Hitachi Spare Parts for Brush Cutter CG31EBS
We are Hitachi-HIKOKI Tanaka authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair issues for Brush Cutter CG31EBS.
In the following table, look for the model of the Brush Cutters and ripettivo spare part.
| Hitachi HIKOKI Brush Cutter CG31EBS Pag.1 |
||
| ENGINE | ||
| # | Part Num. | Description |
| 1 | 791153 | BALL BEARING 6001CM |
| 2 | 791152 | OIL SEAL 6696302 |
| 3 | 791155 | OIL SEAL TB 12227 |
| 4 | 791150 | RING |
| 5 | 791166 | MOTOR HOUSING |
| 6 | 791151 | PLUG |
| 7 | 791167 | CASE GASKET |
| 8 | 791151 | PLUG |
| 9 | 791137 | SCREW |
| 10 | 791168 | PISTON |
| 11 | 791169 | PISTON RING |
| 12 | 791170 | PISTON PIN SUBSTITUITED BY 6686008 |
| 13 | 791171 | CIRCLIP |
| 14 | 791172 | CRANKSHAFT |
| 15 | 791154 | WOODRUF * 6686454 |
| 16 | 791173 | CYLINDER - DISCONTINUED |
| 17 | 791174 | CYLINDER GASKET |
| 18 | 791142 | SREW |
| 20 | 791175 | FLYWHEEL |
| 21 | 791217 | IGNITION COIL |
| 22 | 791146 | NUT |
| 23 | 791148 | WASHER |
| 24 | 791176 | SPACER |
| 25 | 791177 | SCREW |
| 26 | 791158 | CABLE |
| 27 | 791218 | CABLE |
| 28 | 791179 | TAB |
| 29 | 791180 | CLUTCH ASS'Y |
| 30 | 791181 | BOLT |
| 31 | 791147 | WASHER |
| 32 | 791149 | WASHER |
| 33 | 791213 | CLUTCH CARTER |
| 34 | 791140 | SCREW |
| 35 | 791215 | MUFFLER |
| 36 | 791182 | MUFFLER COVER |
| 37 | 791219 | MUFFLER GASKET |
| 38 | 791143 | SCREW |
| 39 | 791138 | SCREW |
| 40 | 791220 | MUFFLER COVER |
| 41 | 791183 | INSULATOR GASKET |
| 42 | 791184 | INSULATOR |
| 43 | 791144 | SCREW |
| 44 | 791185 | GASKET |
| 45 | 791186 | CARBURETOR WYC-14 |
| 46 | 791187 | GASKET |
| 47 | 791188 | AIR CLEANER BASE |
| 48 | 791159 | PRIMER |
| 49 | 791160 | TUBE |
| 50 | 791161 | CLIP |
| 51 | 791162 | CLIP |
| 52 | 791189 | TUBE |
| 53 | 791143 | SCREW |
| 54 | 791222 | SUPPORT |
| 55 | 791190 | AIR CLEANER |
| 56 | 791191 | AIR CLEANER COVER |
| 57 | 791192 | SCREW |
| 58 | 791221 | TOP COVER |
| 59 | 791193 | SPACER |
| 60 | 791139 | SCREW |
| 61 | 791194 | FUEL TANK |
| 62 | 791163 | FILTER |
| 63 | 791195 | PIPE, SUCTION |
| 64 | 791164 | CLIP |
| 66 | 791165 | VALVE |
| 67 | 791196 | PLUG |
| 68 | 791197 | VALVE BODY |
| 69 | 791198 | ELEMENT |
| 70 | 791199 | TUBE |
| 72 | 6698402 | TANK CAP EX 791200 |
| 73 | 6698402 | GASKET EX 791201 |
| 74 | 6698402 | GASKET SUPPORT EX 791202 |
| 75 | 6698402 | STRAP FUEL CAP EX 791203 |
| 76 | 791204 | SUPPORT |
| 77 | 791145 | TORX SOCKET FLANGE |
| 78 | 791139 | SCREW |
| 79 | 791205 | STARTER ASS'Y |
