Hitachi Spare Parts for Engine Brush Cutter CG33EJ-SL
€2.65
Tax included
Hitachi Spare Parts for Engine Brush Cutter CG33EJ-SL
Hitachi-HIKOKI Tanaka authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair issues for Engine Bush Cutter CG33EJ-SL.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Hitachi Spare Parts for Engine Brush Cutter CG33EJ-SL
Hitachi-HIKOKI Tanaka authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair issues for Engine Bush Cutter CG33EJ-SL.In the following table, look for the model of the chainsaw and ripettivo spare part.
| ENGINE BRUSH CUTTER CG33EJ-SL | ||
| B37-01 CYLINDER/PISTON/CRANK SHAFT Pag.1 | ||
| # | Part Num. | Description |
| 1 | 6699326 | SPARK PLUG ASS'Y RCJ6Y |
| 2 | 6685487 | CYLINDER SET |
| 3 | 6684903 | HEX.HOLE BOLT M5X16/S |
| 4 | 6685746 | CYLINDER GASKET |
| 5 | 6685331 | PISTON RING (XR1-1856) |
| 6 | 6685898 | PISTON SET |
| 7 | 6686008 | PISTON PIN |
| 8 | 6685078 | CIRCLIP |
| 11 | 6696499 | CRANK SHAFT COMP |
| 13 | 6684899 | WOODRUFF KEY 3X13X4.5 |
| 30 | 6695407 | HIGH TENSION SCREW 4X18WS |
| 33 | 6688319 | INSULATOR TUBE, 110L |
| 050A | 6699772 | IGNITION COIL ASS'Y - DISCONTINUED |
| 55 | 6687888 | HIGH TENSION CORD 140L |
| 56 | 6684602 | RUBBER CAP |
| 57 | 6687979 | LEAD WIRE ASS'Y |
| 60 | 6684600 | WASHER T1.6 |
| B37-02 CRANK CASE Pag.2 | ||
| 14 | 6686581 | CRANK CASE ASS'Y |
| 15 | 6684607 | OIL SEAL TB 12227 |
| 16 | 6684608 | BALL BEARING 6001 C3 |
| 17 | 6686721 | CRANK CASE GASKET |
| 18 | 6684604 | GEAR SHAFT SHIM 0.20 |
| 18 | 6684605 | GEAR SHAFT SHIM 0.30 |
| 24 | 6687375 | MAGNETO ROTOR COMP. |
| 25 | 6684612 | HEX.NUT M8 |
| 27 | 6695184 | SMALL WASHER 8 |
| 32 | 6684903 | HEX.HOLE BOLT M5X16/S |
| B37-03 ENGINE-1 Pag.3 | ||
| 80 | 6689864 | INLET MANIFOLD GASKET |
| 81 | 6697943 | CARBURETOR INSULATOR SET |
| 82 | 6695514 | HEX.HOLE BOLT 5X22/WS |
| 85 | 6689824 | CARBURETOR GASKET |
| 86 | 6691279 | CHOKE PLATE 3.0 |
| 87 | 6686747 | COLLAR 11.8 |
| 88 | 6690124 | CLEANER BODY COMP. |
| 89 | 6690365 | CLEANER SPONGE |
| 90 | 6690421 | CLEANER COVER ASS'Y |
| 91 | 6698730 | COVER FIXING BOLT COMP. |
| 92 | 6688310 | SPACER |
| 94 | 6695354 | SCREW C-HEAD 5X60/S |
| 96 | 6684864 | SMALL WASHER 5X10 |
| 98 | 6690514 | CARBURETOR SET WT773 |
| 99 | 6691239 | CHOKE CONTROL LEVER |
| 100 | 6691588 | TANK COMP. WHT |
| 101 | 6691337 | SWIVEL CAP |
| 109 | 6684623 | COLLAR C |
| 110 | 6688156 | FUEL PIPE GROMMET |
| 111 | 6684880 | FUEL PIPE 3X5X85 |
| 112 | 6684620 | PUMP FILTER BODY COMP. |
