Hitachi Spare Parts for Engine Brush Cutter CG22EAB
€1.04
Tax included
Hitachi Spare Parts for Engine Brush Cutter CG22EAB
Hitachi-HIKOKI Original spare parts sourced from the manufacturer, at the lowest price on the web, with after-sales service, for to make maintenance or repair deteriorated parts for Engine Brush Cutter CG22EAB.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Hitachi Spare Parts for Engine Brush Cutter CG22EAB
Hitachi-HIKOKI Original spare parts sourced from the manufacturer, at the lowest price on the web, with after-sales service, for to make maintenance or repair deteriorated parts for Engine Brush Cutter CG22EAB.
In the following table, look for the model of the Brush Cutter and ripettivo spare part.
| Brush Cutter CG22EAB | ||
| # | Part Num. | Description |
| 2A | 6600337 | MUFFLER PROTECTOR |
| 3 | 6684638 | HEX. HOLE BOLT M6X55 |
| 5 | 6696554 | MUFFLER |
| 6A | 6600320 | HEAT PROTECTION PANEL |
| 7 | 6684586 | HEX.HOLE BOLT M5X18/S |
| 10 | 6684595 | HEX. SOCKET HD. BOLT (W/SP.WASHER) M4X12 |
| 11 | 6696536 | INTAKE COVER (B) |
| 12 | 6696534 | COVER PACKING |
| 13 | 6696527 | CYLINDER |
| 14B | 6600424 | CYLINDER COVER |
| 18 | 6696535 | INTAKE COVER (A) |
| 19 | 6696548 | INTAKE PACKING |
| 20A | 6698387 | CARBURETOR INSULATOR |
| 21A | 6698844 | SEAL LOCK HEX. SOCKET BOLT (W/WASHERS)M5 |
| 22 | 6684616 | CARBURETOR PACKING |
| 24 | 6696550 | CARBURETOR ASS'Y WYC-22 |
| 24A | 6698474 | CARBURETOR ASS'Y WYC-28 |
| 27 | 6684696 | STOP RING |
| 28 | 6684692 | PUMP GASKET |
| 29 | 6684693 | PUMP DIAPHRAGM |
| 30 | 6691242 | PUMP PLATE |
| 32 | 6691312 | SET SCREW |
| 34 | 6684695 | O-RING |
| 36 | 6691234 | CIRCUIT PLATE |
| 38 | 6685220 | DIAPHRAGM PACKING-METERING |
| 39 | 6684690 | METERING DIAPHRAGM |
| 41A | 6698720 | FUEL PIPE |
| 42 | 6696832 | AIR CLEANER HOUSING |
| 43 | 6685139 | PRIMING PUMP COMP. |
| 44A | 6600704 | CLEANER SPONGE |
| 45 | 6696831 | AIR CLEANER COVER |
| 46 | 6696549 | AIR CLEANER ASS'Y |
| 48 | 6696530 | CYLINDER PACKING |
| 49 | 6696532 | PISTON RING |
| 50 | 6696531 | PISTON |
| 51 | 6684590 | CIR CLIP |
| 52 | 6696944 | PISTON PIN |
| 53 | 6696538 | CRANK CASE (B) COMP |
| 54 | 6696539 | CRANK CASE PACKING |
| 59 | 6696533 | CRANK SHAFT COMP. |
| 66 | 6684681 | STARTER PULLEY ASS'Y |
| 66A | 6696471 | STARTER PULLEY ASS'Y |
| 67A | 6699995 | RECOIL STARTER BODY ASS'Y |
| 68 | 6684679 | SET SCREW |
| 69A | 6699996 | CAM PLATE |
| 70 | 6684677 | DAMPER SPRING |
| 71A | 6699997 | STARTER ROPE REEL |
| 72 | 6684675 | RECOIL SPRING |
| 73 | 6684673 | RECOIL STARTER BODY COMP. |
| 75 | 6684680 | STARTER HANDLE |
