Flex Spare Parts for Vacuum Cleaner VC 35 L MC

€13.75
Tax included

Flex Spare Parts for Vacuum Cleaner VC 35 L MC

We supply original FLEX spare parts on offer at unbeatable prices, we are a service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Vacuum Cleaner L MC/01.09.2012.
ITEM CODE: 297461
Quantity
on 10 Business Days Approx

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Flex Spare Parts for Vacuum Cleaner VC 35 L MC

We supply original FLEX spare parts on offer at unbeatable prices, we are a service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Vacuum Cleaner L MC/01.09.2012.

In the following table, look for the model of the Vacuum Cleaner and the respective parts of the code.
Flex VC 35 L MC - 01.09.2012

Vacuum Cleaner L MC/01.09.2012
Top Cover Pag.1
# Part Num. Description
1 297453 PROBE X S36
2 297461 SPRING X S.36
3 340618 SWITCH S47
4 297496 5x100 SCREW
5 297518 SCREW 5x50 S36
6 297526 HANDLE COMPLETE OEM S36
7 297534 CABLE COMPLETE
8 297542 HOLDER ACCESSORIES S36
9 329797 SCREW, KT, KT 4 x 16 vz
10 297569 S36 DRAIN
12 297577 FRONT PANEL
13 374466 Haube f. Sauger VC 35 L MC
14 297593 INDICATOR GREEN S36
15 297607 JACK S CURRENT 36
16 297615 MICRO SWITCH X S36
17 297623 S36 PROTECTION
19 297631 SCREW 3,5x12 S36
Turbine And Gear Box Pag.2
1 297801 S36 COVER
2 297828 SEAL S36
4 297844 ENGINE S 36
5 297852 SEAL S 36
6 297860 SEAL X S36
7 297879 SEAL S36
8 297887 COVER TURBINE S36
9 297895 CAP TURBINE S36
10 297909 BRUSH AND X S36 S35
11 297917 COVER INTERN.COMPL.S 36
12 297925 SEAL X S36
14 297941 ELECTRONIC CARD X S36
15 297968 CLOSE X S36
16 297976 SEAL S36
17 297984 SCREW 5x50 S36
18 297992 CONTACT SPRING VC35LMC
19 298018 LOCKWASHER
20 297550 SCREW 4x16 VCE
Filter Pag.3
1 305766 FILTER RECIRCULATION XS 36-PZ 3
2 337692 HEPA FILTER
3 298042 FILTER SMALL S36
4 298050 COVER X FILTER S36
6 297550 SCREW 4x16 VCE
7 298220 COMPLETE HOLDER 1200 W S36
8 298093 PLATE S36
9 298123 BUTTON
10 298115 FILTER EIN S36
11 298271 HINGE CLOSING S36
Tank Pag.4
2 298131 TANK X S36
3 298158 BOCCHETTA S36 / S47
4 298166 S36 AXIS
5 298174 WASHER X S47
6 394041 WHEEL COVER (VC / VCE - 35/45)
7 298190 REAR WHEEL X S47
8 298204 WHEELS X S36
9 298212 CONNECTION X S36
10 298298 BOLT S36
Accessories Pag.5
2 379654 SNAP RING SH-C 32 GRAY
3 299782 SUCTION HOSE
4 298239 RUBBER CORD S36
6 259827 UNIVERSAL ADAPTER, 25-32 m
7 251847 ADAPTER, Ø 32/28 mm
8 296961 PAPER FILTER BAG 5 PCS
9 296953 EXTENSION FOR SUCTION HOSE
14 300675 BRUSH
15 300683 RUBBER
16 300659 Bocchetta a clip per pavimenti