| 113 | 6685198 | CLIP D6 |
| 114 | 6688173 | FUEL PIPE ASS'Y L=195 |
| 116 | 6695506 | HEX HOLE BOLT 5X20PS |
| 117 | 6685049 | TANK CAP ASS'Y |
| 118 | 6695280 | TAP SCREW 4X14 P |
| 119 | 6685070 | BOLT WASHER M4 |
| 120 | 6694793 | STAND |
| 200 | 6684625 | TANK CAP CHAIN |
| B37-04 ENGINE-2 Pag.4 | ||
| 35 | 6688610 | CLUTCH ARM COMP. |
| 36 | 6689420 | CLUTCH SPRING |
| 37 | 6689645 | CLUTCH WASHER B |
| 39 | 6695203 | WAVE WASHER 10 |
| 40 | 6689628 | CLUTCH STEP BOLT |
| 43 | 6687022 | FAN CASE (VERMILION) |
| 45 | 6684682 | HEX.HOLE BOLT 4X15/PS |
| 46 | 6684647 | HEX.HOLE BOLT M5X18/WS |
| 65 | 6692803 | MUFFLER PROTECTOR |
| 66 | 6687468 | SPARK PLUG CAP ASS'Y |
| 71 | 6688057 | PRIMARY CORD GROMMET |
| 72 | 6692732 | MUFFLER GASKET |
| 73 | 6687260 | HEAT SHIELD |
| 74 | 6692493 | MUFFLER SET |
| 75 | 6684638 | HEX. HOLE BOLT M6X55 |
| 76 | 6684639 | BOLT WASHER 6 |
| B37-05 RECOIL STARTER Pag.5 | ||
| 0 | 6692991 | RECOIL STARTER BODY ASS'Y |
| 1 | 6693040 | RECOIL STARTER BODY COMP. |
| 2 | 6684674 | STARTER ROPE 3.5X860 |
| 3 | 6684675 | RECOIL SPRING |
| 4 | 6693081 | STARTER PULLEY |
| 5 | 6684677 | DAMPER SPRING |
| 6 | 6692938 | CAM PLATE new code 6692991 |
| 7 | 6684679 | SET SCREW |
| 8 | 6684680 | STARTER HANDLE |
| 10 | 6695503 | HEX. HOLE BOLT 4X20 PS |
| 15 | 6689645 | CLUTCH WASHER B |
| 16 | 6684681 | STARTER PULLEY ASS'Y |
| 17 | 6684685 | STARTER PAWL |
| 18 | 6684684 | STARTER PAWL SPRING |
| 19 | 6684683 | STOP RING E-5 |
| B37-06 CARBURETOR Pag.6 | ||
| 2 | 6684700 | INLET SCREEN |
| 3 | 6685211 | PUMP BODY |
| 4 | 6685210 | SCREW |
| 5 | 6691454 | PUMP GASKET |
| 6 | 6685213 | PUMP DIAPHRAGM |
| 7 | 6690839 | DIAPHRAGM GASKET |
| 8 | 6690827 | METERING DIAPHRAGM COMP. |
| 9 | 6690436 | AIR PURGE COMP. |
| 10 | 6690859 | DIAPHRAGM COVER |
| 11 | 6684689 | PRIMING BODY |
| 12 | 6690873 | VALVE SPRING |
| 13 | 6685215 | NEEDLE VALVE |
| 15 | 6685217 | CONTROL LEVER |
| 16 | 6685218 | HINGE PIN SET SCREW |
| 17 | 6685219 | HINGE PIN |
| 18 | 6690736 | IDLE ADJUST SCREW |
| 19 | 6690766 | IDLE ADJUST SPRING |
| 27 | 6691310 | SET SCREW |
| B37-07 CLUTCH CASE Pag.7 | ||
| 1 | 6688586 | CLUTCH SHAFT COMP. |
| 2 | 6695559 | BALL BEARING #6202Z, 35MM/OD |
| 3 | 6695285 | STOP RING C-15, OUTER |
| 4 | 6689194 | CLUTCH CASE |
| 6 | 6691829 | CUSHION RUBBER |
| 9 | 6695046 | HEX. HOLE BOLT 5X16 |
| 11 | 6685064 | HEX. SOCKET HD. BOLT (W/BUTTON) M6X20 |
| 12 | 6695091 | HEX HOLE BOLT 5X25 |
| 15 | 6689655 | PIPE HOLDER |
| 26 | 6684918 | WASHER M5 (BLACK) |
