Hitachi Spare Parts for Engine Hedge Trimmer CH78EC3
€1.04
Tax included
Hitachi Spare Parts for Engine Hedge Trimmer CH78EC3
Original spare parts Hitachi-HIKOKI recommended for you, at the best prices, fast delivery and lowest prices, for to make maintenance for Engine Hedge Trimmer CH78EC3.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Hitachi Spare Parts for Engine Hedge Trimmer CH78EC3
Original spare parts Hitachi-HIKOKI recommended for you, at the best prices, fast delivery and lowest prices, for to make maintenance for Engine Hedge Trimmer CH78EC3.
In the following table, look for the model of Hedge Trimmer and the respective parts of the code.
| Hedge Trimmer CH78EC3 | ||
| # | Part Num. | Description |
| 1 | 6684597 | INSULATOR TUBE 50L |
| 2 | 6688050 | GROMMET |
| 8 | 6684604 | GEAR SHAFT SHIM 0.20 |
| 8 | 6684605 | GEAR SHAFT SHIM 0.30 |
| 9 | 6686205 | CRANK SHAFT COMP. |
| 10 | 6684591 | PISTON PIN |
| 11 | 6684586 | HEX.HOLE BOLT M5X18/S |
| 12A | 6699319 | SPARK PLUG ASS'Y BPMR6A |
| 13 | 6687476 | SPARK PLUG CAP |
| 14 | 6685481 | CYLINDER ASS'Y |
| 15 | 6685744 | CYLINDER GASKET |
| 16 | 6684588 | PISTON RING |
| 17 | 6686028 | PISTON PIN CIRCLIP |
| 18 | 6685893 | PISTON ASS'Y |
| 19B | 6699079 | FRONT HANDLE |
| 20 | 6695054 | HEX. HOLE BOLT 5X40 |
| 21 | 6684834 | SPRING WASHER 5 |
| 22 | 6684918 | WASHER M5 (BLACK) |
| 23 | 6695441 | BOLT 4X12PS |
| 24 | 6688494 | CLUTCH |
| 25 | 6688570 | CLUTCH DRUM COMP. |
| 26 | 6695538 | BALL BEARING #6002Z, 32MM/OD |
| 27 | 6695285 | STOP RING C-15, OUTER |
| 28 | 6684786 | HEX. SOCKET HD. BOLT M5X30 S |
| 30 | 6684607 | OIL SEAL TB 12227 |
| 31 | 6684608 | BALL BEARING 6001 C3 |
| 32 | 6686720 | CRANK CASE GASKET |
| 34 | 6686771 | STUD BOLT 6X22 |
| 35 | 6686574 | CRANK CASE ASS'Y |
| 36 | 6693237 | STARTER HANDLE |
| 37 | 6693172 | ROPE 3X890 |
| 40 | 6695502 | HEX.HOLE BOLT 4X18PS |
| 41 | 6687014 | FAN CASE COMP. - DISCONTINUED |
| 43 | 6684675 | RECOIL SPRING |
| 44 | 6693072 | STARTER ROPE REEL |
| 45 | 6684677 | DAMPER SPRING |
| 46 | 6684678 | CAM PLATE |
| 47 | 6684679 | SET SCREW |
| 48 | 6684685 | STARTER PAWL |
| 49 | 6684684 | STARTER PAWL SPRING |
| 50 | 6685101 | D4E RETAINING RING |
| 51 | 6684681 | STARTER PULLEY ASS'Y |
| 52 | 6687209 | DEFLECTOR |
| 54 | 6684971 | S.WASHER 8 |
| 55 | 6684611 | BOLT WASHER M8 |
| 56 | 6687389 | MAGNETO ROTOR COMP. |
| 57A | 6698868 | HANDLE A |
| 58 | 6696350 | EARTH TERMINAL |
| 59 | 696352 | TAPPING SCREW D3X6 |
| 60 | 6696344 | TRIGGER LOCKOUT |
| 61 | 6696345 | THROTTLE LEVER SPRING |
| 62 | 6696355 | TAB TERMINAL |
| 63 | 6684913 | SCREW 3X10 |
| 64 | 6688366 | BUTTON STOP |
| 65 | 6694588 | STOP BUTTON MARK |
| 66 | 6696348 | SPRING (A) |
| 67 | 6696346 | LOCK LEVER |
| 68 | 6696349 | SPRING (B) |
| 69 | 6696343 | THROTTLE LEVER |
| 70A | 6698784 | CLICK SPRING |
| 71 | 6696347 | RELEASE LEVER |
| 72A | 6698828 | THROTTLE WIRE |
| 73 | 6687524 | PROTECTION TUBE 150L |
| 74 | 6696354 | STOP SWITCH ASS'Y (A) |
| 75A | 6698869 | HANDLE B |
| 76 | 305812 | TAPPING SCREW (W/FLANGE) D4X16 (BLACK) |
| 77 | 6696363 | FRAME |
| 78 | 6688412 | DAMPER B |
| 79 | 6689680 | BRAKE SHAFT WASHER |
| 80 | 6684786 | HEX. SOCKET HD. BOLT M5X30 S |
