Kawasaki Spare Parts for Bruschcutter NKBC 45
€206.25
Tax included
Kawasaki Spare Parts for Bruschcutter NKBC 45
Kawasaki genuine spare parts or replacement parts for to repair Bruschcutter NKBC 45 - 89906.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Kawasaki Spare Parts for Bruschcutter NKBC 45
Kawasaki genuine spare parts or replacement parts for to repair Bruschcutter NKBC 45 - 89906.
In the following table, look for the model of the Bruschcutter and the respective parts of the code.
| Bruschcutter NKBC 45 | ||
| 1 | 88416 | Profes. Connecter Assy |
| 2.1 | 89639 | Shaft |
| 3 | 89559 | Drive Shaft |
| 7 | 62019 | Level Assy |
| 10.1 | 88413 | Band |
| 10.2 | 88412 | Holder Assy |
| 13 | 88402 | Handle Assy |
| 14 | 88409 | Bracket |
| 15.1 | 88405 | Safety Guard |
| 15.3 | 88406 | Guard Assy |
| 17 | 89957 | Gear Care Assy |
| 11005-2159 | Cylinder-Engine | |
| 11061-2173 | Gasket | |
| 13271-2262 | Plate | |
| 14080-2062 | Crankcase | |
| 14080-2063 | Crankcase | |
| 34001-2089 | Stand | |
| 92043-1302 | Pin | |
| 92045-2279 | Bearing-ball 6201C3 | |
| 92049-2259 | Seal-Oil ISCD12x22x4.5 | |
| 13001-2166 | Piston Engine | |
| 13002-2061 | Piston Pin | |
| 13008-6067 | Ring Set Piston | |
| 13033-2063 | Bearing-Small End | |
| 49119-2231 | CrankShaft Assy | |
| 92026-2353 | Spacer 9x15x1.8 | |
| 92033-2058 | Ring nSnap | |
| 3915-2089 | Screw Pan 5x16 | |
| 49089-2631 | Shroud-Engine | |
| 59066-2797 | Housing-Fan | |
| 92172-2060 | Screw M4x10 | |
| 16073-2220 | lnsulator | |
| 21050-2313 | Flywheel | |
| 21130-2072 | Cap-Spark Plug | |
| 510A3100 | Key Woodruff | |
| 21169-2051 | Terminai | |
| 21171-2250 | Coil Ass'y lgnition | |
| 26011-2113 | Wire-Lead | |
| 26011-2361 | Wire-Lead | |
| 92070-2107 | Sparkplug BPMR7A | |
| 92153-2135 | Bolt 4x20 | |
| 92170-2041 | Clamp | |
| 92192-2165 | Tube 6x6.6x80 | |
| 92210-2101 | Nut M9 | |
| 11049-2006 | Bracket | |
| 11060-2111 | Gasket | |
| 11061-2054 | Gasket | |
| 11061-2175 | Gasket Carburator | |
| 11061-2176 | Gasket Cilinder | |
| 11061-2178 | Gasket | |
| 12022-2059 | Valve Reed | |
| 14043-2051 | Filter | |
| 14090-2017 | Cover Primed Pump | |
| 15004-2050 | Carburetor Assy | |
| 16030-2078 | Valve-Float | |
| 16055-2051 | Lever | |
| 16160-2089 | Body | |
| 16160-2103 | Body | |
| 21083-2073 | Arm | |
| 32085-2105 | Stopper | |
| 43028-2067 | Diaphragm | |
| 43028-2096 | Diaphragm | |
| 16073-2236 | Insulator | |
| 49043-2067 | Pump-Priming | |
| 92009-2235 | Screw 5x20 | |
| 92009-2277 | Screw | |
| 92009-2336 | Screw | |
| 92009-2337 | Screw | |
| 16002-2056 | Adjuster Cable | |
| 92015-2145 | Nut | |
| 92033-2078 | Ring-Snap | |
| 92043-2094 | Pin | |
| 92055-2147 | Ring-O | |
| 92063-2483 | Jet-Main | |
| 92144-2308 | Spring | |
| 92172-2091 | Screw 3x12 | |
| 92200-2074 | Washer | |
| 11011-2362 | Case-Air Filter | |
| 11013-2226 | Element Air Filter | |
| 11061-2174 | Gasket Muffler | |
| 11065-2123 | Cap | |
| 18020-2091 | Baffle | |
| 18077-2137 | Arrester-Spark | |
| 49069-2430 | Muffler Ass'y | |
| 120CB0516 | Bolt Socket 5x16 | |
| 242AA0512 | Screw 5x12 | |
| 92153-2128 | Bolt | |
| 14069-2088 | Breather | |
| 49019-2114 | Filter Fuel | |
| 51001-2324 | Fuel Tank | |
| 51048-2083 | Cap Assy | |
| 92009-2383 | Screw 5x20 | |
| 92071-2142 | Grommet | |
| 92171-2073 | Clamp | |
| 92190-2157 | Tube 3x5x182 | |
| 92192-2149 | Tube 3x6x90 | |
| 99996-6089 | Cap-Breather Assy | |
| 13165-2103 | Pawl | |
| 13169-2386 | Plate Recoil Starter | |
| 32099-2419 | Case Starter-Recoil | |
| 46075-2161 | Grip Starter-Recoil | |
| 49060-2062 | Cam Starter-Recoil | |
| 49080-2201 | Pulley-Starting | |
| 49088-2566 | Starter Recoil | |
| 59101-2119 | Reel, Starter Recoil | |
| 59106-2072 | Rope 3.5x850 | |
| 92033-2010 | Ring-Snap | |
| 92144-2054 | Spring | |
| 92144-2157 | Spring | |
| 92145-2149 | Spring | |
| 92172-2061 | Screw 4x14 | |
| 13081-2220 | Clutch Assy | |
| 49049-2075 | Shoe Clutch | |
| 92026-2125 | Washer | |
| 92043-2210 | Pin Clutch | |
| 92144-2390 | Clutch Spring | |
| 92200-2064 | Washer,Spring 10,5x14,5x0,3 | |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Kawasaki websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Kawasaki brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
