Hitachi Spare Parts for Hammer Drill DH40SR
€1.35
Tax included
Hitachi Spare Parts for Hammer Drill DH40SR
We have the original Spares Hitachi-HIKOKI for Hammer Drill DH40SR the diagram, parts list and tool repair that help you need to get your tools running like new again.Fix Your Hammer Drill DH40SR. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Hitachi Spare Parts for Hammer Drill DH40SR
Fix Your Hammer Drill DH40SR. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following table, look for the model of the Hammer Drill and their spare part.
| HAMMER DRILL HITACHI DH40SR | ||
| # | Part Num. | Description |
| 1 | 990131 | RETAINER |
| 2 | 322078 | DUST COVER DH40SR |
| 3 | 981942 | SEAL LOCK HEX. SOCKET HD. BOLT M6X25 |
| 4 | 991697 | ROLL PIN D4X20 |
| 5 | 990135 | RETAINER PIN |
| 6 | 990134 | DAMPER (B) |
| 7 | 990133 | PUSHING BUTTON |
| 8A | 331239 | SET SPRING (EX 990132) |
| 9 | 321844 | FRONT COVER (A) ASSY DH40SR |
| 10 | 956996 | O-RING 1AS.60 |
| 11 | 321843 | DAMPER (B) DH40SR |
| 12 | 321842 | DRIVER HOLDER DH40SR |
| 13 | 321841 | DRIVER DH40SR |
| 14 | 321840 | OIL SEAL (B) DH40SR |
| 15 | 321839 | RETAINING RING FOR D62 HOLE |
| 16 | 948131 | RETAINING RING FOR D35 SHAFT |
| 17 | 6007DD | BALL BEARING 6007DD |
| 18 | 321297 | BEARING WASHER |
| 19 | 981859 | URETHANE RING |
| 20 | 321838 | RING HOLDER DH40SR |
| 21 | 321837 | HAMMER SLEEVE DH40SR |
| 22 | 313396 | O-RING © |
| 23 | 321833 | SECOND HAMMER DH40SR |
| 24 | 321836 | DAMPER WASHER DH40SR |
| 25 | 321835 | DAMPER |
| 26 | 321834 | DAMPER HOLDER |
| 27 | 321856 | DAMPER HOLDER (B) DH40SR |
| 28 | 321832 | DAMPER © |
| 29 | 321831 | SLIDE RING DH40SR |
| 30 | 313057 | NEEDLE PIN D6X6 |
| 31 | 321827 | CYLINDER DH40SR |
| 32 | 321830 | SLIDE SLEEVE (B) DH40SR |
| 33A | 326512 | SLIDE SLEEVE (A) SET DH40SR / MR |
| 34 | 321828 | SPRING (A) DH40SR / MR |
| 36 | 321976 | STRIKER DH40SR |
| 37 | 986104 | O-RING |
| 38 | 321975 | CLUTCH DH40SR / MR |
| 39 | 321284 | PISTON DH40MR |
| 40 | 980708 | PISTON PIN |
| 41 | 321285 | CONNECTING ROD DH40MR |
| 42 | 321296 | BEVEL GEAR DH40MR |
| 46 | 321315 | CRANK COVER DH40MR |
| 48A | 335023 | RUBBER SEAL DH40MR |
| 49 | 939540 | RETAINING RING FOR D10 SHAFT (10 PCS.) |
| 50 | 321275 | CRANKSHAFT DH40MR |
| 51 | 944109 | FEATHER KEY 3X3X8 3X3X8 |
| 52 | 948391 | RETAINING RING FOR D40 HOLE |
| 53 | 6203DD | BALL BEARING 6203DD |
| 54 | 996363 | O-RING (S-40) |
| 55 | 321274 | OIL SEAL (B) |
| 56 | 321826 | CYLINDER CRANK CASE DH40SR |
| 57 | 321278 | BEVEL PINION DH40MR |
| 58 | 944109 | FEATHER KEY 3X3X8 |
| 59 | 321279 | COLLAR |
| 60 | 313050 | OIL SEAL (A) |
| 61 | 6002DD | BALL BEARING 6002DD |
| 62 | 313058 | WASHER |
| 63 | 313053 | WASHER (A) |
| 64 | 321281 | GEAR HOLDER DH40MRY |
| 65 | 321282 | SPRING C FRIZ.DH40MRY |
| 66 | 320343 | NEEDLE |
| 67 | 321280 | SECOND GEAR DH40MR |
| 68 | 321283 | SPACER DH40MR |
| 69 | 629VVM | BALL BEARING 629VVM |
| 70 | 944525 | BEARING WASHER (C) |
| 71 | 321277 | SLIP CLUTCH ASSY INCLUD.57-59 61-69 DH40MR |
| 72 | 321276 | FIRST GEAR DH40MR |
| 73 | 939299 | NEEDLE BEARING (M661) |
| 74 | 321319 | GEAR COVER DH40MR |
| 75 | 313078 | SIDE HANDLE |
| 76 | 313079 | HANDLE HOLDER |
| 77 | 313080 | HANDLE BOLT |
| 78 | 971786 | STOPPER ROD |
| 79 | 6201DD | BALL BEARING 6201DD |
| 80 | 302429 | DUST WASHER |
| 81 | 321640 | FAN H45MR |
| 82 | 360591E | ARMATURE ASSY 220V-230V INCLUD.81 DH40MR-MRY |
| 83 | 321320 | FAN GUIDE DH40MR FAN |
| 85 | 340542E | STATOR ASSY 240V DH40MR |
| 86 | 982631 | WASHER |
| 87 | 608VVM | BALL BEARING 608VVM |
| 88 | 318721 | MAGNET |
| 90 | 935829 | BRUSH CAP |
| 91 | 999073 | CARBON BRUSH (AUTO STOP TYPE) (1 PAIR) |
| 92 | 971001 | BRUSH HOLDER |
| 93 | 938477 | HEX. SOCKET SET SCREW M5X8 |
| 94 | 321321 | TAIL COVER DH40MR |
| 96 | 930703 | BRUSH TERMINAL |
| 97 | 321322 | VINYL TUBE L35 |
| 98 | 321318 | HOUSING ASSY DH40MR |
| 99 | 321858 | CASE (B) DH40SR |
| 100 | 321862 | CONTROLLER CIRCUIT DH40SR |
| 101 | 317113 | INTERNAL WIRE |
| 102 | 321859 | HANDLE DH40MR / SR |
| 104 | 313093 | SWITCH (C) (2P SCREW TYPE W/O LOCK) |
| 105 | 321324 | HANDLE COVER DH40MR |
| 108 | 980063 | TERMINAL |
| 109 | 940778 | CORD ARMOR D10.7 10.7 |
| 110 | 938307 | PILLAR TERMINAL (OLD 938307Z / 512-31 |
| 111 | 960266 | CORD CLIP |
| 113 | 714520 | CORD 5M 2X1.5 WITH PLUG |
| 114 | 324481 | METAL DH40SR |
| STANDARD ACCESSORIES | ||
| 501 | 321325 | CASE |
| 502 | 981840 | GREASE PACK OF 30G |
| 503 | 943277 | KEY |
| 504 | 944458 | ALLEN KEY |
| 505 | 944459 | KEY |
