Hitachi Spare Parts for Router M12V2
€11.16
Tax included
Hitachi Spare Parts for Router M12V2
We have the original Spares Hitachi-HIKOKI for Router M12V2, the diagram, parts list and tool repair that help you need to get your tools running like new again.Fix Your Router M12V2. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Hitachi Spare Parts for Router M12V2
Fix Your Hitachi-HIKOKI Router M12V2. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following table, look for the model of the Routers and theirs spare part.
| Router M 12V2 Pag.1 |
||
| # | Part Num. | Description |
| 2 | 305490 | TAPPING SCREW (W/FLANGE) D4X30 (BLACK) |
| 3 | 325168 | HEAD COVER |
| 5 | 325368 | CONTROLLER CIRCUIT (A) DIAL SET 230V |
| 6 | 301797 | MAGNET |
| 7 | 954017 | TAPPING SCREW D4X12 |
| 8 | 325169 | BEARING BUSHING |
| 9 | 325184 | RUBBER RING |
| 10 | 6200VV | BALL BEARING 6200VVCMPS2L |
| 11 | 959141 | CONNECTOR 50092 |
| 12 | 961820 | TUBE (D) |
| 13 | 953327 | CORD ARMOR D8.8 |
| 13 | 938051 | CORD ARMOR D10.1 |
| 14 | 984750 | TAPPING SCREW (W/FLANGE) D4X16 |
| 15 | 937631 | CORD CLIP |
| 16 | 981373 | TUBE (D) |
| 17 | 325203 | CORD HOLDER |
| 18 | 302086 | TAPPING SCREW (W/FLANGE) D4X20 (BLACK) |
| 19 | 325170 | FRONT COVER (B) |
| 20 | 325198 | MARKER |
| 21 | 305812 | TAPPING SCREW (W/FLANGE) D4X16 (BLACK) |
| 22 | 325197 | POLE HOLDER |
| 23 | 325219 | HOUSING ASS'Y |
| 24 | 325196 | STOPPER POLE (A) |
| 25 | 958032 | BRUSH TERMINAL |
| 26 | 340659G | STATOR ASS'Y 230V |
| 27 | 961400 | HEX. HD. TAPPING SCREW D5X70 |
| 28 | 360748E | ARMATURE 230V-240V |
| 29 | 325960 | LEVER |
| 30 | 301821 | SWITCH (2P PILLAR TYPE) W/O LOCK |
| 31 | 938477 | HEX. SOCKET SET SCREW M5X8 |
| 32 | 980487 | BRUSH HOLDER |
| 33 | 999044 | CARBON BRUSH (1 PAIR) |
| 34 | 940540 | BRUSH CAP |
| 36 | 500234Z | CORD |
| 37 | 307443 | MACHINE SCREW (W/WASHERS) M6X30 (BLACK) |
| 38 | 325220 | HANDLE (L) B |
| 39 | 325171 | HANDLE (L) A |
| 40 | 325180 | SPRING GUIDE |
| 41 | 325177 | PLUNGE SPRING (R) |
| 42 | 325214 | KNOB (B) ASS'Y |
| 43 | 872654 | O-RING (1AP-10) |
| 44 | 935196 | MACHINE SCREW (W/WASHERS) M4X12 (BLACK) |
| 45 | 984509 | SEAL LOCK HEX. SOCKET HD. BOLT M5X14 |
| 46A | 325194 | KNOB (C) |
| 47 | 325195 | GUIDE SLEEVE |
| 48 | 325176 | PLUNGE SPRING (L) |
| 49 | 301801 | WING BOLT M6X27 |
| 52 | 325173 | FRONT COVER (C) |
| 53 | 325205 | END BRACKET |
| 54 | 325193 | SPRING |
| 55 | 325192 | SPECIAL NUT TR12 |
| 56 | 325191 | SPECIAL BOLT M20 |
| 57 | 949811 | HEX. SOCKET HD. BOLT M4X8 |
| 58 | 325190 | LEVER (B) |
