Hitachi Spare Parts for Gas Strip Nailer NR90GR2
€1.28
Tax included
Hitachi Spare Parts for Gas Strip Nailer NR90GR2
Original spare parts for Hitachi-Koky Gas Strip Nailer NR90GR2.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Hitachi Spare Parts for Gas Strip Nailer NR90GR2
Original spare parts for Hitachi-Koky Gas Strip Nailer NR90GR2.
In the following table, look for the model of the Gas Strip Nailer and their spare part.
| Gas Strip Nailer NR90GR2 | ||
| # | Part Num. | Description |
| 1 | 996399 | HEX. SOCKET HD. BOLT (W/FLANGE) M5X12 |
| 3 | 886129 | FILTER |
| 4 | 885309 | MOTOR |
| 7 | 885310 | MOTOR MOUNT |
| 8 | 885314 | MOUNT SLEEVE |
| 10 | 885333 | SPARK PLUG (A) |
| 13 | 885308 | CYLINDER HEAD ASS'Y |
| 14 | 885316 | O-RING (I.D 59.92) |
| 17 | 885311 | FAN |
| 19 | 885294 | CHAMBER HEAD |
| 20 | 886133 | GASKET (B) |
| 21 | 885296 | CHAMBER |
| 22 | 878607 | PLUNGER O-RING |
| 23 | 880319 | SHAFT RING |
| 27A | 886313 | ADAPTER |
| 28 | 961681 | HEX. SOCKET SET SCREW M4X5 |
| 29 | 885297 | CHAMBER LOCK PLATE |
| 30 | 886484 | PIN (A) |
| 31 | 885306 | SWITCH PLATE |
| 32 | 885283 | O-RING (I.D. 66.27) |
| 33 | 885285 | RETAINING RING |
| 34 | 886132 | PISTON RING (A) |
| 35 | 885619 | PISTON |
| 36 | 885289 | PISTON BUMPER (A) |
| 38 | 885618 | CYLINDER ASS'Y |
| 43 | 885632 | BLADE GUIDE (A) |
| 44 | 886252 | NOSE SLEEVE |
| 45 | 885622 | SIDE PLATE (A) |
| 46 | 886544 | SPECIAL NUT M5 |
| 48 | 886143 | PLATE SLEEVE |
| 51 | 886546 | PUSHING LEVER ARM (C) |
| 52 | 886245 | PUSHING LEVER SPRING (A) |
| 53 | 885301 | PUSHING LEVER CONNECTOR |
| 54 | 885625 | CYLINDER PLATE (B) |
| 57 | 886547 | PUSHING LEVER ARM (D) |
| 62 | 886128 | PUSHING STOPPER |
| 63 | 886144 | PUSHING LEVER(A) |
| 64 | 885272 | ADJUSTER BUSH (A) |
| 68 | 885307 | INSULATOR SHEET |
| 70 | 886244 | HOUSING ASS'Y |
| 71 | 876465 | NYLON NUT M4 |
| 72 | 949820 | HEX. SOCKET HD. BOLT M5X15 (10 PCS.) |
| 73 | 878164 | SLEEVE |
| 75 | 886139 | HANDLE (D) |
| 79 | 885334 | SWITCH MOUNT |
| 80 | 885347 | SWITCH ARM |
| 82 | 885337 | LOCK BAR SPRING |
| *85 | 885331 | CONTROLLER |
| 87 | 885828 | TRIGGER SPRING (A) |
| 89 | 949551 | ROLL PIN D2.5X10 (10 PCS.) |
| 90 | 885799 | TRIGGER INTERNAL WIRE (C) SET |
| 96 | 877371 | NYLON NUT M5 |
| 99 | 886141 | CELL LEVER (A) |
| 100 | 885280 | LATCH |
| 101 | 949859 | ROLL PIN D2X8 (10 PCS.) |
| 102 | 885281 | SPRING D3.6 |
| 103 | 885352 | CELL COVER |
| 106 | 886257 | TENSION PLATE (C) |
| 107 | 886135 | SWITCH LEVER ASS'Y |
| 108 | 885518 | SPRING |
| 110 | 886138 | LEVER STOPPER |
| 111 | 886729 | HANDLE (C) |
| 113 | 885621 | NAIL FEEDER |
| 114 | 883687 | SPRING |
| 115 | 885324 | NAIL FEEDER (B) |
| 116 | 885325 | RIBBON SPRING |
| 117 | 885328 | SPRING D8 |
| 118 | 885623 | PUSHING LEVER STOPPER (A) |
| 119 | 886246 | FEEDER KNOB |
| 121 | 885354 | MAGAZINE GUARD |
| 130 | 886470 | SHAFT COVER |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Hitachi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to hitachi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