| 28 | 6689664 | METAL FITTING |
| B37-08 OPERATION PIPE Pag.8 | ||
| 1 | 6689475 | DRIVE SHAFT |
| 2 | 6699277 | MAIN PIPE COMP |
| 3 | 6699278 | BUSHING ASS'Y |
| 10 | 6695255 | TAPPING SCREW 5X20 |
| 11 | 6689681 | BRAKE SHAFT WASHER |
| 16 | 6691098 | HANDLE GRIP |
| 17 | 6684838 | BOLT 6X43/P (BLACK) |
| 18 | 6691049 | LOOP HANDLE, 26DIA., BLACK |
| 19 | 6691231 | BARRIER, 26 DIA, BLACK |
| 22 | 6684835 | HEX.NUT 6 |
| 25 | 6693731 | THROTTLE LEVER ASS'Y |
| 38 | 6694029 | CONNECTOR CASE |
| 39 | 6693986 | THROTTLE WIRE 125+63 |
| 40 | 6687518 | PRTECTION TUBE 7X50L |
| 51 | 6684965 | NUT M5 |
| 53 | 6689264 | LIFTING METAL |
| 54 | 6684903 | HEX.HOLE BOLT M5X16/S |
| 56 | 6692874 | SHOULDER BELT ASS'Y |
| 83 | 6693957 | THROTTLE WIRE COMP. |
| 84 | 6694010 | THROTTLE WIRE |
| 85 | 6687442 | STOP SWITCH COMP. |
| 86 | 6687519 | SPLIT PROTECTION TUBE,7X70L |
| 98 | 6684721 | TRIGGER LOCK OUT |
| 100 | 6684722 | RETURN SPRING |
| 110 | 6684803 | SCREW M5X20 |
| 111 | 6684727 | CONTAL NUT 5 |
| 112 | 6684725 | SCREW M4X20 (BLACK) |
| 125 | 6684804 | THROTTLE LEVER |
| B37-09 GEAR CASE Pag.9 | ||
| 1 | 6696497 | GEAR CASE SET PN |
| 001A | 6697660 | GEAR CASE ASS'Y |
| 001B | 6696497 | GEAR CASE SET PN |
| 2 | 6684709 | HEX. HOLE BOLT M5X25/S |
| 002A | 6684829 | HEX. SOCKET HD. BOLT M5X12 |
| 002B | 6684709 | HEX. HOLE BOLT M5X25/S |
| 3 | 6684834 | SPRING WASHER 5 |
| 3 | 6684834 | SPRING WASHER 5 |
| 4 | 6695294 | RETAINING RING C-TYPE D26 |
| 5 | 6695315 | STOP RING OUTER 10 |
| 005A | 6684821 | STOP RING C-10,OUTER |
| 005B | 6695315 | STOP RING OUTER 10 |
| 6 | 6695526 | BALL BEARING #6000Z, 26MM/OD |
| 7 | 6695524 | BALL BEARING #6000, 26MM/OD |
| 007A | 6695524 | BALL BEARING #6000, 26MM/OD |
| 007B | 6695524 | BALL BEARING #6000, 26MM/OD |
| 9 | 6688770 | GEAR CASE 26 DIAM. FOR MACHINES FROM SERIAL E6300001 FOR MODEL CG33EJ (SL) |
| 009A | 6697738 | GEAR CASE FOR MACHINES TO SERIAL E539999 FOR MODEL CG33EJ (SL) |
| 009B | 6688770 | GEAR CASE 26 DIAM. FOR MACHINES FROM SERIAL E6300001 FOR MODEL CG33EJ (SL) |
| 11 | 6684667 | HEX.HOLE BOLT M5X12/S |
| 011A | 6695499 | HEX.HOLE BOLT 6X30/S |
| 011B | 6684667 | HEX.HOLE BOLT M5X12/S |
| 12 | 6689109 | OILING BOLT |
| 012A | 6684737 | BOLT (W/PLUS) M6X8 |
| 012B | 6689109 | OILING BOLT |
| 13 | 6684734 | BALL BEARING 609 |
| 13 | 6684734 | BALL BEARING 609 |
| 15 | 6688924 | GEAR SHAFT |
| 015A | 6697739 | GEAR SHAFT |
| 015B | 6688924 | GEAR SHAFT |
| 16 | 6695554 | BALL BEARING 6201D, 32MM/OD |
| 016A | 6695555 | BALL BEARING #6201DD, 32MM/OD |
