Alpina Spare Parts for Brushcutter BC 35 S
€217.20
Tax included
Alpina Spare Parts for Brushcutter BC 35 S
Alpina-Stiga-Castor-Castelgarden-Mountfield authorized repair center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Brushcutter BC 35 S (2013) 281520000/09.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Alpina Spare Parts for Brushcutter BC 35 S
Alpina-Stiga-Castor-Castelgarden-Mountfield authorized repair center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Brushcutter BC 35 S (2013) 281520000/09.
In the following table, look for the model of the Brushcutter and the respective parts of the code.
| ALPINA BC 35 S (2013) 281520000/09 pag.1 | ||
| # | Part Num. | Description |
| 1 | 123071011/0 | Cylinder |
| 2 | 123280050/0 | Cylinder Gasket |
| 4 | 123109555/0 | Cover |
| 5 | 123109556/0 | Cover |
| 6 | 123280032/0 | Gasket |
| 7 | 123878054/0 | Screw |
| 9 | 323106020/0 | cylinder cover Yellow |
| 10 | 123590005/0 | Piston |
| 11 | 123760002/0 | Piston pin |
| 12 | 123204006/0 | Piston Ring |
| 13 | 123202003/0 | Circlip |
| 14 | 123235004/0 | Needle Bearing |
| 15 | 123120005/0 | Nut |
| 21 | 123880006/0 | Flywheel |
| 22 | 123044013/0 | Electronic Ignition coil |
| 23 | 323053003/0 | Spark Plug Cap |
| 24 | 3210024 | Spark Plug |
| 25 | 183065029/0 | Ground Wire |
| 26 | 123280033/0 | Carburettor manifold gasket |
| 27 | 123054030/0 | Carburetor |
| 28 | 123220009/0 | Air filter |
| 29 | 183090009/0 | filter cover Yellow |
| 30 | 123280029/0 | Muffler gasket |
| 31 | 183740014/0 | Muffler |
| 32 | 183215006/0 | Clutch assembly |
| 33 | 183058035/0 | Recoil Starter assembly |
| 34 | 123300007/0 | Recoil Starter handle |
| 35 | 123082003/0 | Starter Cup assembly |
| 36 | 183733006/0 | Tank assembly |
| 37 | 183790008/0 | Fuel Cap Assembly |
| 38 | 183520004/0 | Intake filter |
| 51 | 123685007/0 | Crankcase, clutch side |
| 52 | 123685006/0 | Crankcase, starter side |
| 53 | 114215216/0 | Ball bearing |
| 54 | 119035160/0 | Locking ring |
| 55 | 123208411/0 | Transmission Support Case |
| 56 | 123109560/0 | Cover |
| 58 | 323109535/0 | Housing Yellow |
| 59 | 123878061/0 | Screw |
| 60 | 323109544/0 | Spark Plug Guard Yellow |
| 61 | 323600057/0 | Lower Protection, Yellow |
| 62 | 123020027/0 | Cranck shaft |
| 63 | 123280052/0 | Cylinder Manifold Gasket |
| 64 | 123073510/0 | Intake manifold |
| 65 | 123040002/0 | Air filter Support |
| 66 | 123430587/0 | Spring |
| 67 | 123878060/0 | Screw |
| 68 | 123604009/0 | Starter Pulley |
| 69 | 123430590/0 | Spring |
| 71 | 123275022/0 | Rubber grommet assembly |
| 72 | 123784006/0 | Protection |
| 73 | 123753002/0 | Plug |
| 74 | 123072003/0 | Flywheel Key |
| 75 | 123878066/0 | Screw |
| 76 | 123878064/0 | Screw |
| 77 | 123878063/0 | Screw |
| 78 | 123878065/0 | Screw |
| 79 | 123294002/0 | Guide |
| 80 | 123294003/0 | Guide |
| ALPINA BC 35 S (2013) 281520000/09 pag.2 | ||
| 1 | 3L4121861/1 | Clutch Drum Assembly |
| 2 | 323782007/0 | Transmission Support Assembly |
| 3 | 3353080 | Seeger |
| 4 | 3112170 | Ball bearing |
| 5 | 323275018/0 | grommet |
| 6 | 323720002/0 | Support |
| 7 | 323720003/0 | Support |
| 8 | 2370050 | Washer |
| 9 | 2135030 | Screw |
| 10 | 323044218/0 | Bushing |
| 11 | 2135010 | Screw |
| 14 | 123066016/0 | Throttle cable |
| 15 | 123065000/0 | Ignition Coil-switch cable |
| 16 | 123065014/0 | Ground wire |
| 17 | 323290000/0 | Wire hose |
| 18 | 123878055/0 | Screw |
| 21 | 383300020/0 | Handle assembly |
| 22 | 3654300 | Spring |
| 23 | 3210970 | Stop switch |
| 24 | 323315075/0 | Safety Lever |
| 25 | 323315074/0 | Throttle lever |
| 26 | 1L3654270/1 | Spring |
| 28 | 323170000/0 | Spacer |
| 30 | 2135040 | Screw |
| 31 | 323780000/0 | Brkt, Eng Mounting |
| 32 | 2412030 | Nut |
| 33 | 2135050 | Screw |
| 34 | 2312090 | Washer |
| 35 | 2461030 | Square Nut |
| 36 | 323300001/0 | Front handle |
| 37 | 2132110 | Screw |
| 41 | 383869069/0 | Transmission Hose Assembly |
| 42 | 4251400 | Transmission Shaft Assembly |
| 43 | 3642191 | Bearing Hub |
| 55 | 4253460 | Harness |
| ALPINA BC 35 S (2013) 281520000/09 pag.3 | ||
| 1 | 3L4252780/1 | Gear case assembly Ø26 - Available in Adaptable Version, with Universal Head Adapter and Stone Guard Kit |
| 2 | 2653460 | Screw |
| 3 | 3121170 | Locking ring |
| 4 | 2135050 | Screw |
| 5 | 2653090 | Screw |
| 6 | 2312150 | Washer |
| 7 | 2135060 | Screw |
| 8 | 2135030 | Screw |
| 9 | 3615000 | Wire knife |
| 10 | 112154330/0 | Nut |
| 11 | 2312150 | Washer |
| 12 | 8563570 | Stone guard assembly |
| 13 | 3641700/1 | Gear Case Collar DC D=26 05 |
| 14 | 3641640 | Upper ring nut |
| 15 | 3612640 | Lower ring nut |
| 16 | 4560610 | Fixed Cup |
| 21 | 3L4353000/1 | 2-wire head |
| 22 | 3614950 | plate |
| 23 | 4611880 | 4 Tips Blade |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Alpina websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Alpina brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
BC35S (2013) 281520000/09
11 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10/15 BUSINESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK S/N ALPINA:
- STIGA GROUP S/N START WITH (1 or 2) and have 9 DIGITS
