Hitachi Spare Parts for Chainsaw CS30EG
€1.68
Tax included
Hitachi Spare Parts for Chainsaw CS30EG
Hitachi-HIKOKI Tanaka authorized service center and original spare parts Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Chainsaw CS30EG.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Hitachi Spare Parts for Chainsaw CS30EG
Hitachi-HIKOKI Tanaka authorized service center and original spare parts Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Chainsaw CS30EG.
In the following table, look for the model of Chainsaw and the respective parts of the code.
| Hitachi-HIKOKI Tanaka Chainsaw CS30EG | ||
| # | Part Num. | Description |
| 1 | 6687468 | SPARK PLUG CAP ASS'Y |
| 3 | 6685457 | CYLINDER SET |
| 4 | 6685724 | CYLINDER GASKET |
| 5 | 6685879 | PISTON SET |
| 6 | 6685078 | CIRCLIP |
| 7 | 6685331 | PISTON RING (XR1-1856) |
| 8 | 6686008 | PISTON PIN |
| 9 | 6684903 | HEX. HOLE BOLT M5X16/S |
| 12 | 6687700 | IGNITION COIL COMP. |
| 14 | 6695407 | HIGH TENSION SCREW 4X18WS |
| 15 | 6684899 | WOODRUFF KEY 3X13X4.5 |
| 16 | 6692900 | CORD INSULATOR TUBE |
| 22 | 6685095 | NEEDLE ROLLER 2.5X9.8 |
| 23 | 6685096 | BALL BEARING 6201 A2C3 |
| 25 | 6684668 | HEX.HOLE BOLT M5X20/S |
| 27 | 6685101 | D4E RETAINING RING |
| 28 | 6685105 | STARTER PAWL SPRING |
| 29A | 6685334 | STARTER PAWL |
| 30 | 6685103 | BOLT WASHER M7 |
| 31 | 6685104 | FLYWHEEL NUT |
| 32 | 6685098 | SHIM S T0.2 |
| 32 | 6685099 | SHIM S T0.3 |
| 32 | 6686475 | SHIM 0.4 |
| 33 | 6695222 | S.WASHER 7 |
| 40 | 6691365 | ENGINE CASE ASS'Y, VERMILION |
| 41 | 6685173 | AIR VENT VALVE (B) |
| 42 | 6697231 | AIR VENT VALVE SET |
| 43 | 6684634 | HEX.HOLE BOLT 5X20/PS |
| 44 | 6697602 | EARTH CORD 90M |
| 50 | 6686302 | CLEANER COVER |
| 50A | 6686299 | AIRCLEANER COVER A SET, SPARE |
| 51 | 6689735 | CLEANER COVER BOLT |
| 52 | 6690064 | AIRCLEANER ELEMENT COMP. |
| 53 | 6689935 | INSULATOR SET |
| 54 | 6689871 | INSULATOR GASKET |
| 55 | 6690001 | CARBURETOR INSULATOR RUBBER |
| 56 | 6689806 | VALVE HOLDER |
| 57 | 6689803 | REED VALVE |
| 60 | 6690667 | CARBURETOR SET,WT-760 |
| 61 | 6695350 | SCREW 5X45S |
| 63 | 6684864 | SMALL WASHER 5 |
| 66 | 6687344 | AIRCLEANER COVER B |
| 67 | 6684668 | HEX.HOLE BOLT M5X20/S |
| 68 | 6684864 | SMALL WASHER 5 |
| 69 | 6685224 | IDLE SPONGE |
| 71 | 6690355 | AIRCLEANER SPONGE |
| 72 | 6687182 | SEAL COVER |
| 81 | 6692447 | MUFFLER SET |
| 82 | 6692734 | MUFFLER GASKET |
| 85 | 6692833 | MUFFLER COUPLING GASKET |
| 87 | 6695054 | HEX. HOLE BOLT 5X40 |
| 88 | 6684661 | WASHER 5 |
| 101 | 6691121 | OIL PIPE B |
| 102 | 6692312 | CLIP 7 |
| 103 | 6684661 | WASHER 5 |
| 104 | 6690919 | OIL FILTER |
| 105 | 6685249 | OIL FILTER BODY ASS'Y |
| 106 | 6690974 | THROTTLE ROD |
| 107 | 6690982 | THROTTLE GUIDE |
| 108 | 6685139 | PRIMING PUMP COMP. |
| 110 | 6692292 | RUBBER PIPE |
| 113 | 6697846 | RETURN GROMMET |
| 115 | 6687957 | ADJUSTER CAP |
| 116 | 6692590 | GROMMET |
| 117 | 6692513 | CHOKE BUTTON COMP. |
| 118 | 6687976 | GROMMET |
| 120 | 6692159 | OIL TANK CAP ASS'Y |
