Kawasaki Spare Parts for Bruschcutter NKBC 35
€178.89
Tax included
Kawasaki Spare Parts for Bruschcutter NKBC 35
We are Kawasaki original spare parts Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Bruschcutter AMA GArden Powerde NKBC 35 - 89905.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Kawasaki Spare Parts for Bruschcutter NKBC 35
We are Kawasaki original spare parts Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Bruschcutter AMA Garden Powered Kawasaky NKBC 35 - 89905.
In the following table, look for the model of the Bruschcutter and the respective parts of the code.
| Bruschcutter AMA Garden Powered Kawasaky NKBC 35 - 89905 | ||
| # | Part Num. | Description |
| 1 | 88416 | Profes. Connecter Assy |
| 2.1 | 89639 | Shaft Assy |
| 3 | 89559 | Drive Shaft |
| 7 | 62019 | Level Assy |
| 10.1 | 88413 | Band |
| 10.2 | 88412 | Holder Assy |
| 13 | 88402 | Handle Assy |
| 14 | 88409 | Bracket |
| 15 | 88619 | Safety Guard |
| 15.3 | 88406 | Guard Assy |
| 17 | 89957 | Gear Care Assy |
| 11005-2160 | Cylinder-Engine | |
| 11061-2192 | Gasket | |
| 11065-2130 | Cap | |
| 13272-2009 | Plate | |
| 14080-2064 | Crankcase | |
| 14080-2065 | Crankcase | |
| 34001-2090 | Stand | |
| 92043-1302 | Pin | |
| 92045-2058 | Bearing-ball 6201C3 | |
| 92049-2253 | Seal-Oil ISCD12x22x4.5 | |
| 92049-2267 | Seal-Oil ISCD12x22x4.5F | |
| 13001-2170 | Piston Engine | |
| 13002-2101 | Piston Pin | |
| 13008-6045 | Ring Set Piston | |
| 13033-2067 | Bearing-Small End | |
| 49119-2243 | CrankShaft | |
| 92026-2355 | Spacer 9x15x1.8 | |
| 92033-2061 | Seeger | |
| 49089-2643 | Shroud-Engine | |
| 59066-2800 | Housing-Fan | |
| 92172-2060 | Screw M4x10 | |
| 16073-2220 | Insulator | |
| 21050-2317 | Flywheel | |
| 21130-2074 | Cap-Spark Plug | |
| 21130-2077 | Cap-Spark Plug | |
| 21169-2051 | Terminal | |
| 21171-2257 | Coil Ass'y Ignition | |
| 26011-2113 | Wire-Lead | |
| 26011-2361 | Wire-Lead | |
| 92153-2134 | Bolt 4x20 | |
| 92170-2041 | Clamp | |
| 92192-2165 | Tube 6x6.6x80 | |
| 92210-2094 | Nut M9 | |
| 510A3100 | Key Woodruff | |
| 11049-2006 | Bracket | |
| 11060-2111 | Gasket | |
| 11061-2054 | Gasket | |
| 11061-2208 | Gasket Carburator | |
| 11061-2209 | Gasket Carburator | |
| 12021-2055 | Valve Assy Reed | |
| 12022-2060 | Valve Reed | |
| 14043-2051 | Filter | |
| 14090-2017 | Cover Primed Pump | |
| 15004-2049 | Carburetor Assy | |
| 16030-2078 | Valve-Float | |
| 16055-2051 | Lever | |
| 16160-2089 | Body | |
| 16160-2141 | Body | |
| 21083-2073 | Arm | |
| 32085-2106 | Stopper | |
| 43028-2096 | Diaphragm | |
| 43049-2062 | Packing | |
| 49043-2067 | Pump-Priming | |
| 92009-2249 | Screw 5x20 | |
| 92009-2277 | Screw | |
| 92009-2336 | Screw | |
| 92009-2337 | Screw | |
| 92009-2354 | Screw | |
| 92015-2145 | Nut | |
| 92033-2078 | Ring-Snap | |
| 92043-2094 | Pin | |
| 92055-2147 | Ring-O | |
| 92063-2393 | Jet-Main | |
| 92144-2308 | Spring | |
| 92172-2091 | Screw 3x12 | |
| 92200-2074 | Washer | |
| 234AA0560 | Screw 5x60 | |
| 11011-2366 | Case-Air Filter | |
| 11013-2229 | Element Air Filter | |
| 11061-2193 | Gasket Muffler | |
| 11065-2125 | Cap | |
| 18020-2091 | Baffle | |
| 18077-2139 | Arrester-Spark | |
| 49069-2435 | Muffler Ass'y | |
| 120CB0516 | Bolt Socket 5x16 | |
| 242AA0512 | Screw 5x12 | |
| 92153-2128 | Bolt | |
| 14069-2088 | Breather | |
| 49019-2114 | Filter Fuel | |
| 51001-2336 | Fuel Tank | |
| 51048-2083 | Cap Assy | |
| 92009-2383 | Screw 5x20 | |
| 92071-2142 | Grommet | |
| 92171-2073 | Clamp | |
| 92191-2102 | Tube 3x5x182 | |
| 92192-2117 | Tube 3x6x90 | |
| 99996-6089 | Cap-Breather Assy | |
| 13165-2103 | Pawl | |
| 13169-2386 | Plate Recoil Starter | |
| 32099-2419 | Case Starter-Recoil | |
| 46075-2161 | Grip Starter-Recoil | |
| 49060-2062 | Cam Starter-Recoil | |
| 49080-2201 | Pulley-Starting | |
| 49088-2566 | Starter Recoil | |
| 59101-2119 | Reel, Starter Recoil | |
| 59106-2072 | Rope 3.5x850 | |
| 92033-2010 | Ring-Snap | |
| 92144-2054 | Spring | |
| 92144-2157 | Spring | |
| 92145-2149 | Spring | |
| 92172-2061 | Screw 4x14 | |
| 13081-2220 | Clutch-Assy | |
| 13081-2236 | Clutch-Assy | |
| 49049-2075 | Shoe-Clutch | |
| 49049-2104 | Shoe-Clutch | |
| 92026-2125 | Washer | |
| 92043-2210 | Pin Clutch | |
| 92144-2390 | Clutch Spring | |
| 92145-2178 | Spring | |
| 92200-2064 | Washer Spring 10.5x14.5x0.3 | |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Ama websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Ama brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
