Hitachi Spare Parts for Impact Drill DV16VSS

Impact Drill DV16VSS
#	Part Num.	Description
1	995344	SCREW M6X25 SX
4	948001	RETAINING RING FOR D32 HOLE
5	971654	DUST SEAL
6	331522	SPINDLE
7	322514	SPRING
8	330682	DISTANCE RING
9	6002VV	BALL BEARING 6002VVCMPS2L
10	939544	RETAINING RING FOR D15 SHAFT
12	330726	GEAR COVER
13	330683	GEAR
14	959150	STEEL BALL D6.35
17	330677	RATCHET
18	330678	BUSHING
19	330679	BOLT M3
20	330676	CHANGE PLATE
21	330675	INNER COVER
22	322510	CHANGE LEVER
23	323096	FELT PACKING
24	330674	WASHER (A)
25	608DDM	BALL BEARING 608DD
27	330673	FAN GUIDE
28	950515	TAPPING SCREW D4X50
29	340742F	STATOR 220V-240V
30	608VVM	BALL BEARING 608VVC2PS2L
31	330715	HANDLE COVER
34	330714	HOUSING
36	955203	BRUSH HOLDER
37	999041	CARBON BRUSH (1 PAIR)
38	981373	TUBE (D)
39	937631	CORD CLIP
41	330716	SWITCH AC250V
44	938051	CORD ARMOR D10.1
47	994273	NOISE SUPPRESSOR
502	303709	DEPTH GAUGE