| 121A | 6692121 | TANK CAP ASS'Y |
| 131 | 6692909 | RECOIL STARTER ASS'Y OR |
| 132 | 6686950 | FAN CASE COMP. OR |
| 134 | 6693168 | ROPE |
| 135 | 6693138 | RECOIL SPRING |
| 136 | 6693094 | SPRING CASE ASS'Y |
| 137 | 6693061 | STARTER PULLEY |
| 138 | 6687947 | SPECIAL WASHER 5.2X15 |
| 139 | 6685275 | TAPPING SCREW D5X14 |
| 140 | 6685191 | TAPPING SCREW D4.5X20 |
| 141 | 6687326 | AIR DEFLECTOR |
| 143 | 6693230 | STARTER HANDLE |
| 145 | 6685183 | DAMPER SPRING |
| 146 | 6685185 | SPRING CASE SET |
| 147 | 6685184 | STARTER PULLEY |
| 148 | 6684679 | SET SCREW |
| 149 | 6685182 | CAM PLATE |
| 161 | 6684700 | INLET SCREEN |
| 163 | 6685210 | SCREW |
| 164 | 6685212 | PUMP GASKET |
| 165 | 6685213 | PUMP DIAPHRAGM |
| 168 | 6685217 | CONTROL LEVER |
| 169 | 6685218 | HINGE PIN SET SCREW |
| 171 | 6685219 | HINGE PIN |
| 173 | 6690827 | METERING DIAPHRAGM COMP. |
| 174 | 6685220 | DIAPHRAGM PACKING-METERING |
| 175 | 6685215 | NEEDLE VALVE |
| 176 | 6685297 | IDLE ADJUST SPRING |
| 177 | 6685298 | IDLE ADJUST SCREW |
| 180 | 6685223 | SET SCREW |
| 192 | 6686763 | OIL PUMP COVER |
| 193 | 6691223 | OIL PIPE A |
| 194 | 6686645 | SCREW GEAR |
| 195 | 6691400 | AIR VENT SPONGE |
| 196 | 6687324 | OIL PUMP ASS'Y |
| 197 | 6690956 | OIL ADJUST GROMMET |
| 198 | 6691070 | OIL PUMP ADJUSTER |
| 200 | 6686681 | OIL PUMP CASE SET, SPARE |
| 202 | 6685275 | TAPPING SCREW D5X14 |
| 203 | 6685154 | FUEL PIPE |
| 204 | 6685155 | CHAIN CATCHER |
| 221 | 6685166 | NUT |
| 221A | 6687105 | CHAIN BAR CLAMP NUT |
| 222 | 6685142 | CLUTCH COMP. |
| 223 | 6685143 | NEEDLE BEARING |
| 224 | 6685144 | CLUTCH HOUSING COMP. |
| 225 | 6685145 | CLUTCH WASHER |
| 226 | 6685161 | TAPPING SCREW D4X10 |
| 228 | 6685146 | CRANK SHAFT COLLAR |
| 229 | 6685161 | TAPPING SCREW D4X10 |
| 231 | 6690756 | GUIDE PLATE B |
| 234 | 6685168 | GEAR (A) |
| 235 | 6697958 | BRAKE HANDLE COMP. |
| 236 | 6689712 | BRAKE LINK COVER, BLACK |
| 238 | 6685119 | BRAKE SUPPORT PLATE COMP. |
| 239 | 6685141 | NEEDLE ROLLER 3X9.8 |
| 240 | 6685388 | BRAKE LINK |
| 241 | 6689728 | BRAKE BAND |
| 242 | 6690805 | CLEANER FIXING COLLAR |
| 243 | 6685120 | COLLAR |
| 245 | 6685122 | BRAKE LEVER SPRING |
| 246 | 6685148 | TAPPING SCREW D4X15 |
| 262 | 6695108 | TAPPING SCREW 5X40 |
| 263 | 6688480 | DAMPER COLLAR A |
| 264 | 6688117 | DAMPER A |
| 266 | 6685645 | REAR HANDLE B COMP. |
| 267 | 6692680 | PUSH PIN CAP |
| 268 | 6686447 | STOPPER SPRING |
| 269 | 6686430 | PUSH PIN |
| 270 | 6688363 | TRIGGER LOCKOUT VERMILION |
| 271 | 6686392 | THROTTLE LEVER |
| 272 | 6686416 | THROTTLE LEVER SPRING |
| 273 | 6685620 | REAR HANDLE |
| 274 | 6695107 | TAPPING SCREW 5X35 |
| 275 | 6685148 | TAPPING SCREW D4X15 |
| 276 | 6688083 | FRONT HANDLE |
| 277 | 6688412 | DAMPER B |
| 278 | 6688485 | DAMPER COLLAR B |
| 279 | 6695107 | TAPPING SCREW 5X35 |
| 504 | 6686632 | 4X50 MINUS DRIVER |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Hitachi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to hitachi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