| 80 | 791211 | PULLEY ASSY |
| 81 | 791140 | SCREW |
| 82 | 791212 | SUPPORT |
| 83 | 791141 | SCREW |
| TRASMISSION Pag.2 |
||
| 101 | 791075 | COMPLETE GEAR BOX |
| 102 | 791057 | RING |
| 103 | 791055 | RING |
| 104 | 791014 | BEARING |
| 105 | 791041 | PINION |
| 106 | 791038 | SCREW |
| 107 | 791022 | WASHER |
| 108 | 791051 | BOLT |
| 109 | 791063 | GEAR CASE |
| 110 | 791037 | COVER |
| 111 | 791039 | SCREW |
| 112 | 791012 | BEARING |
| 113 | 791069 | RING |
| 114 | 791068 | SHAFT |
| 115 | 791013 | BEARING |
| 116 | 791058 | RING |
| 117 | 791062 | FLANGE |
| 118 | 791326 | FLANGE SUBSTITUITED BY 791231 |
| 119 | 791060 | WASHER M10 |
| 120 | 791052 | DADO SX |
| 121 | 791061 | PLUG |
| 123 | 791053 | WASHER |
| 125 | 791059 | RING |
| 126 | 791011 | BEARING |
| 127 | 791056 | RING |
| 128 | 791047 | CLUTCH CARTER |
| 128A | 791240 | CLUTCH CASE |
| 129 | 791028 | RUBBER COVER |
| 130 | 791023 | SCREW |
| 131 | 791073 | WASHER |
| 132 | 791070 | WASHER |
| 133 | 791030 | CLAMP B |
| 134 | 791029 | CLAMP A |
| 135 | 791024 | SCREW |
| 136 | 791065 | WASHER |
| 137 | 791046 | WASHER |
| 139 | 791031 | SUPPORT |
| 140 | 791032 | SUPPORT |
| 141 | 791048 | SCREW |
| 142 | 791050 | NUT |
| 144 | 791010 | BUSH |
| 145 | 791015 | BEARING |
| 147A | 791239 | PIPE ASS'Y (26MM) |
| 149 | 791252 | COMPLETE HANDLE |
| 153 | 791080 | SCREW M5 |
| 154 | 791081 | STILL |
| 155 | 791082 | HANDLE CARTER |
| 155A | 791241 | COMPLETE HANDLE - DISCONTINUED |
| 156 | 791083 | HANDLE |
| 157 | 791084 | SUPPORT |
| 158 | 791085 | SWITCH |
| 159 | 791086 | TINE |
| 160 | 791087 | SPRING - DISCONTINUED |
| 161 | 791088 | SPRING |
| 162 | 791089 | SAFETY LEVER |
| 163 | 791090 | SPRING |
| 164 | 791091 | THROTTLE LEVER |
| 165 | 791092 | CONTROL CABLE |
| 166 | 791001 | TUBE |
| 167 | 791093 | SCREW |
| 168 | 791094 | SCREW |
| 169 | 791095 | HANDLE CAERTER |
| 170 | 791040 | SEAL OIL |
| 171 | 791054 | BUSHING |
| 173 | 791097 | SUPPORT |
| 175 | 791099 | SAFETY GUARG |
| 176 | 791100 | SPACER |
| 177 | 791045 | SCREW |
| 179 | 790329 | GUARD |
| HEAD Pag.3 |
||
| 0 | 781303 | UNIVERSAL HEAD |
| 1 | 27354 | TOP COVER |
| 2 | 18308 | PASSPORT THROTTLE |
| 3 | 18307 | SPRING |
| 4 | 18309 | REEL |
| 5 | 27356 | LOWER COVER |
| 6 | 03909 | ADAPTER M8X1.25 X M8X1.25 SX |
| 7 | 03006 | ADAPTER M10X1.25 X M10X1.25 SX |
| 8 | 18846 | CHARGING HANDLE |
| 9 | 612564 | INSERT M10 X 1 SX FEMALE |
| 9 | 612561 | INSERT M8 X 1.25 SX FEMALE |
| 9 | 612565 | INSERT M10X 1.25 SX FEMALE |
| 9 | 618193 | INSERT M12X 1.25 SX FEMALE |
