Fox Spare Parts for Bench Drill F12-921A

€59.88
Tax included

Fox Spare Parts for Drill Press F12-921A

We supply original FOX spare parts on offer at unbeatable prices, we are a service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Bench Drill Press F12-921A .

- NOT SUITABLE FOR DRILL PRESS "MADE IN DELTA FRANCE"
ITEM CODE: F12921A-01
Quantity
on 10 Business Days Approx

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Fox Spare Parts for Drill Press F12-921A

We supply original FOX spare parts on offer at unbeatable prices, we are a service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Bench Drill Press F12-921A .

- NOT SUITABLE FOR DRILL PRESS "MADE IN DELTA FRANCE"

In the following table, look for the model of the Bench Drill and the respective parts of the code.
Drill Press F12-921A
Drill Press F12-921A
# Part Num. Descrizione
1 F12921A-01 BASE
2 F12921A-02 SEAT
6 F12921A-06 WORKTABLE VICE
7 F12921A-07 WORKTABLE
10 DP12-903 KEY CHUCK MM 13 B16
11 F12921A-11 BEARING 6201
12 F12921A-12 WASHER
13 F12921A-13 SLEEVE
14 F12921A-14 PRINCIPAL AXIS
15 F12921A-15 POINTER
17 F12921A-17 BOLT
19 F12921A-19 CHUCK PROTECTION
20 F12921A-20 HANDLE - DISCONTINUED
26 F12921A-26 SWITCH BOX
27 F12921A-27 RETAINING RING
29 F12921A-29 MAGNETIC SWITCH
32 F12921A-32 RETAINING RING
33 F12921A-33 BEARING 6203
34 F12921A-34 SLEEVE
35 F12921A-35 RETAINING RING
36 F12921A-36 SCREW
37 F12921A-37 PULLEY
42 F12921A-42 PLUG CORD
46 F12921A-46 CONDUIT
48 F12921A-48 GUARD COMPONENT
56 F12921A-56 COVER PLATE
58 F12921A-58 MICROSWITCH
62 F12921A-62 COVER
63 F12921A-63 V-BELT
65 F12921A-65 PIN
66 F12921A-66 SPRING
67 F12921A-67 SUPPORT ROAD
68 F12921A-68 CRASH PAD
69 F12921A-69 MOTOR
70 F12921A-70 PULLEY
71 F12921A-71 HANDLE
75 F12921A-75 AXIS
76 F12921A-76 LEVER
77 F12921A-77 HANDLE LEVER
78 F12921A-78 COLUMN
82 F12921A-82 BOTTOM BOARD
84 F12921A-84 CAPACITOR
85 F12921A-85 COMPLETE SPRING
86 F12921A-86 MOTOR FAN COVER
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Fox websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Fox F12-921A
8 Items

Data sheet

SHIPPING IN:
Usually Ships in: 10 BUSYNESS DAYS APPROX.
MORE INFO:
PLEASE PAY ATTENTION! FOR MACHINES FEMI SPA DISTRIBUTION ONLY
CHECK ITEM CODE OR S/N:
CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