| 81 | 6688485 | DAMPER COLLAR B |
| 82 | 6686111 | HANDLE SUPPORT COMP. |
| 83 | 6696359 | CLIP |
| 84 | 6698870 | HANDLE A/B SET |
| 91 | 6684636 | TAPPING SCREW D4.5X16 |
| 92 | 6692799 | MUFFLER PROTECTOR |
| 93 | 6685114 | HEX. SOCKET HD. BOLT M5X50 |
| 94 | 6684661 | WASHER 5 |
| 95 | 6692477 | MUFFLER ASS'Y |
| 96 | 6687252 | HEAT SHIELD |
| 97 | 6692744 | MUFFLER GASKET |
| 98 | 6689891 | INTAKE PIPE GASKET |
| 99 | 6689966 | CARB. INSULATOR SET,SPARE |
| 100 | 6695515 | HEX. HOLE BOLT M5X25WS |
| 101 | 6689839 | CARBURETOR GASKET |
| 102 | 6690487 | CARBURETOR SET, WYL120 |
| 103 | 6684628 | SWIVEL CAP |
| 105 | 6690119 | CLEANER BODY COMP. |
| 106 | 6690804 | COLLAR 7.5 |
| 107 | 6691274 | CHOKE VALVE |
| 108 | 6684658 | WAVE WASHER 8 |
| 109 | 6690843 | BLOW OVER CHECK BOARD |
| 110 | 6684662 | S.WASHER 5 |
| 111 | 6684660 | SCREW M5X60 |
| 112 | 6690364 | CLEANER SPONGE |
| 113 | 6690417 | CLEANER COVER ASS'Y |
| 114 | 6689737 | SPECIAL SCREW |
| 115 | 6684697 | SWIVEL |
| 116 | 6684696 | STOP RING |
| 117 | 6684695 | O-RING |
| 119 | 6684700 | INLET SCREEN |
| 121 | 6685222 | DIAPHRAGM COVER-METERING |
| 122 | 6691312 | SET SCREW |
| 123 | 6684698 | THROTTLE SET SCREW |
| 124 | 6684883 | THROTTLE VALVE |
| 125 | 6691457 | PUMP GASKET |
| 126 | 6684693 | PUMP DIAPHRAGM |
| 127 | 6685220 | DIAPHRAGM PACKING-METERING |
| 128 | 6690827 | METERING DIAPHRAGM COMP. |
| 129 | 6685139 | PRIMING PUMP COMP. |
| 130 | 6692347 | FUEL PIPE 2.5X4X80 |
| 131 | 6692244 | COLLAR 5.8 |
| 132 | 6695505 | HEX. HOLE BOLT 5X18PS |
| 133 | 6696360 | TANK |
| 133 | 6696361 | TANK - DISCONTINUED |
| 134 | 6691389 | AIR VENT ASS'Y |
| 136 | 6692171 | AIR VENT VALVE ASS'Y |
| 137 | 6692346 | FUEL PIPE 2.5X4X70 |
| 138A | 6697846 | RETURN GROMMET |
| 139 | 6684619 | CLIP,6.3 DIA. |
| 140A | 6698874 | PUMP FILTER |
| 141A | 6698715 | FUEL PIPE |
| 142 | 6684625 | TANK CAP CHAIN |
| 143 | 6691763 | TANK CAP D ASS'Y, BLACK |
| 143 | 6691714 | TANK CAP ASS'Y |
| 144A | 6698894 | GUARD PLATE |
| 148 | 6690762 | SUPPORT PLATE |
| 149 | 6695175 | LOCK NUT 6 UPS-P |
| 150 | 6684639 | BOLT WASHER 6 |
| 151 | 6688684 | GEAR CASE COMP. |
| 152 | 6688643 | GREASE NIPPLE COMP. |
| 153 | 6695475 | SPRING NUT 6 |
| 154 | 6695495 | HEX. HOLE BOLT 6X18/S |
| 155 | 6687144 | CUTTER GUIDE 845L M6 |
| 156 | 6686612 | GUIDE PLATE |
| 157 | 6686811 | CAM ROD |
| 159A | 6698773 | GEAR 2 COMP. |
| 160 | 6688909 | GEAR CASE GASKET |
| 161 | 6692101 | GEAR CASE COVER |
| 162 | 6695547 | BALL BEARING 608 ZZ C3 |
| 163 | 6688846 | GEAR CASE B |
| 164 | 6684595 | HEX. SOCKET HD. BOLT (W/SP.WASHER) M4X12 |
| 166 | 6686654 | GREASE SEAL A |
| 169 | 6695484 | HEX. HOLE BOLT 4X10S |
| 170 | 6698931 | FUEL GROMMET |
| 171 | 6698774 | BLADE ASS'Y |
| 601 | 6687275 | GUARD PLATE |
| 602 | 6695170 | FLANGE NUT 6 |
| 603 | 6687289 | PROTECTION PLATE |
| 604 | 6687092 | CUTTER A (812L) |
| 605 | 6695075 | HEX. HOLE FLUSH BOLT 6X25 |
| 606 | 6687187 | WASHER 7 BLACK |
| 607 | 6687158 | FIXING BOLT A M6 |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Hitachi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to hitachi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
