Hitachi Spare Parts for Brush Cutter CG24EKS
Hitachi-HIKOKI Tanaka Authorized Technical Assistance and original spare parts Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Brush Cutter CG24EKS.
In the following table, look for the model of Brush Cutter and the respective parts of the code.
| Brush Cutter CG24EKS | ||
| # | Part Num. | Description |
| 1 | 6684637 | TAPPING SCREW D4.5X12 |
| 4 | 6684587 | CYLINDER GASKET |
| 5 | 6684585 | CYLINDER SET |
| 6 | 6684638 | HEX. HOLE BOLT M6X55 |
| 7 | 6684639 | BOLT WASHER 6 |
| 8 | 6684640 | MUFFLER COMP. |
| 13 | 6684635 | MUFFLER PROTECTOR |
| 14 | 6684641 | HEAT SHIELD |
| 15 | 6684586 | HEX.HOLE BOLT M5X18/S |
| 17 | 6684597 | INSULATOR TUBE 50L |
| 19 | 6684602 | RUBBER CAP |
| 24 | 6684595 | HEX. SOCKET HD. BOLT (W/SP.WASHER) M4X12 |
| 26 | 6684593 | COVER PACKING |
| 27 | 6684588 | PISTON RING |
| 28 | 6684590 | CIR CLIP |
| 29 | 6684589 | PISTON SET |
| 30 | 6684591 | PISTON PIN |
| 31 | 6684592 | CRANK SHAFT COMP. |
| 32 | 6684586 | HEX.HOLE BOLT M5X18/S |
| 33 | 6684609 | CRANK CASE GASKET |
| 36 | 6684604 | GEAR SHAFT SHIM 0.20 |
| 51 | 6684668 | HEX.HOLE BOLT M5X20/S |
| 52 | 6684667 | HEX.HOLE BOLT M5X12/S |
| 53 | 6684666 | ANTI-VIBE RUBBER (A) |
| 54A | 6698643 | PIPE HOLDER (A) |
| 55A | 6698644 | PIPE HOLDER (B) |
| 56 | 6684665 | ANTI-VIBE RUBBER (B) |
| 58 | 6684636 | TAPPING SCREW D4.5X16 |
| 59 | 6684647 | HEX. HOLE BOLT M5X18/WS |
| 60 | 6684669 | FAN CASE COMP. (ORANGE) |
| 61A | 6698793 | CLUTCH DRUM |
| 62 | 6684646 | STEP BOLT |
| 63 | 6684648 | BENT WASHER 8 |
| 64 | 6684645 | CLUTCH PLATE A 0.5 |
| 65 | 6684644 | CLUTCH SPRING |
| 66 | 6684643 | CLUTCH SHOE COMP. |
| 67 | 6684642 | CLUTCH WASHER B |
| 69 | 6684611 | BOLT WASHER M8 |
| 71 | 6684664 | STOP RING C-12 OUTER |
| 81 | 6685101 | D4E RETAINING RING |
| 82 | 6684684 | STARTER PAWL SPRING |
| 83 | 6684685 | STARTER PAWL |
| 84 | 6684681 | STARTER PULLEY ASS'Y |
| 85 | 6684679 | SET SCREW |
| 86 | 6684678 | CAM PLATE |
| 87 | 6684677 | DAMPER SPRING |
| 89 | 6684675 | RECOIL SPRING |
| 91 | 6684673 | RECOIL STARTER BODY COMP. |
| 92 | 6684682 | HEX. HOLE BOLT 4X15/PS |
| 93 | 6684680 | STARTER HANDLE |
| 116 | 6684702 | DRIVE SHAFT PIPE COMP. 1500L |
| 120 | 6684709 | HEX. HOLE BOLT M5X25/S |
| 121 | 6684708 | HANDLE GRIP |
| 123 | 6684713 | HANDLE BRACKET C |
| 124 | 6684714 | HEX. HOLE BUTTON SCREW M6X25S |
| 129 | 6684709 | HEX. HOLE BOLT M5X25/S |
| 130 | 6684725 | SCREW M4X20 (BLACK) |
| 132 | 6684721 | TRIGGER LOCK OUT |
| 136 | 6684717 | PROTECTION TUBE 7X870L |
| 137 | 6684723 | THROTTLE LEVER |
| 139 | 6684722 | RETURN SPRING |
