Hitachi Spare Parts for Rotary Hammer DH30PC2
€2.08
Tax included
Hitachi Spare Parts for Rotary Hammer DH30PC2
Hitachi-HIKOKI original spare parts for to make maintenance, replacement of damaged parts or repair electrical or mechanical components of the Rotary Hammer DH30PC2.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Hitachi Spare Parts for Rotary Hammer DH30PC2
Hitachi-HIKOKI original spare parts for to make maintenance, replacement of damaged parts or repair electrical or mechanical components of the Rotary Hammer DH30PC2.
In the following table, look for the model of the Hammer and the respective parts of the code.
| Rotary Hammer DH30PC2 | ||
| # | Part Num. | Description |
| 1 | 323078 | FRONT CAP |
| 2 | 323077 | GRIP |
| 3 | 306340 | STOPPER RING |
| 4 | 323076 | BALL HOLDER |
| 5 | 323075 | RETAINER SPRING |
| 6 | 325668 | WASHER (D) |
| 7 | 306993 | RETAINING RING |
| 8 | 321313 | SEAL LOCK HEX. SOCKET HD. BOLT M6X22 |
| 9 | 325651 | CYLINDER CASE |
| 10 | 980744 | O-RING (S-55) |
| 11 | 320324 | OIL SEAL |
| 12 | 320325 | DAMPER (B) |
| 13 | 320326 | DAMPER WASHER (B) |
| 14 | 326304 | BALL BEARING 6005DDCMPS2L |
| 15 | 948227 | RETAINING RING FOR D47 HOLE |
| 16 | 325667 | SLEEVE |
| 17 | 959156 | STEEL BALL D7.0 |
| 18 | 325652 | RETAINER SLEEVE |
| 19 | 325658 | NEEDLE PIN |
| 20 | 326301 | SLEEVE (C) |
| 21 | 313420 | RETAINING RING D38 |
| 23 | 325653 | SECOND HAMMER |
| 24 | 323059 | DAMPER WASHER |
| 25 | 323060 | DAMPER |
| 26 | 323061 | DAMPER HOLDER |
| 27 | 323062 | STOPPER RING |
| 28 | 326302 | DAMPER HOLDER (B) |
| 29 | 326303 | DAMPER (C) |
| 30 | 326300 | SLIDE RING |
| 31 | 325660 | STRIKER |
| 32 | 319577 | O-RING (I.D 19.2) |
| 33 | 325656 | SLIDE SLEEVE (B) |
| 34 | 325655 | SLIDE SLEEVE (A) |
| 35 | 325664 | CLUTCH SPRING |
| 36 | 325654 | CYLINDER |
| 37 | 325661 | WASHER (C) |
| 38 | 325662 | LOCK SPRING |
| 39 | 325663 | LOCK SLEEVE |
| 40 | 325665 | CLUTCH |
| 41 | 325666 | BEVEL GEAR |
| 43 | 319581 | PISTON PIN |
| 44 | 319580 | PISTON |
| 45 | 319585 | CONNECTING ROD |
| 46 | 313078 | SIDE HANDLE |
| 47 | 325672 | HANDLE HOLDER |
| 48 | 320973 | STOPPER ROD |
| 49 | 313080 | HANDLE BOLT |
| 50 | 998471 | HEX. SOCKET HD. BOLT (W/FLANGE) M5X12 |
| 51 | 325677 | HOOD |
| 54 | 986940 | SEAL LOCK HEX. SOCKET HD. BOLT M6X45 |
| 56 | 983162 | SEAL LOCK HEX. SOCKET HD. BOLT M4X12 |
| 57A | 331545 | CHANGE LEVER |
| 58 | 321312 | PIN D2X10 |
| 59 | 325671 | LEVER HOLDER |
