.39
Tax included
Makita Spare Parts for Power Cutter DPC9500
We have the original Spares MAKITA for Power Cutter 355MM 95CC - DPC9500 the diagram, parts list and tool repair that help you need to get your tools running like new again.Fix Your Power Cutter DPC9500. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Makita Spare Parts for Power Cutter DPC9500
Fix Your Power Cutter 355MM 95CC - DPC9500. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following table, look for the model of Power Cutter and the respective parts of the code.
| DPC9500 POWER CUTTER 355MM 95CC. pag.1 | ||
| # | Part Num. | Description |
| 1 | 031130004 | CYLINDER PISTON |
| 3 | 031132003 | PISTON A / B COMPL. 1,2mm |
| 6 | 119132060 | PISTON RING C12X1 |
| 7 | 965521023 | GASKET X D 133 |
| 8 | 908006205 | SCREW M6X20 |
| 11 | 254042-8 | KEY 3X3,7 |
| 12 | 962210121 | NEEDLE BEARING X DCS6401 |
| 15 | 962900054 | RADIAL RING 17 / 28X5.4 |
| 17 | 031111630 | CRANKCASE x DPC |
| 18 | 031111650 | CRANKCASE x DPC |
| 20 | 908005305 | SCREW M5X30 (TORX) |
| 21 | 957605112 | BREAK. SHORT CIRCUIT. COMPL. |
| 23 | 965551051 | SCREW M6X70 |
| 24 | 926206000 | ELASTIC WASHER 6 |
| 25 | 123213010 | SQ.NUT W/PIVOT, DPC70 |
| 26 | 924306400 | WASHER 6.4 |
| 27 | 922606000 | HEX NUT M6, DOLMAR, D |
| 29 | 936430160 | SPIRAL PIN 3X16, DCS4 |
| DPC9500 POWER CUTTER 355MM 95CC. pag.2 | ||
| 1 | 123310011 | TUBULAR HANDLE |
| 2 | 144310072 | STRENGTH.PIECE, DPC70 |
| 3 | 122310051 | STRENGTH.PIECE, DPC70 |
| 4 | 908006205 | SCREW M6X20 |
| 5 | 392320100 | FOOT, DPC9500 |
| 6 | 908006355 | SCREW M6X35 (TORX) |
| 11 | 119117021 | THROTTLE LEVER, DPC70 |
| 12 | 119117041 | SPRING |
| 13 | 935950400 | CYLINDRICAL PIN 5X40 |
| 14 | 119117030 | LOCKING LEVER |
| 15 | 935940240 | CYLINDRICAL PIN 4X24 |
| 16 | 119117052 | SPRING X PS6800I |
| 17 | 965451750 | BUTTON |
| 18 | 965551160 | PRESSURE SPRING |
| 19 | 965551150 | STOP PIN |
| 20 | 908005305 | SCREW M5X30 (TORX) |
| 25 | 123114600 | COMPLETE TANK |
| 27 | 965451560 | PLUG |
| 28 | 965402360 | RUBBER BUFFER |
| 30 | 965451901 | GAS CAP COMP.DCS / PS9010 |
| 31 | 963232045 | GASKET OR32X4.5 |
| 32 | 163532-9 | FILTER |
| 33 | 963601240 | FELT |
| 34 | 965450200 | SUCTION LINE |
| 36 | 965452490 | PLASTIC TUBE (1METRO) |
| 37 | 965452450 | FUEL TUBE |
| 38 | 965403131 | RUBBER BUFFER |
| 40 | 010114040 | ANGULAR SLEEVE COMPL. |
| DPC9500 POWER CUTTER 355MM 95CC. pag.3 | ||
| 1 | 031112600 | FAN HOUSING ASSY,DPC7 |
| 2 | 900004363 | SPACER 15 / 75.5X0.5 |
| 3 | 123163013 | REWIND SPRING |
| 4 | 123163020 | SPRING COVER 33 / 73X0.5 |
| 5 | 907204102 | SCREW M4X10 |
| 6 | 123162034 | STARTER PULLEY |
| 7 | 929314100 | SNAP RING, 14 X 1, DC |
| 8B | 985000165 | STARTER ROPE DIAM.4X100M |
| 10 | 965402262 | STARTER HANDLE X DCS9000 |
| 11 | 267821-5 | ELASTIC WASHER |
| 12 | 980114094 | LABEL |
| 15 | 965603021 | SPARK PLUG NGK BPMR7A |
| 16 | 957604240 | SPARK PLUG CAP, DPC70 |
| 20B | 010140010 | IGNITION ASSEMBLY, DP |
| 22 | 031166010 | STARTER RATCHET, DCS6 |
| 23 | 264022-6 | NUT |
| 24 | 926208001 | ELASTIC WASHER 8 |
| 25 | 908004125 | SCREW M4X12 (TORX) |
| DPC9500 POWER CUTTER 355MM 95CC. pag.4 | ||
| 1 | 398213600 | SPROCKET GUARD, DPC70 |
| 2 | 923210002 | HEX NUT W/SHOULDER,DP |
| 7 | 962300016 | NEEDLE BEARING 309 |
| 14 | 123181010 | CLUTCH SHOE, DPC7000 (SET) |
| 16 | 122184011 | CLUTCH SPRING, DPC700 |
| 17 | 122182030 | GUIDE DISC, DPC7000 |