| 140 | 6684727 | CONTAL NUT 5 |
| 142 | 6684835 | HEX.NUT 6 |
| 146 | 6684838 | BOLT 6X43/P (BLACK) |
| 149 | 6684702 | DRIVE SHAFT PIPE COMP. 1500L |
| 152 | 6684709 | HEX. HOLE BOLT M5X25/S |
| 155 | 6684725 | SCREW M4X20 (BLACK) |
| 160 | 6684721 | TRIGGER LOCK OUT |
| 161 | 6684804 | THROTTLE LEVER |
| 163 | 6684722 | RETURN SPRING |
| 164 | 6684727 | CONTAL NUT 5 |
| 181 | 6684731 | GEAR CASE ASS'Y 24 |
| 186 | 6684741 | STOP RING C-28.INNER |
| 189 | 6684752 | GEAR PINION SET |
| 190 | 6684738 | BALL BEARING #608.22MM/OD |
| 192 | 6684973 | HEX.HOLE BOLT M5X30/WS |
| 193 | 6684667 | HEX.HOLE BOLT M5X12/S |
| 195 | 6684734 | BALL BEARING 609 |
| 196 | 6684735 | BALL BEARING 609Z ST |
| 198 | 6684732 | STOP RING C-24.INNER |
| 199 | 6684714 | HEX. HOLE BUTTON SCREW M6X25S |
| 201 | 6684747 | BLADE GUARD 24 CE |
| 202 | 6684748 | GUARD HOLDER |
| 203 | 6684754 | KNIFE |
| 204 | 6684753 | TAPPING SCREW 5X20 |
| 205 | 6684749 | COVER GUARD |
| 206 | 6684751 | TAPPING SCREW 4X14 |
| 207 | 6684750 | KNIFE |
| 208 | 6685064 | HEX. SOCKET HD. BOLT (W/BUTTON) M6X20 |
| 209 | 6684826 | S.WASHER 6 |
| 213 | 6685068 | MACHINE SCREW (W/SP. WASHER) M4X12 |
| 214 | 6685069 | NUT M4 |
| 215 | 6685070 | BOLT WASHER M4 |
| 221 | 6684613 | INSULATOR GASKET |
| 222 | 6684840 | INSULATOR SET |
| 223 | 6684616 | CARBURETOR PACKING |
| 225 | 6684615 | CARBURETOR GASKET |
| 229 | 6684697 | SWIVEL |
| 230 | 6684698 | THROTTLE SET SCREW |
| 231 | 6684696 | STOP RING |
| 232 | 6684695 | O-RING |
| 235 | 6684690 | METERING DIAPHRAGM |
| 236 | 6684689 | PRIMING BODY |
| 238 | 6684693 | PUMP DIAPHRAGM |
| 239 | 6684692 | PUMP GASKET |
| 240 | 6684700 | INLET SCREEN |
| 241 | 6684691 | DIAPHRAGM GASKET |
| 242 | 6684687 | PRIMING PUMP COMP. |
| 244 | 6684656 | CLEANER BODY COMP. |
| 246 | 6684658 | WAVE WASHER 8 |
| 247 | 6684659 | COLLAR 8 |
| 248 | 6684654 | AIR CLEANER ELEMENT |
| 249 | 6684653 | CLEANER COVER |
| 250 | 6684661 | WASHER 5 |
| 251 | 6684662 | S.WASHER 5 |
| 252 | 6684660 | SCREW M5X60 |
| 253 | 6684655 | COVER FIXING BOLT |
| 271 | 6684621 | TANK (WHITE) |
| 272 | 6684623 | COLLAR C |
| 273 | 6684618 | SHIELD TUBE 3X5X180 |
| 274 | 6684619 | CLIP.6.3 DIA. |
| 276 | 6684626 | FUEL PIPE 3X5X65 |
| 277A | 6697846 | RETURN GROMMET |
| 279A | 6698402 | FUEL TANK CAP ASS'Y |
| 285 | 6684634 | HEX.HOLE BOLT 5X20/PS |
| 287 | 6698931 | FUEL GROMMET |
| 302 | 6684760 | SPOOL |
| 303 | 6684762 | EYELET |
| 308 | 6684759 | REEL SPRING |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Hitachi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to hitachi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