| 60 | 948391 | RETAINING RING FOR D40 HOLE |
| 61 | 325670 | LEVER SHAFT |
| 62 | 980948 | O-RING |
| 63 | 321310 | LEVER SPRING |
| 64 | 321311 | PUSHING BUTTON |
| 65 | 6001DD | BALL BEARING 6001DDCMPS2L |
| 66 | 971736 | WASHER (B) |
| 67 | 360768E | ARMATURE 220V-230V |
| 68 | 982631 | WASHER (A) |
| 69 | 608VVM | BALL BEARING 608VVC2PS2L |
| 70 | 323083 | FAN GUIDE |
| 71 | 953121 | HEX. HD. TAPPING SCREW D5X50 |
| 72 | 340672E | STATOR ASS'Y 220V-230V |
| 73 | 930703 | BRUSH TERMINAL |
| 74 | 321322 | VINYL TUBE |
| 75 | 981851 | OIL SEAL (B) |
| 76 | 325647 | BEVEL PINION |
| 77 | 325648 | COLLAR |
| 78 | 6001DD | BALL BEARING 6001DDCMPS2L |
| 79 | 992503 | WASHER |
| 80 | 325649 | SECOND GEAR |
| 81 | 971087 | STOPPER WASHER |
| 82 | 959155 | STEEL BALL D3.97 |
| 83 | 992916 | CLUTCH PLATE |
| 84 | 992926 | SPRING PLATE |
| 85 | 980877 | BELLEVILLE SPRING |
| 86 | 325650 | BUSHING |
| 87 | 608VVM | BALL BEARING 608VVC2PS2L |
| 88 | 940079 | RETAINING RING FOR D8 SHAFT |
| 89 | 325646 | SLIP CLUTCH ASS'Y |
| 90 | 325669 | CRANK CASE COVER |
| 91 | 980715 | O-RING (S-48) |
| 92 | 325644 | CRANK SHAFT |
| 93 | 944109 | FEATHER KEY 3X3X8 |
| 94 | 325643 | CRANK CASE |
| 95 | 6002DD | BALL BEARING 6002DDCMPS2L |
| 96 | 872767 | O-RING (S-32) |
| 97 | 948001 | RETAINING RING FOR D32 HOLE |
| 98 | 325645 | FIRST GEAR |
| 99 | 939299 | NEEDLE BEARING (M661) |
| 100 | 325674 | GEAR COVER |
| 101 | 325680 | HANDLE (A).(B) SET |
| 102 | 994192 | HEX. SOCKET HD. BOLT (W/FLANGE) M5X16 |
| 103 | 302089 | TAPPING SCREW (W/FLANGE) D5X20 (BLACK) |
| 104 | 307028 | TAPPING SCREW (W/FLANGE) D4X25 (BLACK) |
| 106 | 325673 | HOUSING ASS'Y |
| 107 | 945161 | BRUSH CAP |
| 108 | 999073 | CARBON BRUSH (AUTO STOP TYPE) (1 PAIR) |
| 109 | 958900 | BRUSH HOLDER |
| 111 | 310111 | BEARING BUSHING (B) |
| 112 | 323085 | TAIL COVER |
| 113 | 307811 | TAPPING SCREW (W/FLANGE) D4X16 (BLACK) |
| 114 | 317492 | SUPPORT (B) |
| 115 | 325675 | SWITCH (2P PILLAR TYPE) |
| 116 | 994190 | INTERNAL WIRE |
| 117 | 994273 | NOISE SUPPRESSOR |
| 118 | 317492 | SUPPORT (B) |
| 119 | 959140 | CONNECTOR 50091 |
| 120 | 984750 | TAPPING SCREW (W/FLANGE) D4X16 |
| 121 | 960266 | CORD CLIP |
| 122 | 953327 | CORD ARMOR D8.8 |
| 122 | 938051 | CORD ARMOR D10.1 |
| 124 | 326651 | FELT PACKING |
| 125 | 323058 | O-RING (C) |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Hitachi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to hitachi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
