Hitachi Spare Parts for Cordless Impact Driver Drill DV18DBSL

€2.76
Tax included

Hitachi Spare Parts for Cordless Impact Driver Drill DV18DBSL

Hitachi-HIKOKI original spare parts to replace worn components or repair damaged parts of the Cordless Impact Driver Drill DV18DBSL.

Powerful 18 V reversible percussion drill with two 5 Ah high-performance lithium batteries.
ITEM CODE: 744087
Quantity
Usually Ships in: 7/10 Business Days Approx.

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Hitachi Spare Parts for Cordless Impact Driver Drill DV18DBSL

Hitachi-HIKOKI original spare parts to replace worn components or repair damaged parts of the Cordless Impact Driver Drill DV18DBSL.

In the following table, look for the model of the Cordells Impact Drill and their spare part.
Hitachi DV18DBSL

Hitachi Cordless Impact Driver Drill DV18DBSL Pag.1
# Part Num. Description
1 744087 SPECIAL SCREW M6X25 LEFT FOR EUROPE.RUS
2 335961 Drill Chuck 13Vlrun (W/O Chuck Wrench)
3 370593 Gear Box Assembly, Includes #435
4 370611 Clutch Dial (B)
5 327146 Click Spring
6 370602 SPRING COLLAR
7 370607 SPRING
8 370603 SPRING PLATE
9 370597 Spindle
10 327136 SPRING C
11 339772 Ratchet (B)
12 327147 WASHER A
13 339773 Slip Block
14 327133 Stopper Spring
15 370595 Front Case
16 328717 WASHER B
17 370609 LOCK RING
18 319744 ROLLER
19 333539 Pin Set (6 Pcs.)
20 370606 RING GEAR
21 370600 Carrier
22 370616 Planet Gear (C) Set (5 Pcs.)
23 331892 WASHER A
24 331895 Screw Set D2 (2 Pcs.)
25 370608 Shift Arm (NEW)
26 370601 REAR GEAR
28 370605 Slide Ring Gear
29 370599 PINION (C)
30 370615 Planet Gear (B) Set (4 Pcs.)
31 370598 PINION (B)
32 370614 32. Planet Gear (A) Set (4 Pcs.)
33 370604 First Ring Gear
34 339761 Washer (B)
35 339762 MOTOR SPACER
36 361048 Rotor Pinion Set
37 370619 Wiring Assembly, Includes #43,47
38 330583 Shift Knob
41 339768 SELECTOR
42 370618 Housing (A).(B) Set
43 370151 SWITCH
45 332824 HOOK
47 339769 Battery Terminal
48 306952 STRIPPER STRIP.
50 373529 PINION DV18DBSL
STANDARD ACCESSORIES Pag.2
504 337852 CASE X WR / WH14 / 18DBDL
505 402545 BOX HIT-SYSTEM CASE 2 EMPTY INCLUDE.506-508
506 336472 CLIP
507 336473 HANDLE
508 336474 PIN
509 336475
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s HITACHI websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to HITACHI brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