| 59 | 985033 | HEX. SOCKET SET SCREW M6X6 |
| 60 | 971848 | LOCK PIECE |
| 61 | 325187 | LOCK SCREW M10 |
| 62A | 323923 | LEVER (A) |
| 63 | 997314 | MACHINE SCREW (W/WASHERS) M6X10 |
| 64 | 325172 | HANDLE (R) A |
| 66 | 325202 | CORD (A) |
| 67 | 325962 | HANDLE (R) B |
| 68 | 307100 | TAPPING SCREW D5X50 |
| 69 | 6004VV | BALL BEARING 6004VVCMPS2L |
| 70 | 325186 | THRUST NUT |
| 71 | 325185 | BEARING COVER |
| 72 | 325183 | LOCK SPRING (A) |
| 73 | 325182 | PUSHING BUTTON |
| 74 | 325199 | COLLET CHUCK 12MM |
| 75 | 325207 | BELLOWS (A) |
| 76 | 325189 | SPECIAL BOLT TR12 |
| 77 | 325188 | WASHER |
| 78 | 325210 | DUST GUIDE |
| 79 | 325215 | DUST GUIDE ADAPTER |
| 80 | 949662 | HEX. SOCKET HD. BOLT M5X25 |
| 81 | 302012 | NUT M5 (BLACK) |
| 82 | 325181 | STOPPER BLOCK |
| 83 | 317200 | MACHINE SCREW (W/WASHERS) M4X8 (BLACK) |
| 84 | 962569 | WASHER (B) |
| 85 | 971858 | SPRING (A) |
| 86 | 949765 | HEX. SOCKET HD. BOLT M5X12 |
| 87 | 325178 | STOPPER BOLT |
| 88 | 949558 | NUT M8 |
| 89 | 325342 | BASE |
| 90 | 325179 | SUB BASE |
| 91 | 992013 | SEAL LOCK FLAT HD. SCREW M5X14 |
| 92 | 325211 | TEMPLATE GUIDE ADAPTER |
| 93 | 949234 | MACHINE SCREW M5X6 |
| 94 | 956790 | TEMPLATE GUIDE D18 |
| 95 | 301806 | WING BOLT M6X15 |
| 96 | 947859 | LOCK SPRING |
| ACCESSORIES Pag.2 |
||
| 501 | 956797 | STRAIGHT GUIDE |
| 502 | 325216 | GUIDE BAR (A) |
| 503 | 301806 | WING BOLT M6X15 |
| 505 | 325212 | COLLET CHUCK 8MM HIT |
| 505 | 323293 | COLLET CHUCK 1/4 FOR NZL |
| 507 | 325222 | CASE EXCEPT FOR USA |
| 508 | 325217 | BAR HOLDER |
| 510 | 956793 | FEED SCREW |
| 602 | 307801 | COLLET CHUCK 1/2 EXCEPT FOR NZL |
| 603 | 23293 | COLLET CHUCK 1/4 EXCEPT FOR NZL |
| 613 | 956794 | TRIMMER GUIDE |
| 616 | 956801 | DOUBLE FLUSH TRIMMING BIT (TCT) D6X6 |
| 617 | 956806 | FLUSH TRIMMING BIT (TCT) D12X12 |
| 620 | 956810 | STRAIGHT BIT (TCT) D12X12 |
| 621 | 956809 | STRAIGHT BIT (TCT) D12X10 |
| 624 | 956812 | ROUND OVER BIT (TCT) D12XR6X20 |
| 625 | 956811 | ROUND OVER BIT (TCT) D12XR4.5X19 |
| 626 | 956814 | CHAMFERING BIT (TCT) 45? D6X20 |
| 627 | 956816 | DOVETAIL BIT (TCT) D8X15 |
| 628 | 956815 | DOVETAIL BIT (TCT) D6X12 |
| 634 | 303349 | TEMPLATE GUIDE D11.1 |
| 639 | 956932 | TEMPLATE GUIDE D20 |
| 640 | 303354 | TEMPLATE GUIDE D24 |
| 641 | 956933 | TEMPLATE GUIDE D27 |
| 642 | 956934 | TEMPLATE GUIDE D30 |
| 643 | 303355 | TEMPLATE GUIDE D40 |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s HITACHI websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to HITACHI brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
