Flex Spare Parts for Rotary Hammer CHE 5-45
search
  • Flex Spare Parts for Rotary Hammer CHE 5-45
  • Flex Spare Parts for Rotary Hammer CHE 5-45

Flex Spare Parts for Rotary Hammer CHE 5-45

€9.31
Tax included

Flex Spare Parts for Rotary Hammer CHE 5-45

Flex genuine spare parts or replacements parts for to fix Rotary Hammer SDS MAX CHE 5-45.
ITEM CODE: 371939
Quantity

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Flex Spare Parts for Rotary Hammer CHE 5-45

Flex genuine spare parts or replacements parts for to fix Rotary Hammer SDS MAX CHE 5-45.

In the following table, look for the model of the Hammer and the respective parts of the code.
Flex CHE 5-45

Rotary Hammer CHE 5-45
# Part Num. Description
1 371920 STOPPER
2 371939 SLEEVE
3 371947 ELASTIC RING
4 371955 WASHER
5 371963 SPACER
6 371971 RING
7 371998 BLOCK
8 372005 WASHER
9 372013 SPRING
10 373133 ELASTIC RING
11 372021 SLEEVE
12 372048 SLEEVE
13 372986 LIVES
14 373125 ELASTIC RING
15 372056 RING
16 372064 SEAL
17 372994 BOLTS
18 372072 FLANGE
19 372080 O-Ring
20 372099 CANNON
24 372102 BALL
25 372110 CAGE
26 372129 SPRING
27 372137 SHOCK
28 372145 O-Ring
29 372153 SHOCK
30 372161 BEARING
31 372188 SWITCH
32 372196 HOUSING CANNON
33 372218 SPACER
34 372226 SPRING
35 372234 SPRING
36 372242 RING
37 372250 CLUTCH
38 372269 ELASTIC RING
39 372277 GEAR CLUTCH
40 372285 SWING
41 372293 O-Ring
42 372307 PISTON
43 372315 SELECTOR
44 372323 PISTON PIN
45 372331 O-Ring
46 373001 SCREW
47 372358 SPRING
48 372366 ROD
51 372374 COVER
52 372382 STOPPER
53 373036 BOLTS
54 372390 ECCENTRIC
55 372404 BEARING
56 373141 ELASTIC SPRING
57 372412 GEAR
58 372420 WASHER
60 372439 O-Ring
61 372447 SHAFT
62 372455 BEARING
63 372463 BUSH
64 372471 GEAR
65 372498 O-Ring
68 372501 BEARING
69 372528 PROTECTION
70 372536 ARMATURE
71 372544 PROTECTION
72 372552 PROTECTION PAD
73 372560 COVER
74 373044 BOLTS
75 372579 STATOR
76 373052 BOLTS
77 372587 ELECTRONIC BOARD
78 372595 ENGINE HOLDER
79 372609 CARBON BRUSHES HOLDER
80 372617 BRUSHES
81 372625 BRUSH
82 372633 COVER
83 372641 SPACER
84 372668 PLATE
85 373060 BOLTS
86 373079 WASHER
87 372676 COVER
88 373087 BOLTS
89 372684 SPRING
90 372692 SHOCK
92 372714 HOLDER
93 372722 HANDLE BODY
94 372730 SWITCH
95 372749 COVER
96 373095 BOLTS
97 372757 CLAMP
98 373028 BOLTS
99 372765 CABLE PROTECTION
100 372773 CABLE
101 372781 WASHER
102 373109 SCREW
103 372803 CONTROL
104 372811 BELT
105 372838 CLAMP
106 372846 FLYER
107 373117 SCREW
108 372854 HOLDER
109 372862 HANDLE
110 373176 RULER
113 373524 ATTACK
114 373532 GEAR BOX
115 373540 GEAR HOLDER
120 373168 FAT

All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Flex websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Flex brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Flex CHE 5-45
6 Items
New

Download

Diagram Flex CHE 5-45

Diagram Flex CHE 5-45

Download (316.15KB)
