Flex Spare Parts for Angle Grinder LE 9-10 125
€9.71
Tax included
Flex Spare Parts for Angle Grinder LE 9-10 125
Flex original spare parts for to replace broken parts for to fix Angle Grinder LE 9-10 125.Fix Your Angle Grinder. All Spares are Ready For Quick Delivery. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Flex Spare Parts for Angle Grinder LE 9-10 125
Flex original spare parts for to replace broken parts for to fix Angle Grinder LE 9-10 125.
In the following table, look for the model of the Angle Grinder and the respective parts of the code.
| Angle Grinder LE 9-10 125 | ||
| # | Part NUm. | Description |
| 1 | 336440 | STOP BUTTON L 3709 |
| 2 | 336467 | SPRING BUTTON FERMOL 3709 |
| 3 | 357871 | SCREW THE 9-10125 |
| 4 | 336475 | BODY HEAD L 3709 |
| 5 | 336483 | ROLLER HEAD BEARING L3709 |
| 6 | 357901 | O-RING THE 9-10125 |
| 7 | 336459 | PIN ARREST L 3709 |
| 8 | 357936 | THE CROWN 9-10125 |
| 9 | 336513 | SNAP RING L3709 |
| 10 | 336505 | L3709 DISC |
| 11 | 119482 | BEARING 6201 RS 2 |
| 12 | 336521 | BUSH L 3709 |
| 13 | 357987 | DISTANCE RING THE 9-10125 |
| 14 | 336556 | L3709 DRIVE SHAFT |
| 15 | 358002 | HOUSING INGRANAGGILE 9-10125 |
| 16 | 331457 | M4X12 SCREW |
| 17 | 358029 | HEADSET LE 9 TO 10 |
| 18 | 335282 | WASHER SMOOTH L3709 |
| 19 | 100080 | NUT M14 |
| 20 | 100110 | KEY, STIRNLOCH-, BL 5 |
| 21 | 335274 | THE GRIP 3709 |
| 22 | 336580 | WASHER L '3709 |
| 23 | 221872 | HEX NUT M6 DIN 934 |
| 24 | 336599 | PINION 3709 |
| 25 | 336602 | L3709 DISC |
| 26 | 336610 | BEARING X L 3709 |
| 27 | 358150 | FAN 9-10125 |
| 28 | 358169 | ARMATURE 9-10125 |
| 29 | 336645 | SEAL L3709 |
| 30 | 254443 | BEARING 607 2 RSD |
| 31 | 336653 | BEARING COVER RUBBER |
| 32 | 358207 | RING THE MAGNETIC 9-10125 |
| 33 | 336661 | BAFFLE L3709 |
| 34 | 336823 | KT SCREW 4,2X60 L 3709 |
| 35 | 358231 | STATOR 9-10125 |
| 36 | 358258 | BODY OF THE ENGINE 9-10125 |
| 37 | 336769 | L3709 SWITCH |
| 38 | 336831 | SCREW KT 2,9X8 L 3709 |
| 39 | 336718 | BRUSH HOLDER 3709 |
| 40/50 | 336807 | CARBON BRUSH L3709 |
| 41 | 336858 | L3709 SPRING |
| 42 | 358304 | PTC TEMPERATURE OF THE S. 9-10125 |
| 43 | 377163 | CAPACITOR LE9-10 125 |
| 45 | 336777 | 0-RING X SKL 2903 |
| 46 | 336742 | CLAMP L3709 |
| 47 | 358363 | SCREW THE 9-10125 |
| 48 | 358347 | ROD OF CHANGE THE 9-10125 |
| 49 | 358371 | THE LEVER 9-10125 |
| 51 | 336750 | PROTECTION OF CABLE PIPE L3709 |
| 52 | 358401 | COVER THE 9-10125 |
| 53 | 329797 | SCREW, KT, KT 4 X 16 VZ |
| 54 | 386154 | PLUG THE CABLE M. 9-10125 |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Flex websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Flex brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