| 016B | 6695554 | BALL BEARING 6201D, 32MM/OD |
| 17 | 6695295 | STOP RING C-32, INNER |
| 18 | 6689032 | CUTTER HOLDER FINO A MATRICOLA E429999 PER MODELLO CG33EJ (SL) |
| 018A | 6699008 | CUTTER HOLDER |
| 018B | 6689032 | CUTTER HOLDER FINO A MATRICOLA E429999 PER MODELLO CG33EJ (SL) |
| 19 | 6689055 | CUTTER HOLDER CAP |
| 019A | 6699009 | CUTTER HOLDER CAP |
| 019B | 6689055 | CUTTER HOLDER CAP |
| 20 | 6697792 | NUT COVER |
| 20 | 6697792 | NUT COVER |
| 22 | 6689073 | FIXING NUT M10X1.25 |
| 022A | 335759 | U-NUT (LEFT HAND) M10 |
| 022B | 6689073 | FIXING NUT M10X1.25 |
| 23 | 6689159 | GEAR CASE WASHER |
| 23 | 6689159 | GEAR CASE WASHER |
| 26 | 6684714 | HEX. HOLE BUTTON SCREW 6X25S |
| 28 | 6690315 | COVER BRACKET 26 |
| 028A | 6697867 | COVER BRACKET D26 |
| 028B | 6690315 | COVER BRACKET 26 |
| 29 | 6690276 | BLADE GUARD 26CE |
| 30 | 6684748 | GUARD HOLDER |
| B37-09 GEAR CASE Pag.10 | ||
| 32 | 6684750 | KNIFE |
| 34 | 6684751 | TAPPING SCREW 4X14 |
| 35 | 6688875 | GEAR/PINION SET, SPARE |
| 035A | 6697741 | GEAR PINION SET,SPARE |
| 035B | 6688875 | GEAR/PINION SET, SPARE |
| 38 | 6684753 | TAPPING SCREW 5X20 |
| 39 | 6684754 | KNIFE |
| B37-10 TOOLS Pag.11 | ||
| 0 | 6695777 | NYLON HEAD TH-97M |
| 1 | 6693269 | CUTTING BODY ASS'Y |
| 2 | 6693327 | CORD GUIDE |
| 4 | 6693246 | ADJUSTMENT BASE |
| 5 | 6693373 | SPRING (YELLOW/BLACK) |
| 6 | 6693363 | ADJUSTMENT WASHER |
| 7 | 6693290 | SPOOL (BLACK) |
| 8 | 6692271 | STEEL BALL |
| 9 | 6693358 | REEL SLIDER |
| 10 | 6693337 | CUTTING BODY CAP |
| 12 | 6689095 | MOUNTING NUT L-M10X1.25 |
| 15 | 6695784 | NYLON HEAD BF-5 |
| 21 | 6689624 | MOUNTING NUT L-M8X1.25 |
| 22 | 6684756 | MOUNTING NUT L-M10X1.25 |
| 23 | 6684757 | CUTTING BODY |
| 24 | 6684758 | SPECIAL NUT |
| 25 | 6684759 | REEL SPRING |
| 26 | 6684760 | SPOOL |
| 27 | 6684761 | CUTTING BODY CAP |
| 28 | 6684762 | EYELET |
| 29 | 6697805 | SURE TAP MANUAL P/L 9 |
| 30 | 6684813 | HEX. BAR WRENCH 4MM |
| 31 | 6684764 | BOX WRENCH (HEX. SOCKET 17/19) |
| 32 | 6684765 | SAFETY GLASSES |
| 35 | 6684763 | WINDING PROTECTOR |
| 35 | 6684763 | WINDING PROTECTOR |
| 521 | 6601148 | NYLON CORD CUTTER |
| 522 | 6601149 | CASE |
| 523 | 6601150 | NUT |
| 524 | 6693380 | REEL SPRING |
| 525 | 6601151 | LINE HOLDER |
| 526 | 6601152 | COVER |
| 527 | 6684810 | EYELET |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Hitachi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to hitachi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