| 20 | 123174159 | MUFFLER, DPC7000 |
| 21 | 398174600 | HEAT SHIELD, DPC7000 |
| 23 | 266946-2 | SCREW M5X12 (TORX) |
| 24 | 266474-7 | SCREW M5X8 (TORX) |
| 25 | 908006655 | SCREW M6X65 (TORX) |
| 26 | 928406000 | WASHER 6 |
| DPC9500 POWER CUTTER 355MM 95CC. pag.5 | ||
| 2 | 266605-8 | SCREW M5X16 PS32CTLC |
| 3 | 266606-6 | SCREW M5X40 PS32CTLC |
| 7B | 392118050 | FILTER COVER COMPL. |
| 8 | 921708000 | HEXAGONAL NUT M8 |
| 10 | 001173031 | COMPLETE FILTER |
| 11 | 001173000 | PREFILTER |
| 12 | 122173140 | AIR FILTER |
| 13 | 001173021 | INNER FILTER CPL., DP |
| 14 | 965401025 | RUBBER BUSH, DPC7000 |
| 15 | 963257070 | GASKET OR57X7 |
| 16 | 123118052 | COVER |
| 19 | 980113841 | IGNITION LABEL |
| 22 | 926105001 | ELASTIC RING 5 |
| 25 | 266946-2 | SCREW M5X12 (TORX) |
| 27 | 965518090 | GASKET |
| 28 | 965518031 | GASKET |
| 29 | 908405255 | SCREW M5X25 (TORX) |
| 31 | 965518111 | GASKET |
| 34 | 965402851 | RUBBER PLATE COVER |
| 36 | 031150730 | CHOKE SHAFT, DPC9500 |
| 37 | 965401011 | RUBBER BUSH, DCS340 |
| DPC9500 POWER CUTTER 355MM 95CC. pag.6 | ||
| 1 | 122151620 | CARBURETOR HS-239 |
| 6 | 957150100 | DIAPHRAGM SET + GASKETS |
| 7A | 113150150 | PUMP DIAPHRAGM |
| 7B | 001150151 | PUMP DIAPHRAGM |
| 10 | 144151315 | BUSH |
| 16 | 122151400 | WASHER |
| 17 | 100150350 | SAFETY WASHER |
| 21 | 113150261 | Choke Shutter |
| 23 | 113150380 | LOCKING BALL |
| 24 | 122151470 | IDLE ADJUSTMENT SCREW (L) |
| 25 | 144151480 | SPRING (L) |
| 29 | 957150010 | SERIES CONTROL PARTS 309 |
| 32 | 113150040 | WASHER COVER DIAM.9MM |
| 34 | 107150240 | ELASTIC RING |
| 35 | 107150230 | SCREEN |
| 42 | 122151551 | GOVERNOR VALVE, DPC7000 |
| 44 | 001150060 | WASHER 0.7MM |
| DPC9500 POWER CUTTER 355MM 95CC. pag.7 | ||
| 3 | 392341610 | PROTECTION HOOD, DPC9 |
| 4 | 395341600 | SWIVEL SEGMENT, DPC95 |
| 5 | 392341040 | BLOCK CLAMP |
| 6 | 908006255 | SCREW M6X25 |
| 8 | 920406000 | HEXAGONAL NUT M6, DPC |
| 9 | 908006205 | SCREW M6X20 |
| 15 | 392410600 | GUARD PLATE, DPC9500 |
| 16 | 392211610 | HAND PROTECTION |
| 17B | 900208202 | SCREW M8X20 |
| 18 | 926208001 | ELASTIC WASHER 8 |
| 19 | 920410000 | HEXAGONAL NUT M10 |
| 20 | 392221011 | V BELT PULLEY, DPC950 |
| 21 | 965300440 | V- BELT FO-Z SPZ 86 |
| 22 | 963815320 | PACKING RING, DPC7000 |
| 23 | 960102155 | BALL BEARING 15 / 35X11 |
| 24 | 398211090 | BUSH |
| 25 | 900005009 | SPACER 20 / 15X10 |
| 26 | 929235150 | SNAP RING 35X1.5, DPC |
| 27 | 962900036 | RADIAL RING, DPC7000 |
| 28 | 939144140 | KEY 4X4X14 |
| 29 | 398228013 | SPINDLE, DPC7000 D. 20 |
| 30 | 929145175 | SNAP RING 45X1.75,DPC |
| 31 | 907310204 | SCREW M10X20 |
| 40 | 985000870 | CLAMP LEVER |
| 41 | 925300000 | WASHER 8X14X0.5 |
| 42 | 392341090 | RUBBER THICKNESS |
| 43 | 392341031 | WASHER-1 |
| 44 | 392341050 | WASHER-2 |
| 45 | 392341070 | HEX HEAD SCREW |
| 50 | 392228350 | PRESSURE DISC, DPC950 DIAM. 20 |
| 52 | 392228050 | ADAPTOR 20MM TO 7/8" - DIAM. 20-22.2 |
| 55 | 900910204 | SCREW M10X20 |
| DPC9500 POWER CUTTER 355MM 95CC. pag.8 | ||
| 1A | 966144150 | METAL CUTTING DISC 350MM |
| 1B | 966144120 | STONE CUTTING DISC |
| 3 | 957004310 | KEY SET |
| 4 | 950004001 | PLASTIC CASE |
| 5 | 944500791 | ALLEN KEY |
| 6 | 944500630 | ALLEN KEY 5X304MM |
| 7 | 941717191 | UNIVERSAL KEY 17/19 |
| 8 | 782025-3 | TORX KEY |
| 9 | 941717001 | SIMPLE KEY 17 |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
