Flex LW 1703 S Wet Stone Grinder Spare Parts
€0.11
Tax included
Flex LW 1703 S Wet Stone Grinder Spare Parts
Flex Genuine spare parts or replacement parts for to fix LW 1703 S - 950 watt Wet Stone Grinder with PRCD (308773) (129656).
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Flex LW 1703 S Wet Stone Grinder Spare Parts
Flex Genuine spare parts or replacement parts for to fix LW 1703 S - 950 watt Wet Stone Grinder with PRCD (308773) (129656).
In the following table, look for the model of the Sander and the respective parts of the code.
| Flex LW 1703 S - 950 watt Wet Stone Grinder with PRCD (308773) (129656) | ||
| # | Part Num. | Description |
| 2 | --- | |
| 3 | 251331 | Switch M.1245.0104 L 1509 FR |
| 4 | 218294 | Hose, cable protection 10.1 mm |
| 5 | 283606 | Cable with PRCD 10mA 3G1 4m |
| 6 | DIN7985-M4X8 | Lens screw M4x8 DIN7985 galvanized |
| 7 | 195693 | Screw, KT-, KT 4 x 30 |
| 8 | 304735 | Gearbox housing LW 1703 |
| 9 | 439770 | Bearing, sintered 9x13x10 |
| 11 | 257602 | Disc, distance- 0.2 |
| 12 | DIN7985-M4X12-T | Lens screw. M4x12 DIN7985 Torx galvanized |
| 13 | 257591 | Ring, seal 6202 ZAV |
| 14 | 306258 | Mounting the gear shaft LW 1703 |
| 15 | 113263 | ring, support |
| 16 | 113247 | bushing, stuffing |
| 17 | 113271 | Pin, thread with hole |
| 18 | 292478 | Threaded socket |
| 19 | DIN3601-24X1N | O-ring 24x1 NBR70 |
| 20 | 6000LLTN9-803 | Deep groove ball bearings |
| 21 | 308641 | Lid, bearing with flask. 6.3 |
| 22 | 235164 | Wind blades with straight blades |
| 23 | 607LLTN9-803 | Deep groove ball bearings |
| 24 | --- | --- |
| 25 | 159247 | Airflow |
| 26 | 255954 | Screw,KT-,KT 4 x 70 |
| 27 | 290513 | Stranded wire, connected size AWG16 260mm |
| 28 | 212636 | Capacitor X1Y 0.22F |
| 29 | 405442 | Motor housing-17-m.Kh. |
| 30 | 200506 | Lever, switch black |
| 31 | 225304 | rod, switch |
| 32 | 195820 | spring, compression |
| 34 | 293911 | Clamp bracket LW 1503 S |
| 35 | 280259 | Protective conductor plate |
| 36 | DIN7981-F3,9X13 | Pan head sheet metal screw F3.9x13 galvanized |
| 37 | 399647 | Ab.CharcoalK96 6.3x8x15.9L26F12T1 |
| 38 | 317632 | Cover for coal holder L 1517 |
| 39 | 213373 | Screw, KT-, KT 4 x 209 |
| 40 | 215074 | Clamp, cable complete. DMR9.4mm |
| 41 | 244902 | Hood printed L 1517 |
| 42 | DIN3601-48X1,2N | O-ring 48x1.2 NBR70 |
| 43 | 306231 | Water supply complete LW 1703 |
| 44 | 305626 | Elbow with pipe LW 1703 |
| 45 | 251646 | Rooster, ball R 14 |
| 46 | 251648 | Seal, polyamide |
| 47 | 251650 | connector |
| 48 | 293709 | Handle, complete LW 1703 |
| 49 | DIN7984-M8X12 | Hexagon socket screw. low head galv.ver |
| 50 | 258856 | deflection, air |
