Hitachi Spare Parts for Demolition Hammer DH40MEY
Hitachi-HIKOKI Tanaka authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair issues for Demolition Hammer DH40MEY.
In the following table, look for the model of the Demolition Hammer and the respective parts of the code.
| Demolition Hammer DH40MEY | ||
| # | Part Num. | Description |
| 1 | 337562 | FRONT CAP |
| 2 | 337560 | GRIP |
| 3 | 318590 | STOPPER RING |
| 4 | 337561 | RETAINER WASHER |
| 5 | 337559 | RETAINER DAMPER (A) |
| 6 | 337558 | BIT LOCK HOLDER |
| 7A | 370242 | SPRING HOLDER (A) |
| 8 | 337556 | RETAINER SPRING |
| 9 | 337557 | SPRING HOLDER (A) |
| 11 | 337553 | CYLINDER CASE COVER |
| 13A | 337552 | CYLINDER CASE |
| 14 | 956996 | O-RING (1AS-60) |
| 15 | 337549 | RETAINER DAMPER HOLDER |
| 16 | 337548 | RETAINER DAMPER (B) |
| 17 | 337547 | RETAINER DAMPER WASHER |
| 18A | 370654 | BIT LOCK |
| 19 | 337536 | RETAINER SLEEVE |
| 20 | 313396 | O-RING (C) |
| 21 | 337537 | SECOND HAMMER |
| 22 | 337538 | DAMPER WASHER |
| 23 | 321835 | DAMPER |
| 24 | 337539 | DAMPER HOLDER |
| 25 | 337540 | CYLINDER |
| 26 | 337541 | STRIKER |
| 27 | 986104 | O-RING |
| 28 | 337550 | SPRING HOLDER (B) |
| 29 | 337551 | LOCK SPRING |
| 30 | 331535 | LOCK SLEEVE |
| 31 | 337542 | CLUTCH SPRING |
| 32 | 337543 | CLUTCH |
| 33 | 337544 | SLIDER |
| 34 | 337545 | BEVEL GEAR |
| 35 | 337546 | THRUST WASHER |
| 36 | 986104 | O-RING |
| 37 | 980708 | PISTON PIN |
| 38 | 326369 | PISTON |
| 39 | 337535 | CONNECTING ROD ASS'Y |
| 40 | 335303 | NEEDLE BEARING |
| 42 | 340885E | STATOR SENSOR PCB SET 220V-240V |
| 43 | 958915 | WASHER (A) |
| 44 | 629VVM | BALL BEARING 629VV |
| 46A | 333263 | DUST SEAL |
| 47A | 370002 | TAIL COVER |
| 49 | 337580 | CONTROLLER SET 220V-240V |
| 54 | 991711 | DISTANCE PIECE (B) |
| 55 | 337590 | HANDLE (B) |
| 56 | 310124 | HANDLE DAMPER |
| 57 | 310123 | TRANSATORY UNIT |
| 58 | 337586 | FILTER PCB SET 220V-240V |
| 59 | 338447 | SPONGE (B) |
| 60 | 337573 | BACK COVER |
| 61 | 337591 | BELLOWS |
| 62 | 337588 | TRIGGER |
| 63 | 337587 | SWITCH |
| 64 | 337589 | HANDLE (A) |
| 65 | 320218 | O-RING |
| 66 | 994192 | HEX. SOCKET HD. BOLT (W/FLANGE) M5X16 |
| 68 | 940778 | CORD ARMOR D10.7 |
| 69 | 960266 | CORD CLIP |
| 73 | 337574 | HOLDER |
| 74 | 326377 | HANDLE SHAFT |
| 76 | 330209 | SIDE HANDLE |
| 77 | 337577 | WING BOLT |
| 78 | 337576 | MOUNT |
| 79 | 949556 | NUT M6 |
| 80 | 949859 | ROLL PIN D2X8 |
| 81 | 331247 | HANDLE BOLT |
| 82 | 337575 | BAND |
| 83 | 337531 | CRANK SHAFT |
| 84 | 940533 | FEATHER KEY 3X3X10 |
| 85 | 948391 | RETAINING RING FOR D40 HOLE |
| 86 | 996363 | O-RING (S-40) |
| 87 | 6203DD | BALL BEARING 6203DDCMPS2L |
| 88 | 321274 | OIL SEAL (B) |
| 89 | 337530 | CRANK CASE |
| 90 | 337571 | WASHER |
| 91 | 337569 | WEIGHT |
| 92 | 337572 | WEIGHT SPRING |
| 93 | 337570 | WEIGHT SHAFT |
| 94 | 944109 | FEATHER KEY 3X3X8 |
| 95A | 337592 | CRANK CASE COVER |
| 96 | 337567 | LEVER SPRING |
| 97 | 959149 | STEEL BALL D4.76 |
| 98 | 307811 | TAPPING SCREW (W/FLANGE) D4X16 (BLACK) |
| 99 | 337566 | CHANGE LEVER |
| 100 | 337568 | GUIDE PLATE |
| 101 | 337564 | CRANK COVER |
| 102 | 877315 | CYLINDER O-RING (I.D 63.9) |
| 103 | 338312 | O-RING |
| 104 | 337565 | LEVER SHAFT |
| 105 | 337563 | CHANGE PLATE |
| 106 | 338315 | FELT (B) |
| 108 | 949424 | WASHER M5 |
| 109 | 338314 | FELT (A) |
| 110 | 338313 | CAP SCREW |
| 111 | 995396 | VALVE |
| 112 | 337581 | PANEL |
| 114 | 337533 | SLIP CLUTCH ASS'Y |
| 115 | 337534 | BEVEL PINION |
| 116 | 321279 | COLLAR |
| 117 | 313050 | OIL SEAL (A) |
| 118 | 6002DD | BALL BEARING 6002DDCMPS2L |
| 119 | 313058 | WASHER |
| 120 | 313053 | WASHER (A) |
| 121 | 321281 | GEAR HOLDER |
| 122 | 320343 | NEEDLE |
| 123 | 321282 | SPRING (C) |
| 124 | 331215 | SECOND GEAR |
| 125 | 321283 | SPACER |
| 126 | 629VVM | BALL BEARING 629VV |
| 127 | 944525 | BEARING WASHER (C) |
| 128 | 337532 | FIRST GEAR |
| 129 | 939299 | NEEDLE BEARING (M661) |
| 130 | 337583 | GEAR COVER |
| 132 | 6201DD | BALL BEARING 6201DDCMPS2L |
| 133 | 302429 | DUST WASHER (B) |
| 134 | 337578 | ROTOR |
| 135 | 339910 | SPACER |
| 501 | 981840 | GREASE (A) FOR HAMMER.HAMMER DRILL (30G) |
| 502 | 337594 | CASING |
| 601A | 308471 | GREASE FOR HAMMER.HAMMER DRILL (70G) |
| 602A | 980927 | GREASE FOR HAMMER.HAMMER DRILL (500G) |