| 78 | 6696572 | RECOIL STARTER BODY ASS'Y |
| 79 | 6693633 | SET SCREW |
| 81 | 6684675 | RECOIL SPRING |
| 83 | 6693168 | ROPE |
| 84 | 6693227 | STARTER HANDLE |
| 85 | 6684650 | MUFFLER SPECIAL GASKET |
| 86 | 6684652 | SPARK ARRESTOR |
| 88 | 6685068 | MACHINE SCREW (W/SP. WASHER) M4X12 |
| 89 | 6600339 | MUFFLER REAR COVER |
| 98 | 6696560 | THROTTLE WIRE COMP. |
| 101 | 6696963 | ANTI VIBE RUBBER (A) |
| 102 | 6696542 | PIPE HOLDER (A) |
| 104 | 6696543 | PIPE HOLDER (B) |
| 105 | 6696964 | ANTI VIBE RUBBER (B) |
| 106 | 6684667 | HEX.HOLE BOLT M5X12/S |
| 108B | 6699159 | FAN CASE (VERMILION) |
| 109A | 6698790 | CLUTCH SHAFT |
| 110 | 6696469 | STEP BOLT |
| 111 | 6684648 | BENT WASHER 8 |
| 112 | 6696546 | CLUTCH PLATE (A) |
| 113 | 6696948 | CLUTCH |
| 114 | 6696547 | CLUTCH WASHER (B) |
| 115 | 6685337 | FLYWHEEL NUT |
| 117B | 6699464 | IGNITION COIL ASS'Y |
| 121 | 6696544 | CORD |
| 123 | 6696545 | EARTH CORD |
| 124A | 6699289 | MAGNETO ROTOR |
| 125 | 6684636 | TAPPING SCREW D4.5X16 |
| 126 | 305812 | TAPPING SCREW (W/FLANGE) D4X16 (BLACK) |
| 127 | 6696487 | HANDLE (B) |
| 127 | 6696942 | HANDLE (B) |
| 128 | 6696490 | LOCK LEVER |
| 129 | 6696488 | LEVER |
| 130 | 6696489 | SPRING (A) |
| 131A | 6601275 | STOP SWITCH |
| 132 | 6696491 | STOP SWITCH CORD |
| 133 | 6696967 | PROTECTION TUBE |
| 134 | 6696486 | HANDLE (A) |
| 134 | 6696941 | HANDLE (A) |
| 135 | 6696569 | TANK |
| 136A | 6600351 | PUMP FILTER |
| 139 | 6696557 | FLANGE BOLT |
| 139 | 6696574 | BOLT (W/FLANGE) L17.8 |
| 140A | 6698716 | FUEL PIPE |
| 142A | 6697846 | RETURN GROMMET |
| 144A | 6698402 | FUEL TANK CAP ASS'Y |
| 145 | 6684899 | WOODRUFF KEY 3X13X4.5 |
| 146 | 6699463 | MAGNETO KEY SET |
| 162 | 949556 | NUT M6 |
| 163 | 6696975 | LOOP HANDLE |
| 165 | 6698325 | FLEXIBLE SHAFT |
| 169 | 6698323 | FLEXIBLE LINER |
| 170 | 6696972 | HANDLE HOLDER (A) |
| 171 | 6696974 | BOLT (BLACK) M6 |
| 174 | 6698322 | MAIN PIPE |
| 177A | 6698809 | GUARD |
| 184 | 608VVM | BALL BEARING 608VVC2PS2L |
| 186 | 608DDM | BALL BEARING 608DD |
| 192 | 6698336 | MAIN PIPE (A) |
| 195 | 6685074 | TAPPING SCREW D5X16 |
| 202 | 608DDM | BALL BEARING 608DD |
| 208 | 6684639 | BOLT WASHER 6 |
| 216 | 6698798 | BUTTON |
| 217 | 6698799 | CORD GUIDE |
| 218 | 6698800 | CASE |
| 222A | 6698931 | FUEL GROMMET |
| 225 | 6600340 | MUFFER HEAT COVER |
| 228 | 6699691 | CAMPLATE ASS'Y |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Hitachi websites, which we consider as reliable Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to hitachi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
